5945-00-557-4449
Electromagnetic Relay
5945005574449 005574449 1248039 72A0X-92094
A relay which is actuated by the effect of a magnetic field developed by the current in its energizing coil(s). Includes solenoid and armature types. Excludes CONTACTOR, MAGNETIC; RELAY, METER MOVEMENT; RELAY, MOTOR DRIVEN; RELAY, REED; RELAY, RESONANT REED; RELAY, ROTARY; and SWITCH, STEPPING. View more Electromagnetic Relay
May 2023
6
Marketplace 5945-00-557-4449
Request a Quotation from participating marketplace vendors
Related Documents 5945-00-557-4449 2+ Documents (More...)
Photo 1/3 5945-00-557-4449 Photo 2/3 5945-00-557-4449 Photo 3/3 - - - 1.
RQST NE Updated Every Day 5945-00-557-4449 RQST Updated Every Day 5945-00-557-4449 RQST NE Related Documents
Restrictions 5945-00-557-4449
5945-00-557-4449 is a Electromagnetic Relay that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 5945-00-557-4449
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5945-00-557-4449
- US Navy (N9BN)
- Effective Date:
- 1 Nov 2005
- Former MOE Rule:
- N9ND
- Supplementary Collaborators:
- HD
- Turkey (ZW01)
- Effective Date:
- 1 Nov 1998
Approved Sources 5945-00-557-4449
- Part Number
- Manufacturer
- Status
- 1248039
- Manufacturer
- 10001 - Navair And Navsea Managed Original (Active)
- Primary Buy
- Primary Buy
- 1248039
- 03848 - Arma Div (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- 72A0X-92094
- 78277 - Sigma Instruments Inc (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5945-00-557-4449
- Characteristic
- Specifications
- FIIG
- Specifications
- A03300
- Duty Type [APNP]
- Continuous
- Center To Center Distance Between Mounting Facilities Parallel To Length [ABKQ]
- 1.625 Inches Nominal Second Mounting Facility
- Center To Center Distance Between Mounting Facilities Parallel To Width [ABKR]
- 1.625 Inches Nominal Second Mounting Facility
- Coil Quantity [APCN]
- 1
- Environmental Protection [ADZC]
- Hermetic
- Features Provided [CBBL]
- Polarized
- Minimum Differential Electrical Operating Rating [CTCN]
- 0.036 Milliamperes
- Mounting Facility Type And Quantity [AXHR]
- 1 Plug-In Terminal First Mounting Facility
- Mounting Facility Type And Quantity [AXHR]
- 2 Threaded Stud Second Mounting Facility
- Mounting Facility Pattern [CQYJ]
- Diagonal Second Mounting Facility
- Nominal Thread Size [CQJX]
- 0.138 Inches Second Mounting Facility
- Nonpile-Up Main Contact Arrangement [CRNG]
- 1 Pole, Double Throw, One Position Momentary
- Main Contact Load Current Rating At Maximum Rated Voltage [CTDL]
- 2.0 Amperes Ac Resistive Load And 2.0 Amperes Dc Resistive Load
- Main Contact Maximum Voltage Rating In Volts [CWAB]
- 120.0 Ac And 28.0 Dc
- Overall Height [ABKW]
- 3.210 Inches Nominal
- Overall Length [ABHP]
- 1.590 Inches Nominal
- Overall Width [ABMK]
- 1.590 Inches Nominal
- Winding Dc Resistance Rating [APNA]
- 5.5 Kilohms Nominal All Windings
- Winding Quantity [AKDX]
- 2
- Terminal Type And Quantity [TTQY]
- 7 Pin All Functions
- Thread Class [AAJD]
- 2A Second Mounting Facility
- Thread Quantity Per Inch [CMLP]
- 32 Second Mounting Facility
- Thread Series Designator [THSD]
- Unc Second Mounting Facility
DLA Procurement Analysis 5945-00-557-4449
Management Data 5945-00-557-4449
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5945-00-557-4449
Freight Information 5945-00-557-4449
5945-00-557-4449 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061300. A Sub NMFC of X. It has a NMFC Description of CIRCUIT BREAKER/SWITCH NOI. 5945-00-557-4449 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. 5945-00-557-4449 is rated as class 77.5 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 34410 which rates the freight between FCL and LCL. 5945-00-557-4449 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 72D for ocean manifesting and military sealift. 5945-00-557-4449 is not classified as a special type of cargo when transported by water. 5945-00-557-4449 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5945-00-557-4449
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- 0.25 lb or less, one dimension 2" or less, other dimensions less than 24"
- 85 to 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- --
- --
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
- Special requirements
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- Any Suitable Fiber Box
Contracting Technical Data File (CTDF) 5945-00-557-4449 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
