5940-00-186-2531
Terminal Board
5940001862531 001862531 BA10004-17 1020-5 18-140
An item consisting of insulating material, which is specifically designed to have fastened thereon, or on which are fastened terminal(s), such as screws, solder lugs, solder studs, solderless connectors, clips, and the like. It is usually used for junctions or terminations of wire or cable assemblies. It does not include items as defined above with parts, such as resistors and capacitors mounted thereon. Do not use if a more specific name exists, such as FUSEHOLDER; HOLDER, RESISTOR; FANNING STRIP; CONTACT ASSEMBLY, ELECTRICAL; JACK ASSEMBLY, TIP; CHAMBER, CABLE TERMINAL; PANEL (2) (as modified); CONNECTOR (as modified). Excludes TERMINAL, STUD; TERMINAL, FEEDTHRU, INSULATED; POST, BINDING, ELECTRICAL; and CHASSIS, ELECTRICAL-ELECTRONIC EQUIPMENT. For items having printed electrical conductor paths, see PRINTED WIRING BOARD. View more Terminal Board
May 2023
5
Marketplace 5940-00-186-2531
Request a Quotation from participating marketplace vendors
Related Documents 5940-00-186-2531 5+ Documents (More...)
/fsg-59/fsc-5940/us
5940-00-186-2531 RQST Updated Every Day 5940-00-186-2531 RQST NE Related Documents 5940-00-186-2531
RQST Updated Every Day 5940-00-186-2531 RQST NE Related Documents 5940-00-186-2531 RQST Updated
/fsg-59/fsc-5940/us
Vendor Details... 10205 TERMINAL BOARD 99 EA NS Request Quotation Subscribe to View Vendor Details... 1020-5
TERMINAL BOARD 1 EA NS Request Quotation Subscribe to View Vendor Details... 18-140 TERMINAL BOARD
/fsg-99/fsc-9999/dk
/fsg-99/fsc-9999/dk
/fsg-99/fsc-9999/dk
Restrictions 5940-00-186-2531
5940-00-186-2531 is a Terminal Board that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 5940-00-186-2531
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5940-00-186-2531
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
Approved Sources 5940-00-186-2531
- Part Number
- Manufacturer
- Status
- BA10004-17
- Manufacturer
- 32869 - O. C. Keckley Company (Active)
- Primary Buy
- Primary Buy
- 1020-5
- 96214 - Raytheon Company (Active)
- Primary Buy
- Primary Buy
- BA10004-17
- 71785 - Cinch Connectivity Solutions Inc. (Active)
- Primary Buy
- Primary Buy
- 18-140
- 71785 - Cinch Connectivity Solutions Inc. (Active)
- Secondary Buy
- Secondary Buy
- BA10004-17
- 64959 - American Telephone And Telegraph Co (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5940-00-186-2531
- Characteristic
- Specifications
- FIIG
- Specifications
- A011B0
- Material [MATT]
- Plastic Board
- Board Overall Length [ABGN]
- 7.375 Inches
- Board Overall Width [ABGP]
- 0.875 Inches
- Board Height Excluding Terminals [ABGR]
- 0.406 Inches
- Nonfeedthru Terminal Quantity [CSCS]
- 18 Single
- Board Construction [ABCX]
- Solid Construction
- Mounting Facility Type And Quantity [AXHR]
- 4 Unthreaded Hole
- Center To Center Distance Between Mounting Facilities Parallel To Length [ABDU]
- 7.125 Inches
- Center To Center Distance Between Mounting Facilities Parallel To Width [ABDV]
- 0.312 Inches
- Mounting Hole Diameter [AAMA]
- 0.160 Inches
- Special Features [FEAT]
- Double Screw Type Terminals
Similar Supply Items to 5940-00-186-2531
Freight Information 5940-00-186-2531
5940-00-186-2531 has freight characteristics.. 5940-00-186-2531 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
