5940-00-171-0198
Terminal Board
5940001710198 001710198 BA10004-327 601-GP-08-NH 8-141C 601-8NH 7703896P104
An item consisting of insulating material, which is specifically designed to have fastened thereon, or on which are fastened terminal(s), such as screws, solder lugs, solder studs, solderless connectors, clips, and the like. It is usually used for junctions or terminations of wire or cable assemblies. It does not include items as defined above with parts, such as resistors and capacitors mounted thereon. Do not use if a more specific name exists, such as FUSEHOLDER; HOLDER, RESISTOR; FANNING STRIP; CONTACT ASSEMBLY, ELECTRICAL; JACK ASSEMBLY, TIP; CHAMBER, CABLE TERMINAL; PANEL (2) (as modified); CONNECTOR (as modified). Excludes TERMINAL, STUD; TERMINAL, FEEDTHRU, INSULATED; POST, BINDING, ELECTRICAL; and CHASSIS, ELECTRICAL-ELECTRONIC EQUIPMENT. For items having printed electrical conductor paths, see PRINTED WIRING BOARD. View more Terminal Board
May 2023
28
Marketplace 5940-00-171-0198
Request a Quotation from participating marketplace vendors
Related Documents 5940-00-171-0198 5+ Documents (More...)
/fsg-59/fsc-5940/us
Photo 1/2 5940-00-171-0198 Photo 2/2 - - 1.
RQST NE Updated Every Day 5940-00-171-0198 RQST Updated Every Day 5940-00-171-0198 RQST NE Related
/fsg-99/fsc-9999/dk
/fsg-99/fsc-9999/dk
/fsg-99/fsc-9999/dk
/fsg-99/fsc-9999/uk
Restrictions 5940-00-171-0198
5940-00-171-0198 is a Terminal Board that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 5940-00-171-0198
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5940-00-171-0198
- Brazil (YA01)
- Effective Date:
- 1 Dec 1999
- Spain (YB01)
- Effective Date:
- 1 May 1997
- Italy (ZR01)
- Effective Date:
- 1 Jul 1997
- Denmark (ZS01)
- Effective Date:
- 1 Jul 2001
Approved Sources 5940-00-171-0198
- Part Number
- Manufacturer
- Status
- BA10004-327
- Manufacturer
- 32869 - O. C. Keckley Company (Active)
- Primary Buy
- Primary Buy
- 601-GP-08-NH
- 26405 - Regal Beloit America, Inc (Active)
- Primary Buy
- Primary Buy
- 8-141C
- 71785 - Cinch Connectivity Solutions Inc. (Active)
- Secondary Buy
- Secondary Buy
- 601-8NH
- 83330 - Dialight Corporation (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 7703896P104
- 24446 - General Electric Company (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- BA10004-327
- 64959 - American Telephone And Telegraph Co (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- BA10004-327
- 71785 - Cinch Connectivity Solutions Inc. (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- BA10004-327
- 70408 - At And T Corp (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5940-00-171-0198
- Characteristic
- Specifications
- FIIG
- Specifications
- A011B0
- Material [MATT]
- Plastic Phenolic Board
- Board Overall Length [ABGN]
- 4.250 Inches
- Board Overall Width [ABGP]
- 1.125 Inches
- Board Thickness [ABGT]
- 0.500 Inches
- Terminal Row Quantity [ABCS]
- 2
- Board Construction [ABCX]
- Solid Construction
- Terminal Facility Quantity [ABDB]
- 8
- Mounting Facility Type And Quantity [AXHR]
- 4 Unthreaded Hole
- Mounting Hole Diameter [AAMA]
- 0.175 Inches
Similar Supply Items to 5940-00-171-0198
Freight Information 5940-00-171-0198
5940-00-171-0198 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 156600. A Sub NMFC of Z. It has a NMFC Description of PLASTIC/RUBBER ARTICLE VIZ:. 5940-00-171-0198 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. 5940-00-171-0198 is rated as a variable freight class when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 77670 which rates the freight between FCL and LCL. 5940-00-171-0198 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 772 for ocean manifesting and military sealift. 5940-00-171-0198 is not classified as a special type of cargo when transported by water. 5940-00-171-0198 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
