5935-01-383-8872
Electrical Connector Coupling Nut
5935013838872 013838872 MIL-DTL-26482 MS3186C111P
An item with internal threads and an integral seat, specifically designed to hold together mated electrical connector components. View more Electrical Connector Coupling Nut
July 2025
8
Marketplace 5935-01-383-8872
Request a Quotation from participating marketplace vendors
Related Documents 5935-01-383-8872 5+ Documents (More...)
Photo 1/3 5935-01-383-8872 Photo 2/3 NSN 5935-01-383-8872 (Identification) 3/3 - - - 1.
MS3186C111P NUT,COUPLING,ELECTRICAL CONNECTOR 25 EA NS Request Quotation Updated Every Day 5935-01-383
Upgrade your Account Upgrade 5935-01-694-5137Electrical Plug Connector5935016945137 016945137 MIL-DTL-26482
your Account Upgrade 5935-01-312-5247Electrical Connector Coupling Nut5935013125247 013125247 MIL-DTL-26482
Upgrade your Account Upgrade 5935-01-596-6122Electrical Plug Connector5935015966122 015966122 MIL-DTL-26482
MIL-DTL-26482 https//www.nsnlookup.com /fsg-59/fsc-5935/us 5935- https//www.nsnlookup.com /fsg
Upgrade your Account Upgrade 5935-01-336-7731Electrical Connector Cover5935013367731 013367731 MIL-DTL-26482
Upgrade your Account Upgrade 5935-01-694-5137Electrical Plug Connector5935016945137 016945137 MIL-DTL-26482
your Account Upgrade 5935-01-312-5247Electrical Connector Coupling Nut5935013125247 013125247 MIL-DTL-26482
JavaScript in your web browser . 5935-01-685-6562Electrical Plug Connector5935016856562 016856562 MIL-DTL-26482
Restrictions 5935-01-383-8872
5935-01-383-8872 is a Electrical Connector Coupling Nut that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item does not contain a precious metal.
End Users 5935-01-383-8872
- US Air Force (FXGI)
- Effective Date:
- 1 Jun 2005
- Former MOE Rule:
- FXKZ
- US Navy (N9BZ)
- Effective Date:
- 1 Dec 2013
- Supplementary Collaborators:
- GG
- Portugal (ZP01)
- Effective Date:
- 1 Nov 2010
Approved Sources 5935-01-383-8872
- Part Number
- Manufacturer
- Status
- MS3186C111P
- Manufacturer
- 96906 - Military Standards (Active)
- Definitive Standard
- Definitive Standard
- MIL-DTL-26482
- 81349 - Military Specifications (Active)
- Incomplete Standard
- Incomplete Standard
Datasheet 5935-01-383-8872
- Characteristic
- Specifications
- FIIG
- Specifications
- A021A0
- Drilled Hole Diameter [AGGP]
- 0.042 Inches Nominal
- Bearing Surface Type [CRTM]
- Chamfered
- Hole Configuration Style [CRHC]
- Configuration B
- Hole Type And Quantity [ALET]
- 3 Drilled
- Material [MATT]
- Steel Corrosion Resisting Overall
- Nominal Thread Size [CQJX]
- 1.000 Inches
- Nut Height [ADEA]
- 0.108 Inches Minimum And 0.142 Inches Maximum
- Nut Style [ACTA]
- Hexagon
- Material Document And Classification [MDCL]
- Astm A582 Assn Std Single Material Response Overall
- Thread Series [BZRR]
- Un
- Width Across Flats [ASDB]
- 1.121 Inches Minimum And 1.155 Inches Maximum
- Surface Treatment [SFTT]
- Passivate Overall
- Thread Direction [AAJF]
- Right-Hand
- Thread Class [AAJD]
- 2B
- Thread Quantity Per Inch [CMLP]
- 20
Weapon Systems (WSDC) 5935-01-383-8872
DLA Procurement Analysis 5935-01-383-8872
- Last Stock Position:
- 3 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 5935-01-383-8872
Army
- Materiel Category and Inventory Manager:
- T
- Industrial Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5935-01-383-8872
Freight Information 5935-01-383-8872
5935-01-383-8872 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 093486. A Sub NMFC of Z. It has a NMFC Description of BOLTS,NUTS OR SCREWS, NOI (SUB 3). 5935-01-383-8872 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 48950 which rates the freight between FCL and LCL. 5935-01-383-8872 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 576 for ocean manifesting and military sealift. 5935-01-383-8872 is not classified as a special type of cargo when transported by water. 5935-01-383-8872 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5935-01-383-8872
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Bare Metal Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- No Requirement
- Not Applicable
- Bags made of material conforming to MIL-P-130, MIL-DTL-17667, MIL-PRF-121, or any material authorized by MIL-DTL-117. Closure may be by staples, tape, adhesive or heat seal
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
Contracting Technical Data File (CTDF) 5935-01-383-8872 October 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- L
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
