5935-01-365-0488
Electrical Receptacle Connector
5935013650488 013650488 MIL-DTL-38999/40 D38999/40WE99PC MIL-C-38999/40
An electrical fitting with electrical contacts constructed to be affixed to the end of a cable, conduit, coaxial line, cord, wire (includes printed/etched), PRINTED WIRING BOARD, or the like for convenience in joining with another electrical connector(s) or PRINTED WIRING BOARD. It is designed to be mounted on a bulkhead, chassis, panel, wall, PRINTED WIRING BOARD, or the like. Excludes LAMPHOLDER; JACK, TELEPHONE; JACK, TIP; INSERT ELECTRICAL CONNECTOR; INSERT MODULE, ELECTRICAL CONNECTOR; CONNECTOR BODY (as modified) and SOCKET, PLUG-IN ELECTRONIC COMPONENTS. See also WIRING HARNESS (as modified) and CABLE ASSEMBLY (as modified). For items with termination wires of more than four inches in length, see LEAD ASSEMBLY, ELECTRICAL. For items without inserts, see SHELL, ELECTRICAL CONNECTOR. View more Electrical Receptacle Connector
May 2023
3
Marketplace 5935-01-365-0488
Request a Quotation from participating marketplace vendors
Related Documents 5935-01-365-0488 5+ Documents (More...)
BUY NE FedMall Updated Every Day 5935-01-365-0488 RQST NE Updated Every Day 5935-01-365-0488 RQST
Updated Every Day 5935-01-365-0488 RQST NE Related Documents 5935-01-365-0488 5+ Documents ( More...
D38999/40WH55PD MIL-C-38999/40 An electrical fitting with electrical contacts constructed to be affixed
An electrical fitting with electrical contacts constructed to be affixed D38999/40WE6AN MIL-C-38999/40
https//www.nsnlookup.com /fsg-59/fsc-5935/us 5935-01-365-0488 Electrical Receptacle Connector 013650488
D38999/40WE99PC MIL-C-38999/40 An electrical fitting with electrical contacts constructed to be affixed
https//www.nsnlookup.com /fsg-59/fsc-5935/us 5935-01-365-0488 Electrical Receptacle Connector 013650488
D38999/40WE99PC MIL-C-38999/40 An electrical fitting with electrical contacts constructed to be affixed
An electrical fitting with electrical contacts constructed to be affixed D38999/40WE6AN MIL-C-38999/40
Electrical Receptacle Connector 013650488 D38999/40WE99PC MIL-C-38999/40 An electrical fitting
Restrictions 5935-01-365-0488
5935-01-365-0488 is a Electrical Receptacle Connector that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item contains gold.
Import and Export 5935-01-365-0488
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5935-01-365-0488
- US Navy (N9BN)
- Effective Date:
- 1 Nov 2005
- Former MOE Rule:
- N9ND
- Supplementary Collaborators:
- KE
Approved Sources 5935-01-365-0488
- Part Number
- Manufacturer
- Status
- D38999/40WE99PC
- Manufacturer
- 81349 - Military Specifications (Active)
- Definitive Standard
- Definitive Standard
- MIL-DTL-38999/40
- 81349 - Military Specifications (Active)
- Incomplete Standard
- Incomplete Standard
- MIL-C-38999/40
- 81349 - Military Specifications (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5935-01-365-0488
- Characteristic
- Specifications
- FIIG
- Specifications
- A039B0
- Distance From Mounting Shoulder To Front Face [AFQK]
- 19.2 Millimeters Minimum And 20.8 Millimeters Maximum
- Center To Center Distance Between Mounting Facilities Parallel To Height [AEBW]
- 26.98 Millimeters Nominal
- Connector Locking Method [AFRV]
- Detent
- Contact Material [CQTZ]
- Copper Alloy Single Mating End All Contact Groupings
- Contact Position Arrangement Style [AFQX]
- 17-99 Single Mating End
- Contact Removability [AFQZ]
- Removable Single Mating End All Contact Groupings
- Contact Surface Treatment [CQYH]
- Gold Single Mating End All Contact Groupings
- Distance Between Centerlines Of Mounting Facilities Parallel To Body Width [AEHA]
- 26.98 Millimeters Nominal
- Distance Between Mounting Facility Centers [AEJN]
- 26.98 Millimeters Nominal
- Environmental Protection [ADZC]
- Moisture Proof And Salt Water Resistant And Vibration Proof And Corrosion Resistant And Dust Resistant And Fuel Resistant And Fungus Resistant And Humidity Resistant And Oil Resistant And Shock Resistant And Thermal Shock Resistant And Vibration Resistant
- Body Style [AAQL]
- Straight Shape, External Coupling
- Mating End Quantity [AFQW]
- 1
- Nominal Thread Size [CQJX]
- 25.0 Millimeters
- Included Contact Quantity [CXCG]
- 2 Single Mating End 1St Contact Grouping21 Single Mating End 2Nd Contact Grouping
- Included Contact Type [CXCL]
- Round Pin Single Mating End All Contact Groupings
- Insert Position In Deg [AFRP]
- 0.0 And 80.0 And 280.0
- Insert Material [CQZG]
- Plastic Epoxy Single Mating End
- Polarization Method [AFRN]
- Key, Multiple Key Groove
- Precious Material And Location [PMLC]
- Contact Surfaces Gold
- Precious Material And Weight [PMWT]
- 0.030 Gold Grains, Troy
- Precious Material [PRMT]
- Gold
- Shell Material [CSPT]
- Aluminum Alloy
- Shell Surface Treatment [CSWM]
- Cadmium
- Shell Type [AFRT]
- Solid
- Overall Height [ABKW]
- 32.8 Millimeters Minimum And 33.9 Millimeters Maximum
- Overall Length [ABHP]
- 34.16 Millimeters Maximum
- Overall Width [ABMK]
- 32.8 Millimeters Minimum And 33.9 Millimeters Maximum
- Thread Series Designator [THSD]
- Iso M
- Thread Tolerance Class [CTTC]
- 6H External
- Threaded Device Type [AFQR]
- Back Shell
- Unthreaded Mounting Hole Diameter [AEBV]
- 3.6 Millimeters Minimum And 4.0 Millimeters Maximum
- Specification/Standard Data [ZZZK]
- 81349-Mil-C-38999/40 Government Specification
- Terminal Location [CQTM]
- Back Single Mating End All Contact Groupings
- Terminal Type [CSCF]
- Crimp Single Mating End All Contact Groupings
- Test Data Document [TEST]
- 81349-Mil-C-38999 Specification (Includes Engineering Type Bulletins, Brochures,Etc., That Reflect Specification Type Data In Specification Format; Excludes Commercial Catalogs, Industry Directories, And Similar Trade Publications, Reflecting General Type Data On Certain Environmental And Performance Requirements And Test Conditions That Are Shown As "Typical", "Average", "Nominal", Etc.).
- Thread Direction [AAJF]
- Right-Hand
DLA Procurement Analysis 5935-01-365-0488
Management Data 5935-01-365-0488
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5935-01-365-0488
Freight Information 5935-01-365-0488
5935-01-365-0488 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061680. A Sub NMFC of Z. It has a NMFC Description of ELEC WIRING PLUGS ETC. 5935-01-365-0488 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34570 which rates the freight between FCL and LCL. 5935-01-365-0488 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 658 for ocean manifesting and military sealift. 5935-01-365-0488 is not classified as a special type of cargo when transported by water. 5935-01-365-0488 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Contracting Technical Data File (CTDF) 5935-01-365-0488 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- Z
