5935-01-345-4228
Cable Clamp To Connector Adapter
5935013454228 013454228 8532050-228
An item specifically designed to be placed around that portion of a CONNECTOR, RECEPTABLE, ELECTRICAL or CONNECTOR, PLUG, ELECTRICAL which contains the facilities for attaching wires or cables.It may be designed to provide the necessary accomodations between an electrical cable clamping device and an electrical connector shell, or it may include the clamping device.It may be used for shielding against electrical interference, mechanical injury, or physical damage due to environmental conditions. View more Electrical Connector Backshell
May 2023
6
Marketplace 5935-01-345-4228
Request a Quotation from participating marketplace vendors
Related Documents 5935-01-345-4228 2+ Documents (More...)
NE Updated Every Day 5935-01-345-4228 RQST Updated Every Day 5935-01-345-4228 RQST NE Related Documents
5935-01-345-4228 1+ Documents ( More... ) https//www.nsnlookup.com /fsg-59/fsc-5935/us 5935-01-345-4228
Restrictions 5935-01-345-4228
5935-01-345-4228 is a Cable Clamp To Connector Adapter that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item does not contain a precious metal.
Import and Export 5935-01-345-4228
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5935-01-345-4228
- National Security Agency (DGX1)
- Effective Date:
- 1 Nov 2005
- Former MOE Rule:
- DTX1
- Supplementary Receivers:
- TX
- Poland (WP01)
- Effective Date:
- 1 Sep 2007
Approved Sources 5935-01-345-4228
- Part Number
- Manufacturer
- Status
- 8532050-228
- Manufacturer
- 97151 - Air Force Lifecycle Management (Active)
- Primary Buy
- Primary Buy
- 8532050-228
- 0FUP9 - Freedom Electric Custom Controls And (Active)
- Secondary Buy
- Secondary Buy
Datasheet 5935-01-345-4228
- Characteristic
- Specifications
- FIIG
- Specifications
- A10100
- Cable Opening Diameter [AGTW]
- 0.750 Inches Minimum And 0.950 Inches Maximum
- Cable Opening Quantity [AKRD]
- 1
- Material [MATT]
- Copper Alloy
- Mounting Facility Type And Quantity [AXHR]
- 1 Threaded Coupling
- Nominal Thread Size [CQJX]
- 1.375 Inches
- Overall Height [ABKW]
- 1.625 Inches Maximum
- Overall Length [ABHP]
- 2.938 Inches Minimum And 3.062 Inches Maximum
- Overall Width [ABMK]
- 1.796 Inches Minimum And 1.828 Inches Maximum
- Thread Series Designator [THSD]
- Unef
- Style Designator [STYL]
- Straight Type W/Cable Clamp
- Surface Treatment [SFTT]
- Cadmium
- Thread Direction [AAJF]
- Right-Hand
- Thread Class [AAJD]
- 2B
- Thread Quantity Per Inch [CMLP]
- 18
DLA Procurement Analysis 5935-01-345-4228
Management Data 5935-01-345-4228
Similar Supply Items to 5935-01-345-4228
Freight Information 5935-01-345-4228
5935-01-345-4228 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061680. A Sub NMFC of Z. It has a NMFC Description of ELEC WIRING PLUGS ETC. 5935-01-345-4228 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34570 which rates the freight between FCL and LCL. 5935-01-345-4228 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 658 for ocean manifesting and military sealift. 5935-01-345-4228 is not classified as a special type of cargo when transported by water. 5935-01-345-4228 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5935-01-345-4228
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- 0.25 lb or less, one dimension 2" or less, other dimensions less than 24"
- 85 to 110G
- Special Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- --
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- --
- --
- --
- --
- --
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- See Method of Preservation
- --
Contracting Technical Data File (CTDF) 5935-01-345-4228 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
