5935-01-103-6061
Electrical Receptacle Connector
5935011036061 011036061 MIL-DTL-38999 MS27468T17B6S MIL-C-38999
An electrical fitting with electrical contacts constructed to be affixed to the end of a cable, conduit, coaxial line, cord, wire (includes printed/etched), PRINTED WIRING BOARD, or the like for convenience in joining with another electrical connector(s) or PRINTED WIRING BOARD. It is designed to be mounted on a bulkhead, chassis, panel, wall, PRINTED WIRING BOARD, or the like. Excludes LAMPHOLDER; JACK, TELEPHONE; JACK, TIP; INSERT ELECTRICAL CONNECTOR; INSERT MODULE, ELECTRICAL CONNECTOR; CONNECTOR BODY (as modified) and SOCKET, PLUG-IN ELECTRONIC COMPONENTS. See also WIRING HARNESS (as modified) and CABLE ASSEMBLY (as modified). For items with termination wires of more than four inches in length, see LEAD ASSEMBLY, ELECTRICAL. For items without inserts, see SHELL, ELECTRICAL CONNECTOR. View more Electrical Receptacle Connector
November 2023
12
Marketplace 5935-01-103-6061
Request a Quotation from participating marketplace vendors
Updated Every Day Updated Every Day
Updated Every Day Related Documents 5935-01-103-6061 5+ Documents (More...)
Photo 1/3 5935-01-103-6061 Photo 2/3 NSN 5935-01-103-6061 (Identification) 3/3 - - - 1.
,ELECTRICAL 3 EA NS Request Quotation Updated Every Day 5935-01-103-6061 RQST NE Updated Every Day 5935
Restrictions 5935-01-103-6061
5935-01-103-6061 is a Electrical Receptacle Connector that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item contains gold.
Import and Export 5935-01-103-6061
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5935-01-103-6061
- US Air Force (FXGX)
- Effective Date:
- 1 Nov 2005
- Former MOE Rule:
- FXTX
- US Navy (N9BN)
- Effective Date:
- 1 Nov 2005
- Former MOE Rule:
- N9ND
- Supplementary Collaborators:
- HDKE
- Poland (WP01)
- Effective Date:
- 1 Jun 2011
- Australia (ZA01)
- Effective Date:
- 1 Aug 1995
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 2002
- Turkey (ZW01)
- Effective Date:
- 1 Dec 2005
- NATO Maintenance and Supply Agency (ZX01)
- Effective Date:
- 1 Oct 2006
Approved Sources 5935-01-103-6061
- Part Number
- Manufacturer
- Status
- MS27468T17B6S
- Manufacturer
- 96906 - Military Standards (Active)
- Definitive Standard
- Definitive Standard
- MIL-DTL-38999
- 81349 - Military Specifications (Active)
- Incomplete Standard
- Incomplete Standard
- MIL-C-38999
- 81349 - Military Specifications (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5935-01-103-6061
- Characteristic
- Specifications
- FIIG
- Specifications
- A039B0
- Distance From Mounting Shoulder To Front Face [AFQK]
- 0.915 Inches Maximum
- Bushing Accommodation Hole Shape [CXCJ]
- Round
- Connector Locking Method [AFRV]
- Bayonet Latch
- Contact Material [CQTZ]
- Copper Alloy Single Mating End Single Contact Grouping
- Contact Position Arrangement Style [AFQX]
- 17-6 Single Mating End
- Contact Removability [AFQZ]
- Removable Single Mating End Single Contact Grouping
- Contact Surface Treatment [CQYH]
- Gold Single Mating End Single Contact Grouping And Silver Single Mating End Single Contact Grouping
- Environmental Protection [ADZC]
- Moisture Proof And Salt Water Resistant And Vibration Proof
- Body Style [AAQL]
- Straight Shape Threaded
- Mating End Quantity [AFQW]
- 1
- Mounting Facility Thickness [AFQQ]
- 0.062 Inches Minimum And 0.125 Inches Maximum
- Nominal Thread Size [CQJX]
- 1.250 Inches
- Included Contact Type [CXCL]
- Round Socket Single Mating End Single Contact Grouping
- Included Contact Quantity [CXCG]
- 6 Single Mating End Single Contact Grouping
- Insert Position In Deg [AFRP]
- 0.0
- Polarization Method [AFRN]
- Keyway Or Multiple Keyway
- Precious Material And Location [PMLC]
- Contact Surfaces Gold And Contact Surfaces Silver
- Precious Material [PRMT]
- Gold And Silver
- Precious Material And Weight [PMWT]
- 0.030 Gold Grains, Troy
- Shell Material [CSPT]
- Aluminum Alloy
- Shell Surface Treatment Document And Classification [CTBC]
- Qq-P-416 Fed Spec Single Treatment Response
- Shell Surface Treatment [CSWM]
- Cadmium
- Shell Type [AFRT]
- Solid
- Overall Diameter [ADAV]
- 1.750 Inches Nominal
- Overall Length [ABHP]
- 1.243 Inches Maximum
- Threaded Device Type [AFQR]
- Mounting Bushing
- Specification/Standard Data [ZZZK]
- 96906-Ms27468 Government Standard
- Terminal Location [CQTM]
- Back Single Mating End Single Contact Grouping
- Terminal Type [CSCF]
- Crimp Single Mating End Single Contact Grouping
- Test Data Document [TEST]
- 81349-Mil-C-38999 Specification (Includes Engineering Type Bulletins, Brochures,Etc., That Reflect Specification Type Data In Specification Format; Excludes Commercial Catalogs, Industry Directories, And Similar Trade Publications, Reflecting General Type Data On Certain Environmental And Performance Requirements And Test Conditions That Are Shown As "Typical", "Average", "Nominal", Etc.).
- Thread Class [AAJD]
- 2A
- Thread Direction [AAJF]
- Right-Hand
- Thread Series Designator [THSD]
- Unef
- Thread Quantity Per Inch [CMLP]
- 18
Weapon Systems (WSDC) 5935-01-103-6061
DLA Procurement Analysis 5935-01-103-6061
- Last Stock Position:
- 26 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 5935-01-103-6061
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Oct 2022
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
- Oct 2021
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
- Apr 2021
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
- Feb 2021
- US Marine Corps (DM)
- EA
- Subscribe
- 1
- EA
- Mar 2020
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 2
- Non-Critical Repair Part
- Echelon Management:
- B2
- Operational Test:
- No Special Procedures
- Physical Category:
- 1
- Bin
Similar Supply Items to 5935-01-103-6061
Freight Information 5935-01-103-6061
5935-01-103-6061 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061680. A Sub NMFC of Z. It has a NMFC Description of ELEC WIRING PLUGS ETC. 5935-01-103-6061 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34570 which rates the freight between FCL and LCL. 5935-01-103-6061 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 658 for ocean manifesting and military sealift. 5935-01-103-6061 is not classified as a special type of cargo when transported by water. 5935-01-103-6061 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5935-01-103-6061
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- 0.25 lb or less, one dimension 2" or less, other dimensions less than 24"
- 85 to 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- --
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- --
- --
- --
- --
- --
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- See Method of Preservation
- --
Procurement History 5935-01-103-6061 2 Records
