5935-00-872-5467
Electrical Plug Connector Body
5935008725467 008725467 MA28C97S6NH24 MA28C97S6NH22 GC800KV1S 128C606H02
The main or principal part of a CONNECTOR, PLUG, ELECTRICAL which includes insert(s) designed to accommodate but does not include removable contacts. It may have a hood or shell, a jackscrew and jacksocket, or other means for polarizing and aligning. It is not designed to be mounted on a bulkhead, chassis, panel, wall, or the like. Excludes CONNECTOR BODY, MODULAR PLUG, ELECTRICAL. For items without insert(s), see SHELL, ELECTRICAL CONNECTOR. View more Electrical Plug Connector Body
November 2023
27
Marketplace 5935-00-872-5467
Request a Quotation from participating marketplace vendors
Related Documents 5935-00-872-5467 5+ Documents (More...)
... 5935-00-872-5467 CONNECTOR BODY,PLUG,ELECTRICAL RQST NS Request Quotation Updated Every Day 5935-
00-872-5467 RQST NE Updated Every Day 5935-00-872-5467 RQST Updated Every Day 5935-00-872-5467 RQST NE
5935-00-453-8693 Marketplace Restrictions Approved https//www.nsnlookup.com /fsg-59/fsc-5935/us 5935-00-872-5467
Electrical Plug Connector Body 5935008725467 RQST Updated Every Day 5935-00-872-5467 RQST NE https
Restrictions 5935-00-872-5467
5935-00-872-5467 is a Electrical Plug Connector Body that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
Import and Export 5935-00-872-5467
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5935-00-872-5467
- US Air Force (FXGX)
- Effective Date:
- 1 Jul 2005
- Former MOE Rule:
- FXTX
- US Navy (N9BN)
- Effective Date:
- 1 Dec 2013
- Supplementary Collaborators:
- GG
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Singapore (YJ01)
- Effective Date:
- 1 Apr 1991
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
Approved Sources 5935-00-872-5467
- Part Number
- Manufacturer
- Status
- MA28C97S6NH24
- Manufacturer
- 09922 - Souriau Usa, Inc. (Active)
- Primary Buy
- Primary Buy
- MA28C97S6NH22
- 09922 - Souriau Usa, Inc. (Active)
- Primary Buy
- Primary Buy
- GC800KV1S
- 26512 - Northrop Grumman Systems Corporation (Active)
- Secondary Buy
- Secondary Buy
- 128C606H02
- 48306 - Northrop Grumman Support Services (Active)
- Vendor Drawing
- Vendor Drawing
- 128C606H02
- 97942 - Northrop Grumman Systems Corporation (Active)
- Obsolete Drawing
- Obsolete Drawing
Datasheet 5935-00-872-5467
- Characteristic
- Specifications
- FIIG
- Specifications
- A039B0
- Body Style [AAQL]
- Straight Shape, External Coupling W/Backshell
- Connector Locking Method [AFRV]
- Externally Threaded Shell
- Contact Position Arrangement Style [AFQX]
- 22-55 Single Mating End
- Environmental Protection [ADZC]
- Corrosion Resistant And Moisture Resistant And Shock Proof And Thermal Shock Resistant And Vibration Resistant
- Mating End Quantity [AFQW]
- 1
- Nominal Thread Size [CQJX]
- 1.594 Inches And 1.750 Inches
- Insert Material [CQZG]
- Plastic Diallyl Phthalate Single Mating End
- Insert Position In Deg [AFRP]
- 0.0
- Polarization Method [AFRN]
- Keyway Or Multiple Keyway
- Shell Material Document And Classification [CTHH]
- Qq-A-225 Fed Spec Single Material Response
- Shell Surface Treatment Document And Classification [CTBC]
- Qq-P-416,Type 2,Class 2 Fed Spec 2Nd Treatment Response
- Shell Material [CSPT]
- Aluminum
- Shell Surface Treatment [CSWM]
- Cadmium And Chromate
- Shell Type [AFRT]
- Solid
- Overall Diameter [ADAV]
- 2.061 Inches Maximum
- Overall Length [ABHP]
- 2.190 Inches Maximum
- Thread Class [AAJD]
- 2A And 2A
- Thread Direction [AAJF]
- Right-Hand And Right-Hand
- Thread Series Designator [THSD]
- Uns And Uns
- Thread Quantity Per Inch [CMLP]
- 28 And 60
- Threaded Device Type [AFQR]
- Back Shell And Coupling Facility
Weapon Systems (WSDC) 5935-00-872-5467
DLA Procurement Analysis 5935-00-872-5467
- Last Stock Position:
- 12 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 5935-00-872-5467
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Oct 2022
- Department of the Navy (DN)
- EA
- Subscribe
- 1
- EA
- Dec 2021
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
- Oct 2021
- Defense Logistics Agency (DS)
- EA
- Subscribe
- 1
- EA
- Jan 2021
- Defense Logistics Agency (DS)
- EA
- Subscribe
- 1
- EA
- Mar 2020
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5935-00-872-5467
Freight Information 5935-00-872-5467
5935-00-872-5467 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061680. A Sub NMFC of Z. It has a NMFC Description of ELEC WIRING PLUGS ETC. 5935-00-872-5467 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34570 which rates the freight between FCL and LCL. 5935-00-872-5467 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 658 for ocean manifesting and military sealift. 5935-00-872-5467 is not classified as a special type of cargo when transported by water. 5935-00-872-5467 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5935-00-872-5467
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- 0.25 lb or less, one dimension 2" or less, other dimensions less than 24"
- 85 to 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- --
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- --
- --
- --
- --
- --
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- See Method of Preservation
- --
