5935-00-754-8711
Electrical Plug Connector
5935007548711 007548711 SAE-AS50151 23114-3751-01 MS3108R10S13S MS3108BR10SLES 21C1709-122 MS3108E10SL3S MS3108R10SL35 MS3181R10-3 CA6R10SL3SK50 217412-0002 MS3108R10SL3S MS3108R10SL-3S MS3108R10SL3SC 4911 532259 MIL-C-5015
An electrical fitting with electrical contacts, constructed to be affixed to the end of a cable, conduit, coaxial line, cord or wiring for convenience in joining with other electrical connector(s) or PRINTED WIRING BOARD and is not designed to be mounted on a bulkhead, chasses, panel, PRINTED WIRING BOARD, or the like. Excludes JACK, TELEPHONE; JACK, TIP; PLUG, TELEPHONE; PLUG TIP; INSERT, ELECTRICAL CONNECTOR; CONNECTOR BODY (as modified); and SOCKET, PLUG-IN, ELECTRONIC COMPONENTS. See also LEAD ASSEMBLY, ELECTRICAL; WIRING HARNESS (as modified); and CABLE ASSEMBLY (as modified). For items without inserts, see SHELL, ELECTRICAL CONNECTOR. View more Electrical Plug Connector
Managed by United States
NSN Created on 1 Jan 1963
Data Last Changed
July 2025
July 2025
NATO Update Count
52
52
NATO Data Quality
Marketplace 5935-00-754-8711
Need Help?
Request a Quotation from participating marketplace vendors
Request a Quotation from participating marketplace vendors
MILC5015 CONNECTOR,PLUG,ELECTRICAL 42 EA NS
21C1709-122 CONNECTOR,PLUG,ELECTRICAL 2 EA NS
MS3108R10SL-3S CONNECTOR,PLUG,ELECTRICAL 2 EA NS
MIL-C-5015 CONNECTOR,PLUG,ELECTRICAL 23 EA NS
CA6R10SL3SK50 CONNECTOR,PLUG,ELECTRICAL 4 EA NS
MS3108R10SL3SC CONNECTOR,PLUG,ELECTRICAL 2 EA NS
Updated Every Day 5935-00-754-8711 RQST NE
Updated Every Day 5935-00-754-8711 RQST
Updated Every Day 5935-00-754-8711 RQST NE
Related Documents 5935-00-754-8711 5+ Documents (More...)
SAE-AS50151 23114-3751-01 MS3108R10S13S MS3108BR10SLES 21C1709-122 MS3108E10SL3S MS3108R10SL35 MS3181R10
-3 CA6R10SL3SK50 217412-0002 MS3108R10SL3S MS3108R10SL-3S MS3108R10SL3SC 4911 532259 MIL-C-5015 An electrical
EA NS Request Quotation MS3108R10SL-3S CONNECTOR,PLUG,ELECTRICAL 2 EA NS Request Quotation MIL-C-5015
-3 CA6R10SL3SK50 217412-0002 MS3108R10SL3S MS3108R10SL-3S MS3108R10SL3SC 4911 532259 MIL-C-5015 An electrical
EA NS Request Quotation MS3108R10SL-3S CONNECTOR,PLUG,ELECTRICAL 2 EA NS Request Quotation MIL-C-5015
MS3108R10SL3S CONNECTOR,PLUG,ELECTRICAL 1 EA NS Request Quotation Subscribe to View Vendor Details...
MS3108R10SL3S CONNECTOR,PLUG,ELECTRICAL 1 EA NS Request Quotation Subscribe to View Vendor Details...
MS3108R10SL3S CONNECTOR,PLUG,ELECTRICAL 2 EA NS Request Quotation Subscribe to View Vendor Details...
MS3108R10SL3S CONNECTOR,PLUG,ELECTRICAL 1 EA NS Request Quotation Subscribe to View Vendor Details...
MS3108R10SL3S CONNECTOR,PLUG,ELECTRICAL 2 EA NS Request Quotation Subscribe to View Vendor Details...
Documents 5310-14-415-8864 2+ Documents ( More... ) https//www.nsnlookup.com /fsg-59/fsc-5935/us 5935-00-754-8711
Electrical Plug Connector 5935007548711, MS3108R10SL35 MS3181R10-3 CA6R10SL3SK50 217412-0002 MS3108R10SL3S
MS3108R10SL-3S MS3108R10SL3SC 4911 532259 ELECTRICAL 2 EA NS Request Quotation MIL-C-5015 https//www.nsnlookup.com
Electrical Plug Connector 5935007548711, MS3108R10SL35 MS3181R10-3 CA6R10SL3SK50 217412-0002 MS3108R10SL3S
MS3108R10SL-3S MS3108R10SL3SC 4911 532259 ELECTRICAL 2 EA NS Request Quotation MIL-C-5015 https//www.nsnlookup.com
MS3108R10SL3S CONNECTOR,PLUG,ELECTRICAL 1 EA NS Request Quotation Subscribe to View Vendor Details...
MIL-C-5015 CONNECTOR,PLUG,ELECTRICAL 1 EA NS Request Quotation Subscribe to View Vendor Details...
MS3108R10SL-3S CONNECTOR,PLUG,ELECTRICAL 2 EA NS Request Quotation 21C1709-122 CONNECTOR,PLUG,ELECTRICAL
MIL-C-5015 CONNECTOR,PLUG,ELECTRICAL 1 EA NS Request Quotation Subscribe to View Vendor Details...
MS3108R10SL-3S CONNECTOR,PLUG,ELECTRICAL 2 EA NS Request Quotation 21C1709-122 CONNECTOR,PLUG,ELECTRICAL
MS3108E10SL3S CONNECTOR,PLUG,ELECTRICAL 5 EA NS Request Quotation Subscribe to View Vendor Details...
MS3108E10SL3S CONNECTOR,PLUG,ELECTRICAL 3 EA NS Request Quotation Subscribe to View Vendor Details...
https//www.nsnlookup.com /fsg-59/fsc-5935/us 5935-00-754-8711 Electrical Plug Connector 5935007548711
MS3108E10SL3S CONNECTOR,PLUG,ELECTRICAL 3 EA NS Request Quotation Subscribe to View Vendor Details...
https//www.nsnlookup.com /fsg-59/fsc-5935/us 5935-00-754-8711 Electrical Plug Connector 5935007548711
Restrictions 5935-00-754-8711
5935-00-754-8711 is a Electrical Plug Connector that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item contains gold.
Import and Export 5935-00-754-8711
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5935-00-754-8711
- US Army (A918)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- A196
- Supplementary Receivers:
- AZCTCLBD
- MOE Rule:
- B031
- Effective Date:
- 1 Apr 1991
- MOE Rule:
- BGX1
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- BTX1
- US Coast Guard (C911)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- C007
- US Air Force (FXGX)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- FXTX
- US Marine Corps (MC49)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- MC13
- US Navy (N9BN)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- NIND
- Supplementary Collaborators:
- GTKEHXHD
- Austria (WB01)
- Effective Date:
- 1 Feb 2005
- Poland (WP01)
- Effective Date:
- 1 Jan 2006
- Brazil (YA01)
- Effective Date:
- 1 Sep 2000
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Columbia (YC01)
- Effective Date:
- 1 Jul 2015
- Israel (YD01)
- Effective Date:
- 1 Sep 2016
- Singapore (YJ01)
- Effective Date:
- 1 Apr 1991
- Malaysia (YW01)
- Effective Date:
- 1 Aug 1997
- Australia (ZA01)
- Effective Date:
- 1 Apr 1991
- Belgium (ZB01)
- Effective Date:
- 1 Apr 1991
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
- New Zealand (ZE01)
- Effective Date:
- 1 Apr 1991
- France (ZF01)
- Effective Date:
- 1 Apr 1991
- Germany (ZG01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- United Kingdom (ZK01)
- Effective Date:
- 1 Apr 1991
- Netherlands (ZN01)
- Effective Date:
- 1 Apr 1991
- Portugal (ZP01)
- Effective Date:
- 1 Apr 1991
- Italy (ZR01)
- Effective Date:
- 1 Apr 1991
- Denmark (ZS01)
- Effective Date:
- 1 Apr 1991
- Norway (ZT01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Nov 1998
- NATO Maintenance and Supply Agency (ZX01)
- Effective Date:
- 1 Apr 1991
Approved Sources 5935-00-754-8711
- Part Number
- Manufacturer
- Status
- SAE-AS50151
- Manufacturer
- 0U583 - Sae International (Active)
- Incomplete Reference
- Incomplete Reference
- MS3108R10SL3S
- 0U583 - Sae International (Active)
- Primary Buy
- Primary Buy
- MS3108R10SL-3S
- 0U583 - Sae International (Active)
- Primary Buy
- Primary Buy
- 23114-3751-01
- C2311 - Baainbw Benutzungsrechte An (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- MS3108R10SL3SC
- D1371 - Itt Cannon Gesellschaft Mit (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- 23114-3751-01
- D1839 - Baainbw Dokumente Ohne (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- MS3108R10SL-3S
- 96906 - Military Standards (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- MS3108R10SL3SC
- 96906 - Military Standards (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 4911 532259
- D8770 - Te Ka De Felten & Guilleaume (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- MIL-C-5015
- 81349 - Military Specifications (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- MS3108R10S13S
- 96906 - Military Standards (Active)
- Advisory Reference
- Advisory Reference
- MS3108BR10SLES
- 96906 - Military Standards (Active)
- Advisory Reference
- Advisory Reference
- 21C1709-122
- 07482 - General Electric Company (Active)
- Advisory Reference
- Advisory Reference
- MS3108E10SL3S
- 96906 - Military Standards (Active)
- Advisory Reference
- Advisory Reference
- MS3108R10SL35
- 96906 - Military Standards (Active)
- Advisory Reference
- Advisory Reference
- MS3181R10-3
- 96906 - Military Standards (Active)
- Advisory Reference
- Advisory Reference
- CA6R10SL3SK50
- 71468 - Itt Cannon Llc (Active)
- Advisory Reference
- Advisory Reference
- 217412-0002
- 99657 - Marotta Controls Inc (Active)
- Advisory Reference
- Advisory Reference
Datasheet 5935-00-754-8711
- Characteristic
- Specifications
- FIIG
- Specifications
- A039B0
- Distance From Centerline To Cable End [AKFA]
- 1.500 Inches Maximum
- Distance From Centerline To Connector End [AKEZ]
- 1.625 Inches Nominal
- Body Angle In Deg [ADMW]
- 90.0
- Connector Locking Method [AFRV]
- Internally Threaded Coupling Ring
- Contact Material [CQTZ]
- Copper Alloy Single Mating End Single Contact Grouping
- Contact Maximum Ac Voltage Rating In Volts [AFRD]
- 500.0 Single Mating End Single Contact Grouping
- Contact Maximum Current Rating In Amps [AFRC]
- 22.0 Single Mating End Single Contact Grouping
- Contact Removability [AFQZ]
- Nonremovable Single Mating End Single Contact Grouping
- Contact Maximum Dc Voltage Rating In Volts [AFRE]
- 700.0 Single Mating End Single Contact Grouping
- Contact Position Arrangement Style [AFQX]
- 10Sl-3 Single Mating End
- Contact Surface Treatment Document And Classification [CRBJ]
- Mil-G-45204,Type 1,Grade B Mil Spec 1St Treatment Response Single Mating End Single Contact Grouping And Qq-N-290,Class 1,Grade B Fed Spec 2Nd Treatment Response Single Mating End Single Contact Grouping
- Contact Surface Treatment [CQYH]
- Gold Single Mating End Single Contact Grouping And Nickel Single Mating End Single Contact Grouping
- Environmental Protection [ADZC]
- Moisture Proof And Salt Water Resistant And Vibration Proof And Shock Resistant And Cold Resistant And Heat Resistant And Explosion Proof
- Features Provided [CBBL]
- Pre-Tinned Terminal
- Body Style [AAQL]
- Angle Shape, W/O Cable Clamp
- Mating End Quantity [AFQW]
- 1
- Nominal Thread Length [AKMG]
- 0.290 Inches And 0.414 Inches
- Nominal Thread Size [CQJX]
- 0.625 Inches And 0.625 Inches
- Operating Temp Rating [AWTN]
- -55.0 Deg Celsius Minimum And 125.0 Deg Celsius Maximum
- Included Contact Quantity [CXCG]
- 3 Single Mating End Single Contact Grouping
- Included Contact Type [CXCL]
- Round Socket Single Mating End Single Contact Grouping
- Insert Material Document And Classification [CTKL]
- Mil-R-3065 Mil Spec Single Material Response Single Mating End
- Insert Material [CQZG]
- Rubber Single Mating End
- Insert Position In Deg [AFRP]
- 0.0
- Polarization Method [AFRN]
- Keyway Or Multiple Keyway
- Precious Material And Location [PMLC]
- Contact Surfaces Gold
- Precious Material And Weight [PMWT]
- 0.003 Gold Grains, Troy
- Precious Material [PRMT]
- Gold
- Shell Surface Treatment Document And Classification [CTBC]
- Qq-P-416,Type 2,Class 3 Fed Spec All Treatment Responses
- Shell Surface Treatment [CSWM]
- Cadmium And Chromate
- Shell Type [AFRT]
- Solid
- Shell Material [CSPT]
- Aluminum Alloy
- Overall Diameter [ADAV]
- 1.125 Inches Maximum
- Specification/Standard Data [ZZZK]
- 96906-Ms3108 Government Standard
- Terminal Location [CQTM]
- Back Single Mating End Single Contact Grouping
- Terminal Type [CSCF]
- Solder Well Single Mating End Single Contact Grouping
- Test Data Document [TEST]
- 81349-Mil-C-5015 Specification (Includes Engineering Type Bulletins, Brochures,Etc., That Reflect Specification Type Data In Specification Format; Excludes Commercial Catalogs, Industry Directories, And Similar Trade Publications, Reflecting General Type Data On Certain Environmental And Performance Requirements And Test Conditions That Are Shown As "Typical", "Average", "Nominal", Etc.).
- Thread Class [AAJD]
- 2A And 2B
- Thread Direction [AAJF]
- Right-Hand And Right-Hand
- Thread Series Designator [THSD]
- Unef And Unef
- Thread Quantity Per Inch [CMLP]
- 24 And 24
- Threaded Device Type [AFQR]
- Back Shell And Coupling Facility
Weapon Systems (WSDC) 5935-00-754-8711
DLA Procurement Analysis 5935-00-754-8711
- Last Stock Position:
- 456 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 5935-00-754-8711
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Oct 2022
- Department of the Navy (DN)
- EA
- Subscribe
- 1
- EA
- Oct 2021
- Defense Logistics Agency (DS)
- EA
- Subscribe
- 1
- EA
- Oct 2020
- Defense Logistics Agency (DS)
- EA
- Subscribe
- 1
- EA
- Mar 2020
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- US Marine Corps (DM)
- M
- 0
- Reversal Of Phrase Code Z 5935-00-192-3820
- 0
Army
- Materiel Category and Inventory Manager:
- Q
- Electronics Materiel (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Air Force
- Fund:
- SF
- Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point
- Budget:
- 9
- 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors
- Aggregation Code:
- EH
- ELECTRONIC COMPONENTS
- Price Validation Code:
- V
- The current standard price has been validated.
The item has been analyzed in conjunction with the Zero Overpricing Program and is in the accepted price range.
The item was procured under open competition and under the competitive arena the price is considered fair and reasonable.
ZOP or Standard price challenges are permissible but must be supported by adequate justification.
- Expendability
Recoverability
Repairability: - N
- Expendable. Condemn at User. Stock Fund (except Munitions).
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 5
- Critical Repair Part to a Combat Essential End Item
- Echelon Management:
- B2
- Material Identification:
- B
- Consumable Repair Parts
- Operational Test:
- No Special Procedures
NATO Stock Numbers Related to 5935-00-754-8711
5935-14-574-3604 5935-15-061-3649 5935-12-145-8923 5935-14-533-7391 5935-14-386-8021 5935-14-442-1970 5935-14-267-0144 5935-15-108-9253 5935-99-762-4807 5935-21-820-6744 5935-26-300-7621 5935-99-386-6420 5935-66-150-9489 5935-99-580-1134 5935-14-394-9881 5935-14-454-5696 5935-14-528-8334 5935-15-189-8376
Freight Information 5935-00-754-8711
5935-00-754-8711 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061680. A Sub NMFC of Z. It has a NMFC Description of ELEC WIRING PLUGS ETC. 5935-00-754-8711 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34570 which rates the freight between FCL and LCL. 5935-00-754-8711 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 658 for ocean manifesting and military sealift. 5935-00-754-8711 is not classified as a special type of cargo when transported by water. 5935-00-754-8711 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5935-00-754-8711
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Bare Metal Item
- Over 10lb
- Less than 85G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- 1.1" H x 1.1" W x 1.0" L
- --
- --
- --
- Any Suitable Process
- 1.1" H x 1.1" W x 1.0" L
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- MIL-DTL-17667, Neutral Wrapping Paper
- No Requirement
- Not Applicable
- --
- No special marking
- MIL-DTL-17667, Neutral Wrapping Paper
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
Contracting Technical Data File (CTDF) 5935-00-754-8711 October 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- F
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
