5935-00-665-5874
Electrical Plug Connector
5935006655874 006655874 SAE-AS50151 MS3108B24-15S MS3108B2415S MS3108A24-15S MIL-C-5015
An electrical fitting with electrical contacts, constructed to be affixed to the end of a cable, conduit, coaxial line, cord or wiring for convenience in joining with other electrical connector(s) or PRINTED WIRING BOARD and is not designed to be mounted on a bulkhead, chasses, panel, PRINTED WIRING BOARD, or the like. Excludes JACK, TELEPHONE; JACK, TIP; PLUG, TELEPHONE; PLUG TIP; INSERT, ELECTRICAL CONNECTOR; CONNECTOR BODY (as modified); and SOCKET, PLUG-IN, ELECTRONIC COMPONENTS. See also LEAD ASSEMBLY, ELECTRICAL; WIRING HARNESS (as modified); and CABLE ASSEMBLY (as modified). For items without inserts, see SHELL, ELECTRICAL CONNECTOR. View more Electrical Plug Connector
November 2023
18
Marketplace 5935-00-665-5874
Request a Quotation from participating marketplace vendors
Updated Every Day Updated Every Day
Updated Every Day Related Documents 5935-00-665-5874 5+ Documents (More...)
Plug Connector 5935006655874, MIL/C/5015 ADAPTER ,CABLE CLAMP MIL-C-5015 ,CABLE https//www.nsnlookup.com
-5935/us 5935-00-665-5874 Electrical Plug Connector 5935006655874, An ADAPTER ,CABLE CLAMP MIL-C-5015
/C/5015 ,ELECTRICAL MIL/C/5015 Connector MIL-C-5015 ,CABLE 5935006655874, MIL/C/5015 ADAPTER ,CABLE CLAMP
Plug Connector 5935009510114 MIL-C-5015 ,ELECTRICAL , ELECTRICAL MIL/C/5015 ,ELECTRICAL MIL/C/5015 MIL
/fsc-5935/us 5935-00-665-5874 Electrical Plug Connector 5935006655874, An ADAPTER ,CABLE CLAMP MIL-C-
5015 CONNECTOR ,ELECTRICAL MIL /C/5015 ,ELECTRICAL MIL/C/5015 Connector MIL-C-5015 ,CABLE 5935006655874
CONNECTOR ,ELECTRICAL MIL/C/5015 ,ELECTRICAL MIL/C/5015 Connector MIL-C-5015 ,CABLE 5935006655874
, MIL/C/5015 ADAPTER ,CABLE CLAMP MIL-C-5015 ,CABLE CLAMP MIL-C-5015 https//www.nsnlookup.com /fsg-59
, MIL/C/5015 ADAPTER ,CABLE CLAMP MIL-C-5015 ,CABLE CLAMP MIL-C-5015 ,CABLE CLAMP MIL-C-5015 CONNECTOR
-5935/us 5935-00-665-5874 Electrical Plug Connector 5935006655874, An ADAPTER ,CABLE CLAMP MIL-C-5015
Restrictions 5935-00-665-5874
5935-00-665-5874 is a Electrical Plug Connector that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item contains gold.
Import and Export 5935-00-665-5874
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5935-00-665-5874
- Brazil (YA01)
- Effective Date:
- 1 Sep 2000
- Spain (YB01)
- Effective Date:
- 1 Feb 2006
- Portugal (ZP01)
- Effective Date:
- 1 Apr 1991
Approved Sources 5935-00-665-5874
- Part Number
- Manufacturer
- Status
- SAE-AS50151
- Manufacturer
- 0U583 - Sae International (Active)
- Incomplete Reference
- Incomplete Reference
- MS3108B24-15S
- 0U583 - Sae International (Active)
- Primary Buy
- Primary Buy
- MS3108B2415S
- 0U583 - Sae International (Active)
- Primary Buy
- Primary Buy
- MS3108B24-15S
- 96906 - Military Standards (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- MIL-C-5015
- 81349 - Military Specifications (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- MS3108A24-15S
- 96906 - Military Standards (Active)
- Transferred
- Transferred
Datasheet 5935-00-665-5874
- Characteristic
- Specifications
- FIIG
- Specifications
- A039B0
- Distance From Centerline To Cable End [AKFA]
- 1.562 Inches Maximum
- Distance From Centerline To Connector End [AKEZ]
- 2.406 Inches Nominal
- Body Angle In Deg [ADMW]
- 90.0
- Connector Locking Method [AFRV]
- Internally Threaded Coupling Ring
- Contact Material [CQTZ]
- Copper Alloy Single Mating End Single Contact Grouping
- Contact Maximum Ac Voltage Rating In Volts [AFRD]
- 500.0 Single Mating End Single Contact Grouping
- Contact Maximum Current Rating In Amps [AFRC]
- 22.0 Single Mating End Single Contact Grouping
- Contact Removability [AFQZ]
- Nonremovable Single Mating End Single Contact Grouping
- Contact Maximum Dc Voltage Rating In Volts [AFRE]
- 700.0 Single Mating End Single Contact Grouping
- Contact Position Arrangement Style [AFQX]
- 24-15 Single Mating End
- Contact Surface Treatment Document And Classification [CRBJ]
- Mil-G-45204,Ty 1,Grade B Mil Spec 1St Treatment Response Single Mating End Single Contact Grouping And Qq-N-290,Cl 1,Grade B Fed Spec 2Nd Treatment Response Single Mating End Single Contact Grouping
- Contact Surface Treatment [CQYH]
- Gold Single Mating End Single Contact Grouping And Nickel Single Mating End Single Contact Grouping
- Environmental Protection [ADZC]
- Moisture Proof And Salt Water Resistant And Vibration Proof And Vibration Resistant And Cold Resistant And Heat Resistant And Explosion Proof
- Features Provided [CBBL]
- Pre-Tinned Terminal
- Body Style [AAQL]
- Angle Shape, W/O Cable Clamp
- Mating End Quantity [AFQW]
- 1
- Nominal Thread Size [CQJX]
- 1.438 Inches And 1.500 Inches
- Operating Temp Rating [AWTN]
- -55.0 Deg Celsius Minimum And 125.0 Deg Celsius Maximum
- Included Contact Quantity [CXCG]
- 16 Single Mating End Single Contact Grouping
- Included Contact Type [CXCL]
- Round Socket Single Mating End Single Contact Grouping
- Insert Material [CQZG]
- Rubber Single Mating End
- Insert Position In Deg [AFRP]
- 0.0
- Polarization Method [AFRN]
- Keyway Or Multiple Keyway
- Precious Material And Location [PMLC]
- Contact Surfaces Gold
- Precious Material And Weight [PMWT]
- 0.016 Gold Grains, Troy
- Precious Material [PRMT]
- Gold
- Shell Surface Treatment Document And Classification [CTBC]
- Qq-P-416,Ty 2,Cl 3 Fed Spec All Treatment Responses
- Shell Surface Treatment [CSWM]
- Cadmium And Chromate
- Shell Material [CSPT]
- Aluminum Alloy
- Shell Type [AFRT]
- Split
- Overall Diameter [ADAV]
- 2.000 Inches Maximum
- Specification/Standard Data [ZZZK]
- 96906-Ms3108 Government Standard
- Terminal Location [CQTM]
- Back Single Mating End Single Contact Grouping
- Terminal Type [CSCF]
- Solder Well Single Mating End Single Contact Grouping
- Test Data Document [TEST]
- 81349-Mil-C-5015 Specification (Includes Engineering Type Bulletins, Brochures,Etc., That Reflect Specification Type Data In Specification Format; Excludes Commercial Catalogs, Industry Directories, And Similar Trade Publications, Reflecting General Type Data On Certain Environmental And Performance Requirements And Test Conditions That Are Shown As "Typical", "Average", "Nominal", Etc.).
- Thread Class [AAJD]
- 2A And 2B
- Thread Direction [AAJF]
- Right-Hand And Right-Hand
- Thread Quantity Per Inch [CMLP]
- 18 And 18
- Thread Series Designator [THSD]
- Unef And Unef
- Threaded Device Type [AFQR]
- Back Shell And Coupling Facility
NATO Stock Numbers Related to 5935-00-665-5874
Freight Information 5935-00-665-5874
5935-00-665-5874 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061680. A Sub NMFC of Z. It has a NMFC Description of ELEC WIRING PLUGS ETC. 5935-00-665-5874 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. 5935-00-665-5874 is rated as class 77.5 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 34570 which rates the freight between FCL and LCL. It has a Water Commodity Code (WCC) of 658 for ocean manifesting and military sealift. 5935-00-665-5874 is not classified as a special type of cargo when transported by water. 5935-00-665-5874 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
