5935-00-629-9276
Electrical Plug Connector
5935006299276 006299276 453C120 A2286 573442 7762606 99925 1082G6 120466 1204G6 108266
An electrical fitting with electrical contacts, constructed to be affixed to the end of a cable, conduit, coaxial line, cord or wiring for convenience in joining with other electrical connector(s) or PRINTED WIRING BOARD and is not designed to be mounted on a bulkhead, chasses, panel, PRINTED WIRING BOARD, or the like. Excludes JACK, TELEPHONE; JACK, TIP; PLUG, TELEPHONE; PLUG TIP; INSERT, ELECTRICAL CONNECTOR; CONNECTOR BODY (as modified); and SOCKET, PLUG-IN, ELECTRONIC COMPONENTS. See also LEAD ASSEMBLY, ELECTRICAL; WIRING HARNESS (as modified); and CABLE ASSEMBLY (as modified). For items without inserts, see SHELL, ELECTRICAL CONNECTOR. View more Electrical Plug Connector
August 2025
17
Marketplace 5935-00-629-9276
Request a Quotation from participating marketplace vendors
Related Documents 5935-00-629-9276 5+ Documents (More...)
... ) https//www.nsnlookup.com /fsg-59/fsc-5935/us 5935-00-629-9276 Electrical Plug Connector 5935006299276
Electrical Plug Connector 5935006299276 Electrical Plug Connector 5935006299276 Connector 5935006299276
www.nsnlookup.com /fsg-53/fsc-5315/us 5315-00-102-8948 Machine Key 5315001028948 001028948,108266 108266
https//www.nsnlookup.com /fsg-59/fsc-5935/us 5935-00-629-9276 Electrical Plug Connector 5935006299276
A2286 Managed by United States NSN Created on 1 Jan 1961 Data Last Changed January 2023 NATO Update
Release Spring 2520003118351003118351,A2286 how to enable JavaScript in your web browser . 2520 -00-
CONNECTOR,PLUG,ELECTRICAL RQST NS Request Quotation 99925 CONNECTOR,PLUG,ELECTRICAL RQST NS Request
Quotation 7762606 CONNECTOR,PLUG,ELECTRICAL RQST NS Request Quotation Subscribe to View Vendor Details
CONNECTOR,PLUG,ELECTRICAL RQST NS Request Quotation 573442 CONNECTOR,PLUG,ELECTRICAL RQST NS Request
Quotation 99925 CONNECTOR,PLUG,ELECTRICAL RQST NS Request Quotation Subscribe to View Vendor Details
Restrictions 5935-00-629-9276
5935-00-629-9276 is a Electrical Plug Connector that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
Import and Export 5935-00-629-9276
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5935-00-629-9276
- Austria (WB01)
- Effective Date:
- 1 Feb 2005
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Jun 1995
- Turkey (ZW01)
- Effective Date:
- 1 Sep 2009
Approved Sources 5935-00-629-9276
- Part Number
- Manufacturer
- Status
- 453C120
- Manufacturer
- 46522 - Dcm Manufacturing, Inc. (Active)
- Primary Buy
- Primary Buy
- A2286
- 46522 - Dcm Manufacturing, Inc. (Active)
- Primary Buy
- Primary Buy
- 573442
- 19204 - Army, United States Department Of (Active)
- Secondary Buy
- Secondary Buy
- 7762606
- 19204 - Army, United States Department Of (Active)
- Secondary Buy
- Secondary Buy
- 99925
- 58464 - Sheller-Globe Corp Superior-Lima Div (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- 1082G6
- 56442 - Diamond Reo Truck Co (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- 120466
- 56442 - Diamond Reo Truck Co (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- 1204G6
- 56442 - Diamond Reo Truck Co (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- 573442
- 81263 - Universal Components Corp (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- 7762606
- 81263 - Universal Components Corp (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- 108266
- 56442 - Diamond Reo Truck Co (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5935-00-629-9276
- Characteristic
- Specifications
- FIIG
- Specifications
- A039B0
- Overall Length [ABHP]
- 0.875 Inches Nominal
- Overall Diameter [ADAV]
- 0.640 Inches Nominal
- Connector Locking Method [AFRV]
- Shell Twistlock
- Cable Entrance Diameter [AFQJ]
- 0.235 Inches Nominal
- Shell Material [CSPT]
- Steel
- Mating End Quantity [AFQW]
- 1
- Insert Material [CQZG]
- Rubber Single Mating End
- Included Contact Quantity [CXCG]
- 1 Single Mating End Single Contact Grouping
- Included Contact Type [CXCL]
- Round Pin Single Mating End Single Contact Grouping
Similar Supply Items to 5935-00-629-9276
Freight Information 5935-00-629-9276
5935-00-629-9276 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061680. A Sub NMFC of Z. It has a NMFC Description of ELEC WIRING PLUGS ETC. 5935-00-629-9276 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34570 which rates the freight between FCL and LCL. 5935-00-629-9276 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 723 for ocean manifesting and military sealift. 5935-00-629-9276 is not classified as a special type of cargo when transported by water. 5935-00-629-9276 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5935-00-629-9276
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- 0.25 lb or less, one dimension 2" or less, other dimensions less than 24"
- 85 to 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- --
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- MIL-P-130, Laminated and Creped Wrapping Paper
- No Requirement
- Not Applicable
- --
- No special marking
- MIL-P-130, Laminated and Creped Wrapping Paper
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- PPP-B-566 or PPP-B-676, Folding or Setup Box
