5935-00-548-0952

Electrical Plug Connector

5935005480952 005480952 SAE-AS50151 415-0400-014 414-3234-006 10-214618-1P MS3106A18-1P MS3106F18-1P MS3106R18-1P MS3456W28-21P MS3456W18-1P 613010 X21-559-W18-1P AN3106A18-1P AS50151 MIL-C-5015 MIL-DTL-5015 5935PL1367218

An electrical fitting with electrical contacts, constructed to be affixed to the end of a cable, conduit, coaxial line, cord or wiring for convenience in joining with other electrical connector(s) or PRINTED WIRING BOARD and is not designed to be mounted on a bulkhead, chasses, panel, PRINTED WIRING BOARD, or the like. Excludes JACK, TELEPHONE; JACK, TIP; PLUG, TELEPHONE; PLUG TIP; INSERT, ELECTRICAL CONNECTOR; CONNECTOR BODY (as modified); and SOCKET, PLUG-IN, ELECTRONIC COMPONENTS. See also LEAD ASSEMBLY, ELECTRICAL; WIRING HARNESS (as modified); and CABLE ASSEMBLY (as modified). For items without inserts, see SHELL, ELECTRICAL CONNECTOR. View more Electrical Plug Connector

Managed by United States

NSN Created on 12 Oct 1974

Data Last Changed
November 2023

NATO Update Count
76

NATO Data Quality

5935-00-548-0952 CONNECTOR,PLUG,ELECTRICAL 5935005480952 005480952 1/2 — 5935-00-548-0952 Photo 1/2

AAQL Style 9A for 5935-00-548-0952 2/2 — NSN 5935-00-548-0952 (Identification) 2/2

Marketplace 5935-00-548-0952

Need Help?
Request a Quotation from participating marketplace vendors

Subscribe to View Vendor Details...

MS3106A18-1P CONNECTOR,PLUG,ELECTRICAL 9 EA NS

Subscribe to View Vendor Details...

613010 CONNECTOR,PLUG,ELECTRICAL 4 EA NS

Subscribe to View Vendor Details...

MS3456W18-1P CONNECTOR,PLUG,ELECTRICAL 1 EA NS

Subscribe to View Vendor Details...

MS3106R18-1P CONNECTOR,PLUG,ELECTRICAL 12 EA NS

MS3456W18-1P CONNECTOR,PLUG,ELECTRICAL 1 EA NS

MS3456W28-21P CONNECTOR,PLUG,ELECTRICAL 148 EA NS

MIL-C-5015 CONNECTOR,PLUG,ELECTRICAL 117 EA NS

MIL-DTL-5015 CONNECTOR,PLUG,ELECTRICAL 172 EA NS

Subscribe to View Vendor Details...

MILC5015 CONNECTOR,PLUG,ELECTRICAL RQST NS

Subscribe to View Vendor Details...

MS3106F18-1P CONNECTOR,PLUG,ELECTRICAL 2 EA NS

Subscribe to View Vendor Details...

MS3106A18-1P CONNECTOR,PLUG,ELECTRICAL 1 EA NS

Subscribe to View Vendor Details...

MS3456W18-1P CONNECTOR,PLUG,ELECTRICAL 2 EA NS

Subscribe to View Vendor Details...

MS3106A-18-1P CONNECTOR,PLUG,ELECTRICAL 1 EA NS

MS3456W28-21P CONNECTOR,PLUG,ELECTRICAL 1 EA NS

MS3106R18-1P CONNECTOR,PLUG,ELECTRICAL 5 EA NS

Subscribe to View Vendor Details...

MS3106R18-1P CONNECTOR,PLUG,ELECTRICAL 2 EA NS

Updated Every Day

5935-00-548-0952 RQST NE

Updated Every Day

5935-00-548-0952 RQST

Updated Every Day

5935-00-548-0952 RQST NE

Restrictions 5935-00-548-0952

5935-00-548-0952 is a Electrical Plug Connector that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item does not contain a precious metal.

Import and Export 5935-00-548-0952

Schedule B: Subscribe to View Schedule B
HTS Code: Subscribe to View HTS Code

End Users 5935-00-548-0952

US Army (A918)
Effective Date:: 1 Aug 2006
Former MOE Rule:: A196
Supplementary Receivers:: AZCTCLBD; AMC 1 AMSC T IMC Z IMCACTY CD

MOE Rule:: BGX1
Effective Date:: 1 Aug 2006
Former MOE Rule:: BTX1; AMC 1 AMSC T

US Coast Guard (C911)
Effective Date:: 1 Aug 2006
Former MOE Rule:: C007; AMC 1 AMSC T

US Air Force (FXGX)
Effective Date:: 1 Aug 2006
Former MOE Rule:: FXTX; AMC 1 AMSC T IMC Z IMCACTY SX

NASA (G170)
Effective Date:: 1 Apr 1991; AMC 0 AMSC 0 AAC C

NASA (G180)
Effective Date:: 1 Apr 1991; AMC 0 AMSC 0 AAC C

NASA (G860)
Effective Date:: 1 Apr 1991; AMC 0 AMSC 0 AAC C

NASA (G940)
Effective Date:: 1 Apr 1991; AMC 0 AMSC 0 AAC B

US Marine Corps (MC49)
Effective Date:: 1 Aug 2006
Former MOE Rule:: MC13; AMC 1 AMSC T IMC Z IMCACTY PA

US Navy (N9BN)
Effective Date:: 1 Aug 2006
Former MOE Rule:: N9ND
Supplementary Collaborators:: GTKEJSJBHXHSHD
Supplementary Receivers:: JV; AMC 1 AMSC T IMC Z IMCACTY KE

MOE Rule:: S911
Effective Date:: 1 Aug 2006
Former MOE Rule:: S007; AMC 1 AMSC T IMC Z IMCACTY XN

Poland (WP01)
Effective Date:: 1 Nov 2005

Brazil (YA01)
Effective Date:: 1 Sep 2000

Spain (YB01)
Effective Date:: 1 Apr 1991

Columbia (YC01)
Effective Date:: 1 Jul 2015

Israel (YD01)
Effective Date:: 1 Sep 2016

Singapore (YJ01)
Effective Date:: 1 Apr 1991

Australia (ZA01)
Effective Date:: 1 Apr 1991

Belgium (ZB01)
Effective Date:: 1 Apr 1991

Canada (ZC01)
Effective Date:: 1 Apr 1991

New Zealand (ZE01)
Effective Date:: 1 Apr 1991

France (ZF01)
Effective Date:: 1 Apr 1996

Germany (ZG01)
Effective Date:: 1 Apr 1991

Republic of Korea (ZH01)
Effective Date:: 1 Apr 1991

Philippines (ZM01)
Effective Date:: 1 Feb 2015

Netherlands (ZN01)
Effective Date:: 1 Apr 1991

Portugal (ZP01)
Effective Date:: 1 Dec 1998

Italy (ZR01)
Effective Date:: 1 Jul 1997

Norway (ZT01)
Effective Date:: 1 Apr 1991

Greece (ZU01)
Effective Date:: 1 Aug 1995

Turkey (ZW01)
Effective Date:: 1 Nov 1998

NATO Maintenance and Supply Agency (ZX01)
Effective Date:: 1 Apr 1991

Approved Sources 5935-00-548-0952

Part Number
Manufacturer
Status
SAE-AS50151: 0U583 - Sae International (Active); Incomplete Reference; RNCC 3 RNVC 1 DAC E
MS3456W18-1P: 0U583 - Sae International (Active); Primary Buy; RNCC 3 RNVC 2 DAC E
613010: 66943 - Datron World Communications, Inc. (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 6
X21-559-W18-1P: A181N - Bae Systems Bofors Ab (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 6
AN3106A18-1P: 81350 - Joint Army-Navy Specifications (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 3
AN3106A18-1P: 81352 - Air Force-Navy Aeronautical (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 3
AN3106A18-1P: 88044 - Aeronautical Standards Group (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 3
MS3106A18-1P: 96906 - Military Standards (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC E
MS3456W18-1P: 96906 - Military Standards (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 3
X21-559-W18-1P: S3715 - Bofors Ab (Replaced); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 6
X21-559-W18-1P: S3712 - Bae Systems Bofors Ab (Replaced); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 6
MS3456W18-1P: 81343 - Society Of Automotive Engineers Inc (Replaced); Canceled/Obsolete; RNCC 5 RNVC 9 DAC E
AS50151: 81343 - Society Of Automotive Engineers Inc (Replaced); Canceled/Obsolete; RNCC 5 RNVC 9 DAC E
MIL-C-5015: 81349 - Military Specifications (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 3
AS50151: 0U583 - Sae International (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC E
MIL-DTL-5015: 81349 - Military Specifications (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC E
5935PL1367218: 9009H - Jednolity Indeks Materialowy - (Active); NATO Reference; RNCC 6 RNVC 9 DAC 9
415-0400-014: 94756 - The Boeing Company (Active); Advisory Reference; RNCC C RNVC 1 DAC 5
414-3234-006: 94756 - The Boeing Company (Active); Advisory Reference; RNCC C RNVC 1 DAC 5
10-214618-1P: 80064 - Naval Ship Systems Command (Active); Advisory Reference; RNCC C RNVC 1 DAC 6
MS3106A18-1P: 81349 - Military Specifications (Active); Advisory Reference; RNCC C RNVC 1 DAC 6
MS3106F18-1P: 96906 - Military Standards (Active); Advisory Reference; RNCC C RNVC 1 DAC 6
MS3106R18-1P: 96906 - Military Standards (Active); Advisory Reference; RNCC C RNVC 1 DAC 6
MS3456W28-21P: 96906 - Military Standards (Active); Advisory Reference; RNCC C RNVC 1 DAC 6

Datasheet 5935-00-548-0952

Characteristic
Specifications
FIIG: A039B0
Connector Locking Method [AFRV]: Internally Threaded Coupling Ring
Contact Maximum Ac Voltage Rating In Volts [AFRD]: 200.0 Single Mating End 2Nd Contact Grouping
Contact Maximum Ac Voltage Rating In Volts [AFRD]: 500.0 Single Mating End 1St Contact Grouping
Contact Removability [AFQZ]: Removable Single Mating End All Contact Groupings
Contact Maximum Dc Voltage Rating In Volts [AFRE]: 250.0 Single Mating End 2Nd Contact Grouping
Contact Maximum Dc Voltage Rating In Volts [AFRE]: 700.0 Single Mating End 1St Contact Grouping
Contact Position Arrangement Style [AFQX]: 18-1 Single Mating End
Environmental Protection [ADZC]: Moisture Resistant And Vibration Resistant And Salt Water Resistant
Body Style [AAQL]: Straight Shape, Internal Coupling W/Backshell
Mating End Quantity [AFQW]: 1
Nominal Thread Length [AKMG]: 0.290 Inches And 0.625 Inches
Nominal Thread Size [CQJX]: 1.062 Inches And 1.125 Inches
Included Contact Quantity [CXCG]: 4 Single Mating End 1St Contact Grouping
Included Contact Quantity [CXCG]: 6 Single Mating End 2Nd Contact Grouping
Included Contact Type [CXCL]: Round Pin Single Mating End All Contact Groupings
Insert Material [CQZG]: Plastic Silicone Single Mating End
Insert Position In Deg [AFRP]: 0.0
Polarization Method [AFRN]: Keyway Or Multiple Keyway
Shell Material [CSPT]: Aluminum Alloy
Shell Surface Treatment Document And Classification [CTBC]: Qq-P-416,Ty 2,Cl 3 Fed Spec Single Treatment Response
Shell Surface Treatment [CSWM]: Cadmium
Shell Type [AFRT]: Solid
Overall Diameter [ADAV]: 1.344 Inches Maximum
Overall Length [ABHP]: 2.125 Inches Maximum
Special Features [FEAT]: In Order To Complete The Connector Assembly,The User Must Obtain/Provide The Backshell. Standard Versions May Be Ordered As Nsn 5935-01-177-9556,P/N M85049/52-1-18W For The Straight Style,Or Nsn 5935-01-174-3671,P/N M85049/51-1-18W For The Right Angle Style.
Specification/Standard Data [ZZZK]: 81349-Mil-C-5015 Government Specification
Terminal Location [CQTM]: Back Single Mating End All Contact Groupings
Terminal Type [CSCF]: Crimp Single Mating End All Contact Groupings
Test Data Document [TEST]: 81349-Mil-C-5015 Specification (Includes Engineering Type Bulletins, Brochures,Etc., That Reflect Specification Type Data In Specification Format; Excludes Commercial Catalogs, Industry Directories, And Similar Trade Publications, Reflecting General Type Data On Certain Environmental And Performance Requirements And Test Conditions That Are Shown As "Typical", "Average", "Nominal", Etc.).
Thread Class [AAJD]: 2A And 2B
Thread Direction [AAJF]: Right-Hand And Right-Hand
Thread Series Designator [THSD]: Unef And Unef
Threaded Device Type [AFQR]: Back Shell And Coupling Facility

Weapon Systems (WSDC) 5935-00-548-0952

Subscribe
View WSDC

Subscribe to View Weapon System Codes...

Subscribe
View Data

DLA Procurement Analysis 5935-00-548-0952

Last Stock Position:: 322 In Stock
DLA Administrative Lead Time:: Subscribe
DLA Production Lead Time:: Subscribe

Subscribe to View DLA Inventory and Forecast...

Management Data 5935-00-548-0952

Subscribe
View Prices

Effective Date: Organization; Unit of Issue; Unit Price; Qty Unit Pack
Oct 2022: Department of the Navy (DN); EA; Subscribe; 1
Oct 2021: US Marine Corps (DM); EA; Subscribe; 1
Oct 2020: Defense Logistics Agency (DS); EA; Subscribe; 1
Mar 2020: Department of the Air Force (DF); EA; Subscribe; 1

MOE: USC; Code; Statement; Order of Use; Jump To Code; Qty Per Assy; UOM; Technical Document; Quantative Expression
US Marine Corps (DM): M; 0; Reversal Of Phrase Code Z 5935-00-642-2653

Army

Materiel Category and Inventory Manager:

Q: Electronics Materiel (DLA/GSA Items)

Appropriation and Budget Activity:

2: Stock Fund Secondary Items

Management Inventory Segment:

2: Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.

Weapons System / End Item / Homogeneous Group:

00: DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item

Accounting Requirements:

X: Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.

Air Force

Fund:

SF: Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point

Budget:

9: 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors

Aggregation Code:

EH: ELECTRONIC COMPONENTS

Price Validation Code:

V: The current standard price has been validated.
The item has been analyzed in conjunction with the Zero Overpricing Program and is in the accepted price range.
The item was procured under open competition and under the competitive arena the price is considered fair and reasonable.
ZOP or Standard price challenges are permissible but must be supported by adequate justification.

Expendability Recoverability Repairability:

N: Expendable. Condemn at User. Stock Fund (except Munitions).

Navy

Cognizance:

9B: Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg

Special Material Content:

9: Non-Hazardous or Non-Sensitive Item

Marine Corps

Stores Account:

1: Stock Fund Account Item

Combat Essentiality:

2: Non-Critical Repair Part

Echelon Management:

B2

Material Identification:

B: Consumable Repair Parts

Operational Test:

: No Special Procedures

Similar Supply Items to 5935-00-548-0952

Freight Information 5935-00-548-0952

5935-00-548-0952 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061680. A Sub NMFC of Z. It has a NMFC Description of ELEC WIRING PLUGS ETC. 5935-00-548-0952 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34570 which rates the freight between FCL and LCL. 5935-00-548-0952 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 658 for ocean manifesting and military sealift. 5935-00-548-0952 is not classified as a special type of cargo when transported by water. 5935-00-548-0952 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.

Packaging Data 5935-00-548-0952

Responsible Activity
Packaging Data Source: Primary Inventory Control Activity (PICA); --

Item Pack Level (Unpackaged)

Item Size
Item Weight
Characteristics
Weight/Dimensions Category
Fragility
Item Preservation: --; --; --; Over 10lb; Less than 85G; No Requirement

Unit Pack Level (Packaged)

Quantity per Pack
Unit Size
Unit Weight
Unit Cube
Preservation Method
Cleaning/Drying: 1; --; --; --; --; Any Suitable Process

Preservation Material
Wrapping Material
Cushioning/Dunnage
Cushioning Thickness
Container
Special Marking: No Requirement; MIL-DTL-17667, Neutral Wrapping Paper; No Requirement; Not Applicable; --; No special marking

Intermediate Pack Level

Quantity of Unit Packs
Container: PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box

Procurement History 5935-00-548-0952 3 Records

Subscribe
View Prices

Contract: Date; CAGE; Quantity; Net Price; Std Price
SPE7M123P6695: 27 Jun 2023; Subscribe; 73; Subscribe; Subscribe
SPE7M123P6695P00001: 27 Jun 2023; Subscribe; 84; Subscribe; Subscribe
SPM7M113V9262: 25 May 2013; Subscribe; 218; Subscribe; Subscribe

Contracting Technical Data File (CTDF) 5935-00-548-0952 October 2021

Criticality and Quality

Critical Item Code:: X
Flight Safety:
Life Support:
Certified Samples:
Serialization:
First Article Test (FAT):
Certificate of Quality Compliance:
Production Lot Testing:
Special Testing:
Qualified Products List (QPL):

Commercial Properties

Government Furnished Material:
Government Furnished Tooling:
Government Furnished Property:
Price Evaluation Code:
Diminshing Manufacturing Sources:
Warranty:
Commerical Off The Shelf (COTS):
End Item Application:
Auctioning Candidate:
Source of Procurement:
Contract Option:

Restrictions

Boeing Rights Guard:
Export Controlled:
Controlled Technical Data Package (TDP):
Restricted Technical Data Package (TDP):
Contains Classified Material
Weapons System Indicator Code (WSIC):: F

Packaging Requirements

Packaging Determination Table:
Packaging Review Code:: N
Special Packaging Instruction Number (SPIN):
Special Packaging Instruction Number Revision:
Special Packaging Instruction Number Date:
Pallet Reference Number Required:

Subscribe
View CTDF

Subscribe to View CTDF Details...

Marketplace 5935-00-548-0952

Related Documents 5935-00-548-0952 5+ Documents (More...)

Restrictions 5935-00-548-0952

Import and Export 5935-00-548-0952

End Users 5935-00-548-0952

Approved Sources 5935-00-548-0952

Datasheet 5935-00-548-0952

Weapon Systems (WSDC) 5935-00-548-0952

DLA Procurement Analysis 5935-00-548-0952

Management Data 5935-00-548-0952

Army

Air Force

Navy

Marine Corps

Similar Supply Items to 5935-00-548-0952

Freight Information 5935-00-548-0952

Packaging Data 5935-00-548-0952

Item Pack Level (Unpackaged)

Unit Pack Level (Packaged)

Intermediate Pack Level

Procurement History 5935-00-548-0952 3 Records

Contracting Technical Data File (CTDF) 5935-00-548-0952 October 2021

Criticality and Quality

Commercial Properties

Restrictions

Packaging Requirements
