5935-00-325-4475
Electrical Receptacle Connector Body
5935003254475 003254475 MS20RMIC SMA731330-3 MS20RM1C
The main or principal part of a CONNECTOR, RECEPTACLE, ELECTRICAL which includes insert(s) designed to accommodate but does not include removable contacts. It may have a hood or shell, a jackscrew and jacksocket, or other means for polarizing and aligning. It is designed to be mounted on a bulkhead, chassis, panel, wall, or the like. Excludes CONNECTOR BODY, MODULAR RECEPTACLE, ELECTRICAL. For items without inserts, see SHELL, ELECTRICAL CONNECTOR. View more Electrical Receptacle Connector Body
May 2023
7
Marketplace 5935-00-325-4475
Request a Quotation from participating marketplace vendors
Related Documents 5935-00-325-4475 4+ Documents (More...)
RQST NE Updated Every Day 5935-00-325-4475 RQST Updated Every Day 5935-00-325-4475 RQST NE Related
Documents 5935-00-325-4475 1+ Documents ( More... ) https//www.nsnlookup.com /fsg-59/fsc-5935/us 5935
Restrictions 5935-00-325-4475
5935-00-325-4475 is a Electrical Receptacle Connector Body that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
Import and Export 5935-00-325-4475
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5935-00-325-4475
- US Navy (N9BN)
- Effective Date:
- 1 Nov 2005
- Former MOE Rule:
- N9ND
- Supplementary Collaborators:
- HD
- Italy (ZR01)
- Effective Date:
- 1 Jul 1997
Approved Sources 5935-00-325-4475
- Part Number
- Manufacturer
- Status
- SMA731330-3
- Manufacturer
- 80063 - Us Army Communications & Electronics (Active)
- Primary Buy
- Primary Buy
- MS20RM1C
- 09922 - Souriau Usa, Inc. (Active)
- Secondary Buy
- Secondary Buy
- MS20RMIC
- 09922 - Souriau Usa, Inc. (Active)
- Advisory Reference
- Advisory Reference
Datasheet 5935-00-325-4475
- Characteristic
- Specifications
- FIIG
- Specifications
- A039B0
- Connector Locking Method [AFRV]
- Latch
- Contact Position Arrangement Style [AFQX]
- 20 20-20 Single Mating End
- Distance Between Mounting Facility Centers [AEJN]
- 1.250 Inches Nominal
- Environmental Protection [ADZC]
- Moisture Resistant And Shock Resistant And Vibration Resistant And Salt Water Resistant
- Body Style [AAQL]
- Straight Shape
- Mating End Quantity [AFQW]
- 1
- Nominal Thread Size [CQJX]
- 0.112 Inches
- Insert Material Document And Classification [CTKL]
- Mil-M-14 Mil Spec Single Material Response Single Mating End
- Insert Material [CQZG]
- Plastic Phenolic Single Mating End
- Polarization Method [AFRN]
- Guide Pin/Socket
- Overall Length [ABHP]
- 1.770 Inches Nominal
- Overall Width [ABMK]
- 0.460 Inches Nominal
- Thread Direction [AAJF]
- Right-Hand
- Thread Class [AAJD]
- 2A
- Thread Series Designator [THSD]
- Unc
- Threaded Device Type [AFQR]
- Mounting Stud
