5935-00-242-3999
Plug-In Electronic Components Socket
5935002423999 002423999 09P237595-21-11
An item designed to electrically connect and mechanically position the base of an item having plug-in-type contacts, and to facilitate replacement of the item accommodated. It includes sockets which accommodate the contacts of capacitors, coils, crystals, electron tubes, relays, semiconductor devices and vibrators. Excludes sockets or receptacles designed to accommodate plug-in component circuit boards (printed circuit boards) and electronic modules or sub-assemblies. Also excludes heat-dissipating (not heat-sinks) sockets for mounting "power transistors". View more Plug-In Electronic Components Socket
May 2023
3
Marketplace 5935-00-242-3999
Request a Quotation from participating marketplace vendors
Updated Every 15 Minutes
Updated Every Day Updated Every Day
Updated Every Day Related Documents 5935-00-242-3999 5+ Documents (More...)
NE FedMall Updated Every Day 5935-00-242-3999 RQST NE Updated Every Day 5935-00-242-3999 RQST Updated
Every Day 5935-00-242-3999 RQST NE Related Documents 5935-00-242-3999 1+ Documents ( More... ) https
Restrictions 5935-00-242-3999
5935-00-242-3999 is a Plug-In Electronic Components Socket that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item does not contain a precious metal.
Import and Export 5935-00-242-3999
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5935-00-242-3999
- US Navy (N9BN)
- Effective Date:
- 1 Nov 2005
- Former MOE Rule:
- N9ND
- Supplementary Collaborators:
- KE
Approved Sources 5935-00-242-3999
- Part Number
- Manufacturer
- Status
- 09P237595-21-11
- Manufacturer
- 98738 - Herley Chicago (Active)
- Primary Buy
- Primary Buy
Datasheet 5935-00-242-3999
- Characteristic
- Specifications
- FIIG
- Specifications
- A02300
- Accommodated Contact Quantity [AFRL]
- 4
- Body Material [AAFZ]
- Plastic
- Body Mounting Hole Accommodation Diameter [ADAL]
- 1.172 Inches Nominal
- Body Style [AAQL]
- Top Mount W/Center Thru Hole
- Mounting Hole Style [AEVB]
- Round, Body
- Mounting Type For Which Designed [BCNX]
- Chassis
- Projection Length Below Mounting Surface [AKXC]
- 0.708 Inches Nominal
- Overall Diameter [ADAV]
- 1.250 Inches Nominal
- Overall Height [ABKW]
- 0.843 Inches Nominal
- Terminal Type And Quantity [TTQY]
- 4 Tab, Solder Lug
