5935-00-225-8952
Electrical Plug Connector Body
5935002258952 002258952 REM175M2SLFS80 REM1175M2SLFS80 659C724PC04
The main or principal part of a CONNECTOR, PLUG, ELECTRICAL which includes insert(s) designed to accommodate but does not include removable contacts. It may have a hood or shell, a jackscrew and jacksocket, or other means for polarizing and aligning. It is not designed to be mounted on a bulkhead, chassis, panel, wall, or the like. Excludes CONNECTOR BODY, MODULAR PLUG, ELECTRICAL. For items without insert(s), see SHELL, ELECTRICAL CONNECTOR. View more Electrical Plug Connector Body
November 2023
10
Marketplace 5935-00-225-8952
Request a Quotation from participating marketplace vendors
Related Documents 5935-00-225-8952 3+ Documents (More...)
Photo 1/2 NSN 5935-00-225-8952 (Identification) 2/2 - - 1.
Minutes 5935-00-225-8952 BUY NE FedMall Updated Every Day 5935-00-225-8952 RQST NE Updated Every Day
Restrictions 5935-00-225-8952
5935-00-225-8952 is a Electrical Plug Connector Body that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
Import and Export 5935-00-225-8952
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5935-00-225-8952
- US Navy (N9BN)
- Effective Date:
- 1 Nov 2005
- Former MOE Rule:
- NIND
- Supplementary Collaborators:
- GTJBHD
Approved Sources 5935-00-225-8952
- Part Number
- Manufacturer
- Status
- REM175M2SLFS80
- Manufacturer
- 97954 - U S Components Inc (Replaced)
- Original Design
- Original Design
- REM1175M2SLFS80
- 97954 - U S Components Inc (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- 659C724PC04
- 88725 - Westinghouse Electric Corp General (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5935-00-225-8952
- Characteristic
- Specifications
- FIIG
- Specifications
- A039B0
- Body Style [AAQL]
- Straight Shape W/Screw Locks
- Connector Locking Method [AFRV]
- Jackscrew-Socket
- Contact Position Arrangement Style [AFQX]
- 75 Single Mating End
- Mating End Quantity [AFQW]
- 1
- Nominal Thread Size [CQJX]
- 0.138 Inches And 0.138 Inches
- Insert Material [CQZG]
- Plastic Diallyl Phthalate Single Mating End
- Insert Material Document And Classification [CTKL]
- Mil-M-19833,Type Gdi-30F Mil Spec Single Material Response Single Mating End
- Polarization Method [AFRN]
- Jackscrew
- Overall Height [ABKW]
- 0.844 Inches Nominal
- Overall Length [ABHP]
- 1.453 Inches Nominal
- Overall Width [ABMK]
- 2.719 Inches Nominal
- Thread Class [AAJD]
- 2A And 2B
- Thread Direction [AAJF]
- Right-Hand And Right-Hand
- Thread Series Designator [THSD]
- Unc And Unc
- Threaded Device Type [AFQR]
- Coupling Facility
Weapon Systems (WSDC) 5935-00-225-8952
DLA Procurement Analysis 5935-00-225-8952
- Last Stock Position:
- 6 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 5935-00-225-8952
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5935-00-225-8952
Freight Information 5935-00-225-8952
5935-00-225-8952 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061680. A Sub NMFC of Z. It has a NMFC Description of ELEC WIRING PLUGS ETC. 5935-00-225-8952 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34570 which rates the freight between FCL and LCL. 5935-00-225-8952 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 658 for ocean manifesting and military sealift. 5935-00-225-8952 is not classified as a special type of cargo when transported by water. 5935-00-225-8952 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5935-00-225-8952
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- 0.25 lb or less, one dimension 2" or less, other dimensions less than 24"
- 85 to 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- MIL-DTL-17667, Neutral Wrapping Paper
- PPP-C-795, Cellular Plastic Film Cushioning; or A-A-3129, Open Cell Plastic Cushioning; or PPP-C-1797, Polypropylene Foam Cushioning; or A-A-59136, Polyethylene Foam Cushioning
- --
- --
- No special marking
- MIL-DTL-17667, Neutral Wrapping Paper
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- PPP-B-566 or PPP-B-676, Folding or Setup Box
Contracting Technical Data File (CTDF) 5935-00-225-8952 October 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- F
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
