5935-00-222-7811
Electrical Plug Connector
5935002227811 002227811 MILC5015 AN3106A22-14PW MS3106A22-14PW
An electrical fitting with electrical contacts, constructed to be affixed to the end of a cable, conduit, coaxial line, cord or wiring for convenience in joining with other electrical connector(s) or PRINTED WIRING BOARD and is not designed to be mounted on a bulkhead, chasses, panel, PRINTED WIRING BOARD, or the like. Excludes JACK, TELEPHONE; JACK, TIP; PLUG, TELEPHONE; PLUG TIP; INSERT, ELECTRICAL CONNECTOR; CONNECTOR BODY (as modified); and SOCKET, PLUG-IN, ELECTRONIC COMPONENTS. See also LEAD ASSEMBLY, ELECTRICAL; WIRING HARNESS (as modified); and CABLE ASSEMBLY (as modified). For items without inserts, see SHELL, ELECTRICAL CONNECTOR. View more Electrical Plug Connector
May 2023
24
Marketplace 5935-00-222-7811
Request a Quotation from participating marketplace vendors
Updated Every Day Updated Every Day
Updated Every Day Related Documents 5935-00-222-7811 5+ Documents (More...)
Photo 1/6 5935-00-222-7811 Photo 2/6 5935-00-222-7811 Photo 3/6 5935-00-222-7811 Photo 4/6 5935
... ) https//www.nsnlookup.com /fsg-59/fsc-5935/us 5935-00-222-7811 Electrical Plug Connector 5935002227811
-424-0524Electrical Plug Connector5935214240524 https//www.nsnlookup.com /fsg-59/fsc-5935/us 5935-00-222-7811
Electrical Plug Connector 5935002227811 222-7811 Electrical Plug Connector 5935002227811 https/
Restrictions 5935-00-222-7811
5935-00-222-7811 is a Electrical Plug Connector that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item contains a combination of two or more precious metals.
Import and Export 5935-00-222-7811
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5935-00-222-7811
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Australia (ZA01)
- Effective Date:
- 1 Apr 1991
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
- Germany (ZG01)
- Effective Date:
- 1 Apr 1991
- Italy (ZR01)
- Effective Date:
- 1 Jul 1997
Approved Sources 5935-00-222-7811
- Part Number
- Manufacturer
- Status
- MS3106A22-14PW
- Manufacturer
- 96906 - Military Standards (Active)
- Definitive Standard
- Definitive Standard
- MILC5015
- 81349 - Military Specifications (Active)
- Incomplete Standard
- Incomplete Standard
- AN3106A22-14PW
- 88044 - Aeronautical Standards Group (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
Datasheet 5935-00-222-7811
- Characteristic
- Specifications
- FIIG
- Specifications
- A039B0
- Connector Locking Method [AFRV]
- Internally Threaded Coupling Ring
- Contact Maximum Ac Voltage Rating In Volts [AFRD]
- 500.0 Single Mating End Single Contact Grouping
- Contact Maximum Current Rating In Amps [AFRC]
- 22.0 Single Mating End Single Contact Grouping
- Contact Removability [AFQZ]
- Nonremovable Single Mating End Single Contact Grouping
- Contact Maximum Dc Voltage Rating In Volts [AFRE]
- 700.0 Single Mating End Single Contact Grouping
- Contact Position Arrangement Style [AFQX]
- 22-14 Single Mating End
- Contact Surface Treatment [CQYH]
- Gold Single Mating End Single Contact Grouping And Silver Single Mating End Single Contact Grouping
- Environmental Protection [ADZC]
- Moisture Resistant And Salt Water Resistant And Vibration Resistant
- Body Style [AAQL]
- Straight Shape, Internal Coupling
- Mating End Quantity [AFQW]
- 1
- Nominal Thread Length [AKMG]
- 0.594 Inches
- Nominal Thread Size [CQJX]
- 1.188 Inches And 1.375 Inches
- Included Contact Quantity [CXCG]
- 19 Single Mating End Single Contact Grouping
- Included Contact Type [CXCL]
- Round Pin Single Mating End Single Contact Grouping
- Insert Position In Deg [AFRP]
- 80.0
- Polarization Method [AFRN]
- Key, Multiple Key Groove
- Precious Material And Location [PMLC]
- Contact Surfaces Gold And Contact Surfaces Silver
- Precious Material And Weight [PMWT]
- 0.019 Gold Grains, Troy And 0.019 Silver Grains, Troy
- Precious Material [PRMT]
- Gold And Silver
- Shell Surface Treatment Document And Classification [CTBC]
- Qq-P-416,Ty 2,Cl 3 Fed Spec Single Treatment Response
- Shell Surface Treatment [CSWM]
- Cadmium
- Shell Type [AFRT]
- Solid
- Shell Material [CSPT]
- Aluminum Alloy
- Overall Diameter [ADAV]
- 1.594 Inches Maximum
- Overall Length [ABHP]
- 2.188 Inches Maximum
- Specification/Standard Data [ZZZK]
- 81349-Mil-C-5015 Government Specification
- Terminal Location [CQTM]
- Back Single Mating End Single Contact Grouping
- Terminal Type [CSCF]
- Solder Well Single Mating End Single Contact Grouping
- Test Data Document [TEST]
- 81349-Mil-C-5015 Specification (Includes Engineering Type Bulletins, Brochures,Etc., That Reflect Specification Type Data In Specification Format; Excludes Commercial Catalogs, Industry Directories, And Similar Trade Publications, Reflecting General Type Data On Certain Environmental And Performance Requirements And Test Conditions That Are Shown As "Typical", "Average", "Nominal", Etc.).
- Thread Class [AAJD]
- 2A And 2B
- Thread Direction [AAJF]
- Right-Hand And Right-Hand
- Thread Series Designator [THSD]
- Unef And Unef
- Threaded Device Type [AFQR]
- Back Shell And Coupling Facility
DLA Procurement Analysis 5935-00-222-7811
Management Data 5935-00-222-7811
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Sep 2007
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
- Jun 2007
- Defense Logistics Agency (DS)
- EA
- Subscribe
- 1
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- Department of the Air Force (DF)
- F
- N
- Disposal
- N
Air Force
- Fund:
- SF
- Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point
- Budget:
- 9
- 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors
- Aggregation Code:
- EH
- ELECTRONIC COMPONENTS
- Price Validation Code:
- N
- The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
The price has not been analyzed or reviewed for accuracy.
ZOP or Standard price challenges are permissible but must be supported with adequate justification. However, if coded for Local Purchase (LP) or Fabrication/Manufacture as indicated with an (LM) Acquisition Advice Code of “L” or “F”, then it must be evaluated locally where purchased or fabricated.
- Expendability
Recoverability
Repairability: - N
- Expendable. Condemn at User. Stock Fund (except Munitions).
Similar Supply Items to 5935-00-222-7811
Freight Information 5935-00-222-7811
5935-00-222-7811 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061680. A Sub NMFC of Z. It has a NMFC Description of ELEC WIRING PLUGS ETC. 5935-00-222-7811 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34570 which rates the freight between FCL and LCL. 5935-00-222-7811 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 723 for ocean manifesting and military sealift. 5935-00-222-7811 is not classified as a special type of cargo when transported by water. 5935-00-222-7811 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5935-00-222-7811
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- 0.25 lb or less, one dimension 2" or less, other dimensions less than 24"
- 85 to 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- --
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- --
- --
- --
- --
- --
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- Any Suitable Fiber Box
