5935-00-201-0894
Electrical Plug Connector Body
5935002010894 002010894 MS42PM124S5
The main or principal part of a CONNECTOR, PLUG, ELECTRICAL which includes insert(s) designed to accommodate but does not include removable contacts. It may have a hood or shell, a jackscrew and jacksocket, or other means for polarizing and aligning. It is not designed to be mounted on a bulkhead, chassis, panel, wall, or the like. Excludes CONNECTOR BODY, MODULAR PLUG, ELECTRICAL. For items without insert(s), see SHELL, ELECTRICAL CONNECTOR. View more Electrical Plug Connector Body
May 2023
5
Marketplace 5935-00-201-0894
Request a Quotation from participating marketplace vendors
Related Documents 5935-00-201-0894 4+ Documents (More...)
5935-00-201-0894 1+ Documents ( More... ) https//www.nsnlookup.com /fsg-59/fsc-5935/us 5935-00-201-0894
Electrical Plug Connector Body 5935002010894 5935-00-201-0894 1+ Documents ( More... ) https//www.nsnlookup.com
Restrictions 5935-00-201-0894
5935-00-201-0894 is a Electrical Plug Connector Body that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item contains gold.
Import and Export 5935-00-201-0894
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5935-00-201-0894
- US Navy (N9BN)
- Effective Date:
- 1 Nov 2005
- Former MOE Rule:
- N9ND
- Supplementary Collaborators:
- KE
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
Approved Sources 5935-00-201-0894
- Part Number
- Manufacturer
- Status
- MS42PM124S5
- Manufacturer
- 09922 - Souriau Usa, Inc. (Active)
- Primary Buy
- Primary Buy
Datasheet 5935-00-201-0894
- Characteristic
- Specifications
- FIIG
- Specifications
- A039B0
- Body Style [AAQL]
- Hood, Top Opening W/Clamp
- Connector Locking Method [AFRV]
- Jackscrew-Socket
- Connector Cable Strain Relief Method [AFRW]
- Cable Clamp
- Contact Position Arrangement Style [AFQX]
- 42 Single Mating End
- Environmental Protection [ADZC]
- Moisture Resistant And Salt Water Resistant And Vibration Resistant
- Mating End Quantity [AFQW]
- 1
- Nominal Thread Size [CQJX]
- 0.138 Inches And 0.138 Inches
- Insert Material Document And Classification [CTKL]
- Mil-M-14,Ty Mdg Mil Spec Single Material Response Single Mating End
- Insert Material [CQZG]
- Plastic Diallyl Phthalate Single Mating End
- Polarization Method [AFRN]
- Jackscrew
- Precious Material And Location [PMLC]
- Shell Surface Gold
- Precious Material And Weight [PMWT]
- 0.100 Gold Grains, Troy
- Precious Material [PRMT]
- Gold
- Shell Surface Treatment [CSWM]
- Chromate And Gold
- Shell Type [AFRT]
- Hood, Top Opening
- Shell Material [CSPT]
- Aluminum Alloy
- Shell Surface Treatment Document And Classification [CTBC]
- Mil-C-5541 Mil Spec 1St Treatment Response
- Overall Height [ABKW]
- 3.330 Inches Nominal
- Overall Width [ABMK]
- 0.750 Inches Nominal
- Special Features [FEAT]
- Shell Polarized At Position 5
- Thread Class [AAJD]
- 2A And 2B
- Thread Direction [AAJF]
- Right-Hand And Right-Hand
- Thread Series Designator [THSD]
- Unc And Unc
- Threaded Device Type [AFQR]
- Coupling Facility
DLA Procurement Analysis 5935-00-201-0894
Management Data 5935-00-201-0894
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
- Special Material Content:
- 9
- Non-Hazardous or Non-Sensitive Item
Similar Supply Items to 5935-00-201-0894
Freight Information 5935-00-201-0894
5935-00-201-0894 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061680. A Sub NMFC of Z. It has a NMFC Description of ELEC WIRING PLUGS ETC. 5935-00-201-0894 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34570 which rates the freight between FCL and LCL. 5935-00-201-0894 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 658 for ocean manifesting and military sealift. 5935-00-201-0894 is not classified as a special type of cargo when transported by water. 5935-00-201-0894 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5935-00-201-0894
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Electrical Instrument
- Over 10lb
- Less than 85G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- --
- No Requirement
- Not Applicable
- Bags made of material conforming to MIL-P-130, MIL-DTL-17667, MIL-PRF-121, or any material authorized by MIL-DTL-117. Closure may be by staples, tape, adhesive or heat seal
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
Contracting Technical Data File (CTDF) 5935-00-201-0894 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
