5935-00-140-0073
Connector Adapter
5935001400073 001400073 MIL-DTL-26482 PTB-16-26PSY MS3119E16-26Y MILC26482
An adapter with electrical contacts which provides facilities for joining two or more electrical connectors, whose design or function will not normally warrant their junction.It is not designed for permanent attachment to a cable, cord, coaxial line, or wire.The physical shape of an electrical connector should not be the determining factor of its name.Tee, angle, straight, and Y-shaped adapters are all ADAPTER, CONNECTOR.Excludes ADAPTER, CONNECTOR TO LAMPBASE; ADAPTER, LAMPHOLDER TO CONNECTOR; ADAPTER (1), CABLE CLAMP TO CONNECTOR; and ADAPTER, LAMPHOLDER.For items designed as a mechanical connection between an electrical conduit and an electrical connector, see ADAPTER (1), ELECTRICAL CONDUIT. View more Connector Adapter
November 2023
8
Marketplace 5935-00-140-0073
Request a Quotation from participating marketplace vendors
Updated Every Day Updated Every Day
Updated Every Day Related Documents 5935-00-140-0073 5+ Documents (More...)
Photo 1/7 5935-00-140-0073 Photo 2/7 5935-00-140-0073 Photo 3/7 5935-00-140-0073 Photo 4/7 5935
-00-140-0073 Photo 5/7 5935-00-140-0073 Photo 6/7 NSN 5935-00-140-0073 (Identification) 7/7 - - - - -
MILC26482 ADAPTER,CONNECTOR 2 EA NS Request Quotation Subscribe to View Vendor Details...
MILC26482 ADAPTER,CONNECTOR 3 EA NS Request Quotation MIL-C-26482 ADAPTER,CONNECTOR 8 EA NS Request Quotation
Restrictions 5935-00-140-0073
5935-00-140-0073 is a Connector Adapter that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item contains gold.
Import and Export 5935-00-140-0073
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5935-00-140-0073
- US Army (A918)
- Effective Date:
- 1 Nov 2005
- Former MOE Rule:
- A196
- Supplementary Receivers:
- BD
- US Air Force (FXGX)
- Effective Date:
- 1 Nov 2005
- Former MOE Rule:
- FXTX
- US Marine Corps (MC49)
- Effective Date:
- 1 Dec 2015
- Israel (YD01)
- Effective Date:
- 1 Sep 2016
- Greece (ZU01)
- Effective Date:
- 1 Mar 2008
- NATO Maintenance and Supply Agency (ZX01)
- Effective Date:
- 1 Apr 1991
Approved Sources 5935-00-140-0073
- Part Number
- Manufacturer
- Status
- MS3119E16-26Y
- Manufacturer
- 96906 - Military Standards (Active)
- Definitive Standard
- Definitive Standard
- MIL-DTL-26482
- 81349 - Military Specifications (Active)
- Incomplete Standard
- Incomplete Standard
- MILC26482
- 81349 - Military Specifications (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- PTB-16-26PSY
- 77820 - Amphenol Corp (Active)
- Advisory Reference
- Advisory Reference
Datasheet 5935-00-140-0073
- Characteristic
- Specifications
- FIIG
- Specifications
- A039B0
- Distance From Mounting Shoulder To Front Face [AFQK]
- 0.562 Inches Minimum And 0.593 Inches Maximum
- Body Style [AAQL]
- Straight Shape W/Flange
- Center To Center Distance Between Mounting Facilities Parallel To Height [AEBW]
- 0.969 Inches Nominal
- Connector Locking Method [AFRV]
- Bayonet Pin
- Contact Maximum Ac Voltage Rating In Volts [AFRD]
- 600.0 All Mating Ends All Contact Groupings
- Contact Removability [AFQZ]
- Nonremovable All Mating Ends Single Contact Grouping
- Contact Position Arrangement Style [AFQX]
- 16-26 All Mating Ends
- Contact Surface Treatment [CQYH]
- Gold All Mating Ends All Contact Groupings
- Distance Between Centerlines Of Mounting Facilities Parallel To Body Width [AEHA]
- 0.969 Inches Nominal
- Environmental Protection [ADZC]
- Moisture Resistant And Salt Water Resistant And Vibration Resistant
- Mating End Quantity [AFQW]
- 2
- Included Contact Quantity [CXCG]
- 26 2Nd Mating End All Contact Groupings
- Included Contact Quantity [CXCG]
- 26 1St Mating End All Contact Groupings
- Included Contact Type [CXCL]
- Round Pin 1St Mating End All Contact Groupings
- Included Contact Type [CXCL]
- Round Socket 2Nd Mating End All Contact Groupings
- Insert Position In Deg [AFRP]
- 275.0 And 85.0
- Polarization Method [AFRN]
- Key, Multiple Key Groove
- Precious Material And Location [PMLC]
- Contact Surfaces Gold
- Precious Material And Weight [PMWT]
- 0.052 Gold Grains, Troy
- Precious Material [PRMT]
- Gold
- Shell Material [CSPT]
- Aluminum Alloy
- Shell Surface Treatment [CSWM]
- Cadmium
- Shell Type [AFRT]
- Solid
- Overall Height [ABKW]
- 1.234 Inches Maximum
- Overall Length [ABHP]
- 1.125 Inches Maximum
- Overall Width [ABMK]
- 1.234 Inches Maximum
- Unthreaded Mounting Hole Diameter [AEBV]
- 0.115 Inches Minimum And 0.125 Inches Maximum
- Specification/Standard Data [ZZZK]
- 81349-Mil-C-26482 Government Specification
- Test Data Document [TEST]
- 81349-Mil-C-26482 Specification (Includes Engineering Type Bulletins, Brochures,Etc., That Reflect Specification Type Data In Specification Format; Excludes Commercial Catalogs, Industry Directories, And Similar Trade Publications, Reflecting General Type Data On Certain Environmental And Performance Requirements And Test Conditions That Are Shown As "Typical", "Average", "Nominal", Etc.).
Weapon Systems (WSDC) 5935-00-140-0073
DLA Procurement Analysis 5935-00-140-0073
- Last Stock Position:
- 28 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 5935-00-140-0073
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Oct 2022
- US Marine Corps (DM)
- EA
- Subscribe
- 1
- EA
- Oct 2021
- Department of the Army (DA)
- EA
- Subscribe
- 1
- EA
- Apr 2021
- Defense Logistics Agency (DS)
- EA
- Subscribe
- 1
- EA
- Feb 2021
- US Marine Corps (DM)
- EA
- Subscribe
- 1
- EA
- Mar 2020
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
Army
- Materiel Category and Inventory Manager:
- Q
- Electronics Materiel (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 2
- Non-Critical Repair Part
- Echelon Management:
- B2
- Operational Test:
- No Special Procedures
- Physical Category:
- 1
- Bin
Similar Supply Items to 5935-00-140-0073
Freight Information 5935-00-140-0073
5935-00-140-0073 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061680. A Sub NMFC of Z. It has a NMFC Description of ELEC WIRING PLUGS ETC. 5935-00-140-0073 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34570 which rates the freight between FCL and LCL. 5935-00-140-0073 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 72D for ocean manifesting and military sealift. 5935-00-140-0073 is not classified as a special type of cargo when transported by water. 5935-00-140-0073 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5935-00-140-0073
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- Over 10lb
- Less than 85G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- --
- No Requirement
- Not Applicable
- --
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
Contracting Technical Data File (CTDF) 5935-00-140-0073 October 2021
