5935-00-129-9358
Plug-In Electronic Components Socket
5935001299358 001299358 MILS12883 39107 9751-21 402656-6 7408127P3 TS101P02 JANS28 587B9-3 2885316333 632542-1 1890406PC9 7480923P1 402656
An item designed to electrically connect and mechanically position the base of an item having plug-in-type contacts, and to facilitate replacement of the item accommodated. It includes sockets which accommodate the contacts of capacitors, coils, crystals, electron tubes, relays, semiconductor devices and vibrators. Excludes sockets or receptacles designed to accommodate plug-in component circuit boards (printed circuit boards) and electronic modules or sub-assemblies. Also excludes heat-dissipating (not heat-sinks) sockets for mounting "power transistors". View more Plug-In Electronic Components Socket
Managed by United States
NSN Created on 1 Jan 1963
Data Last Changed
November 2023
November 2023
NATO Update Count
36
36
NATO Data Quality
Marketplace 5935-00-129-9358
Need Help?
Request a Quotation from participating marketplace vendors
Request a Quotation from participating marketplace vendors
M1288301-04 SOCKET,PLUG-IN ELECTRONIC COMPONENTS RQST NS
TS101P02 SOCKET,PLUG-IN ELECTRONIC COMPONENTS 195 EA NS
9751-21 SOCKET,PLUG-IN ELECTRONIC COMPONENTS 100 EA NS
M1288301-04 SOCKET,PLUG-IN ELECTRONIC COMPONENTS 3 EA NS
7408127P3 SOCKET,PLUG-IN ELECTRONIC COMPONENTS 2 EA NS
391-0-7 SOCKET,PLUG-IN ELECTRONIC COMPONENTS RQST NS
JANS28 SOCKET,PLUG-IN ELECTRONIC COMPONENTS 14 EA NS
TS101-P02 SOCKET,PLUG-IN ELECTRONIC COMPONENTS 1 EA NS
TS101P02 SOCKET,PLUG-IN ELECTRONIC COMPONENTS 7 EA NS
TS101P02 SOCKET,PLUG-IN ELECTRONIC COMPONENTS 7 EA NS
TS101-P02 SOCKET,PLUG-IN ELECTRONIC COMPONENTS 1 EA NS
JANS28 SOCKET,PLUG-IN ELECTRONIC COMPONENTS 1 EA NS
MIL-S-12883 SOCKET,PLUG-IN ELECTRONIC COMPONENTS 1 EA NS
Updated Every Day 5935-00-129-9358 RQST NE
Updated Every Day 5935-00-129-9358 RQST
Updated Every Day 5935-00-129-9358 RQST NE
Related Documents 5935-00-129-9358 5+ Documents (More...)
MILS12883 39107 9751-21 402656-6 7408127P3 TS101P02 JANS28 587B9-3 2885316333 402656 632542-1 1890406PC9
Photo 1/4 NSN 5935-00-129-9358 (Identification) 2/4 NSN 5935-00-129-9358 (Identification) 3/4 NSN
COMPONENTS 1 EA NS Request Quotation Updated Every Day 5935-00-129-9358 RQST NE Updated Every Day 5935
Photo 1/4 NSN 5935-00-129-9358 (Identification) 2/4 NSN 5935-00-129-9358 (Identification) 3/4 NSN
COMPONENTS 1 EA NS Request Quotation Updated Every Day 5935-00-129-9358 RQST NE Updated Every Day 5935
https//www.nsnlookup.com /fsg-58/fsc-5815/ca 5815-21-898-9624 Shaft 5815218989624 218989624,402656 402656
TS101P02 JANS28 587B9-3 2885316333 402656 632542 https https//www.nsnlookup.com /fsg-59/fsc-5930/us
SWITCH,ROTARY RQST NS Request Quotation Subscribe to View Vendor Details... 402656 SWITCH,ROTARY RQST
TS101P02 JANS28 587B9-3 2885316333 402656 632542 https https//www.nsnlookup.com /fsg-59/fsc-5930/us
SWITCH,ROTARY RQST NS Request Quotation Subscribe to View Vendor Details... 402656 SWITCH,ROTARY RQST
SWITCH,ROTARY RQST NS Request Quotation Subscribe to View Vendor Details... 402656 SWITCH,ROTARY RQST
SWITCH,ROTARY RQST Shaft 5815218989624 218989624,402656 -6 7408127P3 https//www.nsnlookup.com /fsg-28
MILS12883 39107 9751-21 402656 -6 7408127P3 TS101P02 JANS28 587B9-3 2885316333 402656 632542-1 1890406PC9
SWITCH,ROTARY RQST Shaft 5815218989624 218989624,402656 -6 7408127P3 https//www.nsnlookup.com /fsg-28
MILS12883 39107 9751-21 402656 -6 7408127P3 TS101P02 JANS28 587B9-3 2885316333 402656 632542-1 1890406PC9
JANS28 SOCKET,PLUG-IN ELECTRONIC COMPONENTS 11 EA NS Request Quotation Subscribe to View Vendor Details
TS101P02 SOCKET,PLUG-IN ELECTRONIC COMPONENTS 4 EA NS Request Quotation Subscribe to View Vendor Details
... 9751-21 SOCKET,PLUG-IN ELECTRONIC COMPONENTS 100 EA NS Request Quotation Subscribe to View Vendor
TS101P02 SOCKET,PLUG-IN ELECTRONIC COMPONENTS 4 EA NS Request Quotation Subscribe to View Vendor Details
... 9751-21 SOCKET,PLUG-IN ELECTRONIC COMPONENTS 100 EA NS Request Quotation Subscribe to View Vendor
JANS28 SOCKET,PLUG-IN ELECTRONIC COMPONENTS 11 EA NS Request Quotation Subscribe to View Vendor Details
JANS28 SOCKET,PLUG-IN ELECTRONIC COMPONENTS 14 EA NS Request Quotation Subscribe to View Vendor Details
N16S62603-6700 SOCKET,PLUG-IN ELECTRONIC COMPONENTS 1 EA NS Request Quotation MILS12883-2 SOCKET,PLUG-IN
JANS28 SOCKET,PLUG-IN ELECTRONIC COMPONENTS 14 EA NS Request Quotation Subscribe to View Vendor Details
N16S62603-6700 SOCKET,PLUG-IN ELECTRONIC COMPONENTS 1 EA NS Request Quotation MILS12883-2 SOCKET,PLUG-IN
Restrictions 5935-00-129-9358
5935-00-129-9358 is a Plug-In Electronic Components Socket that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item contains Silver.
Import and Export 5935-00-129-9358
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5935-00-129-9358
- Austria (WB01)
- Effective Date:
- 1 Feb 2005
- Brazil (YA01)
- Effective Date:
- 1 Dec 1999
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Australia (ZA01)
- Effective Date:
- 1 Apr 1991
- Belgium (ZB01)
- Effective Date:
- 1 Apr 1991
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
- New Zealand (ZE01)
- Effective Date:
- 1 Apr 1991
- France (ZF01)
- Effective Date:
- 1 Apr 1991
- Germany (ZG01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- United Kingdom (ZK01)
- Effective Date:
- 1 Apr 1991
- Portugal (ZP01)
- Effective Date:
- 1 Apr 1991
- Italy (ZR01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Nov 1998
Approved Sources 5935-00-129-9358
- Part Number
- Manufacturer
- Status
- TS101P02
- Manufacturer
- 81349 - Military Specifications (Active)
- Definitive Standard
- Definitive Standard
- MILS12883
- 81349 - Military Specifications (Active)
- Incomplete Standard
- Incomplete Standard
- 39107
- 17657 - Dictaphone Corporation (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- 9751-21
- 72785 - Dunlop Tire Corp (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- 9751-21
- 72825 - Eby Group, Llc, The (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- 402656-6
- 96214 - Raytheon Company (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- 7408127P3
- 03538 - Lockheed Martin Corporation (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- TS101P02
- 80058 - Joint Electronics Type Designation (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- JANS28
- 81350 - Joint Army-Navy Specifications (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- TS101P02
- 81350 - Joint Army-Navy Specifications (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- 587B9-3
- 94033 - Cardwell Condenser Corp (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- 2885316333
- 19204 - Army, United States Department Of (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- 632542-1
- 06424 - Alliant Techsystems Operations Llc (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 1890406PC9
- 10001 - Navair And Navsea Managed Original (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 7408127P3
- 24446 - General Electric Company (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 7480923P1
- 24446 - General Electric Company (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 7480923P1
- 24454 - General Electric Co (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- 402656
- 96214 - Raytheon Company (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5935-00-129-9358
- Characteristic
- Specifications
- FIIG
- Specifications
- A02300
- Accommodated Contact Quantity [AFRL]
- 8
- Body Material [AAFZ]
- Plastic
- Body Mounting Hole Accommodation Diameter [ADAL]
- 1.109 Inches Nominal
- Body Style [AAQL]
- Bottom Mount W/Metal Saddle
- Contact Material [AFRG]
- Copper Alloy
- Contact Position Arrangement Style [CRPY]
- Octal .687 Inch
- Contact Surface Treatment [AFRH]
- Silver And Lacquer
- Distance Between Mounting Facility Centers [AEJN]
- 1.500 Inches Nominal
- Features Provided [CBBL]
- Center Shield
- Mounting Hole Diameter [ABTB]
- 0.138 Inches Nominal
- Mounting Hole Style [AEVB]
- Round, W/Two Mounting Holes
- Mounting Method [AXGY]
- Saddle
- Mounting Type For Which Designed [BCNX]
- Chassis
- Precious Material And Location [PMLC]
- Contact Surfaces Silver
- Precious Material And Weight [PMWT]
- 0.008 Silver Grains, Troy
- Precious Material [PRMT]
- Silver
- Projection Length Above Mounting Surface [AKXD]
- 0.188 Inches Nominal
- Special Features [FEAT]
- 0.781 In. High Excluding Terminals And Contacts
- Overall Height [ABKW]
- 1.000 Inches Nominal
- Overall Length [ABHP]
- 1.875 Inches Nominal
- Overall Width [ABMK]
- 1.375 Inches Nominal
- Terminal Type And Quantity [TTQY]
- 8 Tab, Solder Lug
DLA Procurement Analysis 5935-00-129-9358
Management Data 5935-00-129-9358
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Mar 1998
- Defense Logistics Agency (DS)
- EA
- Subscribe
- 5
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- Defense Logistics Agency (DS)
- I
- Z
- Discontinued-Use 5935-00-201-4783
- Z
Similar Supply Items to 5935-00-129-9358
Freight Information 5935-00-129-9358
5935-00-129-9358 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061680. A Sub NMFC of Z. It has a NMFC Description of ELEC WIRING PLUGS ETC. 5935-00-129-9358 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34570 which rates the freight between FCL and LCL. 5935-00-129-9358 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 658 for ocean manifesting and military sealift. 5935-00-129-9358 is not classified as a special type of cargo when transported by water. 5935-00-129-9358 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5935-00-129-9358
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- 0.25 lb or less, one dimension 2" or less, other dimensions less than 24"
- 85 to 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 5
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- MIL-DTL-17667, Type II, Neutral Wrapping Paper, Creped
- --
- --
- --
- --
- MIL-DTL-17667, Type II, Neutral Wrapping Paper, Creped
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- Any Suitable Fiber Box
