5935-00-064-3359
Plug-In Electronic Components Socket
5935000643359 000643359 910120-19 6403-10B
An item designed to electrically connect and mechanically position the base of an item having plug-in-type contacts, and to facilitate replacement of the item accommodated. It includes sockets which accommodate the contacts of capacitors, coils, crystals, electron tubes, relays, semiconductor devices and vibrators. Excludes sockets or receptacles designed to accommodate plug-in component circuit boards (printed circuit boards) and electronic modules or sub-assemblies. Also excludes heat-dissipating (not heat-sinks) sockets for mounting "power transistors". View more Plug-In Electronic Components Socket
May 2023
5
Marketplace 5935-00-064-3359
Request a Quotation from participating marketplace vendors
Related Documents 5935-00-064-3359 5+ Documents (More...)
Photo 1/4 NSN 5935-00-064-3359 (Identification) 2/4 NSN 5935-00-064-3359 (Identification) 3/4 NSN
RQST NE Updated Every Day 5935-00-064-3359 RQST Updated Every Day 5935-00-064-3359 RQST NE Related Documents
Components Socket your Account Upgrade 5935-00-064-3359Plug-In Electronic Components Socket5935000643359 000643359
910120 https//www.nsnlookup.com /fsg-59/fsc-5935/us 5935-00-064-3359 Plug-In Electronic Components Socket
Restrictions 5935-00-064-3359
5935-00-064-3359 is a Plug-In Electronic Components Socket that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item contains a combination of two or more precious metals.
Import and Export 5935-00-064-3359
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5935-00-064-3359
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
Approved Sources 5935-00-064-3359
- Part Number
- Manufacturer
- Status
- 910120-19
- Manufacturer
- 06481 - Northrop Grumman Systems Corporation (Active)
- Primary Buy
- Primary Buy
- 6403-10B
- 99699 - Dri Relays Inc. (Active)
- Secondary Buy
- Secondary Buy
Datasheet 5935-00-064-3359
- Characteristic
- Specifications
- FIIG
- Specifications
- A02300
- Accommodated Contact Quantity [AFRL]
- 20
- Body Material [AAFZ]
- Steel And Plastic And Glass
- Body Mounting Hole Accommodation Diameter [ADAL]
- 0.958 Inches Minimum And 0.978 Inches Maximum
- Body Style [AAQL]
- Top Mount W/Metal Saddle
- Contact Maximum Current Rating In Amps [AFRC]
- 7.0
- Contact Material [AFRG]
- Phosphor Bronze
- Contact Position Arrangement Style [CRPY]
- Concentric
- Contact Surface Treatment [AFRH]
- Gold And Silver
- Distance Between Mounting Facility Centers [AEJN]
- 1.396 Inches Minimum And 1.416 Inches Maximum
- Furnished Items And Quantity [TMQY]
- 2 Bolt And 2 Nut And 2 Screw
- Fabrication Method [AARN]
- Molded
- Mounting Hole Diameter [ABTB]
- 0.138 Inches Nominal
- Mounting Hole Style [AEVB]
- Round, W/Two Mounting Holes
- Mounting Method [AXGY]
- Threaded Stud And Saddle
- Mounting Type For Which Designed [BCNX]
- Chassis
- Nominal Thread Size [CQJX]
- 0.138 Inches
- Saddle Material [AKWW]
- Steel
- Saddle Surface Treatment [AKWX]
- Cadmium
- Precious Material And Weight [PMWT]
- 0.021 Gold Grains, Troy And 0.021 Silver Grains, Troy
- Polarization Type [AKWN]
- Off Center Hole
- Precious Material And Location [PMLC]
- Contact Surface Gold And Contact Surface Silver
- Precious Material [PRMT]
- Gold And Silver
- Projection Length Below Mounting Surface [AKXC]
- 0.300 Inches Nominal
- Overall Height [ABKW]
- 0.970 Inches Nominal
- Overall Length [ABHP]
- 1.780 Inches Nominal
- Overall Width [ABMK]
- 1.060 Inches Nominal
- Specific Equipment Accommodated [AFJE]
- Electron Tube
- Terminal Type And Quantity [TTQY]
- 20 Tab, Solder Lug
- Thread Class [AAJD]
- 2A
- Thread Direction [AAJF]
- Right-Hand
- Thread Quantity Per Inch [CMLP]
- 32
- Thread Series Designator [THSD]
- Unc
Similar Supply Items to 5935-00-064-3359
Freight Information 5935-00-064-3359
5935-00-064-3359 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061680. A Sub NMFC of Z. It has a NMFC Description of ELEC WIRING PLUGS ETC. 5935-00-064-3359 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34570 which rates the freight between FCL and LCL. 5935-00-064-3359 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 723 for ocean manifesting and military sealift. 5935-00-064-3359 is not classified as a special type of cargo when transported by water. 5935-00-064-3359 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5935-00-064-3359
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- Over 10lb
- Less than 85G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- --
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- MIL-DTL-17667, Neutral Wrapping Paper
- No Requirement
- Not Applicable
- --
- No special marking
- MIL-DTL-17667, Neutral Wrapping Paper
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
