5930-01-177-3773
Code Indicating Wheel Switch
5930011773773 011773773 SM-D-703413 7-U-79
A switch which is externally actuated by a thumbwheel and/or pushbutton. A legend or message is visually displayed at each position of the indicating wheel which corresponds to electrically coded output. Electrically coded output is achieved by rotating a set of brush contacts permanently attached to the code indicating wheel, against a stationary commutator which is usually a printed wiring board having electrical pads or contacts which are interconnected by the rotating brush contacts. May have additional electrical components (such as resistors, capacitors, diodes) premounted on that portion of printed wiring board which extends beyond the back of switch housing. View more Code Indicating Wheel Switch
May 2023
5
Marketplace 5930-01-177-3773
Request a Quotation from participating marketplace vendors
Related Documents 5930-01-177-3773 3+ Documents (More...)
Photo 1/4 5930-01-177-3773 Photo 2/4 5930-01-177-3773 Photo 3/4 NSN 5930-01-177-3773 (Identification
5930-01-177-3773 2+ Documents ( More... ) https//www.nsnlookup.com /fsg-59/fsc-5930/us 5930-01-177-3773
Code Indicating Wheel Switch 5930011773773 Upgrade your Account Upgrade 5930-01-177-3773Code Indicating
Wheel Switch5930011773773 011773773 SM-D-703413 Restrictions Approved Sources Datasheet Management https
Restrictions 5930-01-177-3773
5930-01-177-3773 is a Code Indicating Wheel Switch that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item does not contain a precious metal.
Import and Export 5930-01-177-3773
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5930-01-177-3773
- US Army (A918)
- Effective Date:
- 1 Nov 2005
- Former MOE Rule:
- A196
- Supplementary Receivers:
- CL
Approved Sources 5930-01-177-3773
- Part Number
- Manufacturer
- Status
- SM-D-703413
- Manufacturer
- 80063 - Us Army Communications & Electronics (Active)
- Primary Buy
- Primary Buy
- 7-U-79
- 07126 - Electro Switch Corp. (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5930-01-177-3773
- Characteristic
- Specifications
- FIIG
- Specifications
- A052B0
- Actuator Type [AYDW]
- Thumbwheel All Actuators
- Color [HUES]
- Red Each Lamp
- Contact Arrangement Truth Table [CTZT]
- Bcd, Separate Common To Not-True Bits, 2 Pole - 8 Positions Each Section
- Contact Load Current Rating [CTHF]
- 125.0 Milliamperes Resistive Load Dc At Sea Level
- Contact Voltage Rating In Volts [CQMK]
- 28.0 Dc At Sea Level
- End Item Identification [AGAV]
- Test Set,Airborne Laser Tracker An/Aam-55
- Features Provided [CBBL]
- Rfi Shielding And Dummy Section
- Mounting Facility Pattern [CQYJ]
- Four Position Rectangular Single Mounting Facility
- Mounting Method [AXGY]
- Bracket Single Mounting Facility And Unthreaded Hole Single Mounting Facility
- Operating Temp Range [AFGA]
- -65.0/+85.0 Deg Celsius
- Style Designator [STYL]
- Rectangular Inline Indicating
- Individual Section Quantity [AFBH]
- 3
- Longest Horizontal Distance Between Mounting Centers [AFDS]
- 2.342 Inches Nominal Single Mounting Facility
- Longest Vertical Distance Between Mounting Centers [AFDV]
- 0.900 Inches Nominal Single Mounting Facility
- Readout Indicator Marking [CTZF]
- 1,2,3,4,5,6,7,8 Each Section
- Overall Height [ABKW]
- 1.780 Inches Nominal
- Overall Length [ABHP]
- 2.520 Inches Nominal
- Overall Width [ABMK]
- 1.330 Inches Nominal
- Unthreaded Mounting Hole Diameter [AEBV]
- 0.100 Inches Nominal Single Mounting Facility
- Switch Actuator Indexing Position Quantity [CRJH]
- 8 All Actuators
- Terminal Type [CSCF]
- Printed Circuit
DLA Procurement Analysis 5930-01-177-3773
Management Data 5930-01-177-3773
Army
- Materiel Category and Inventory Manager:
- Q
- Electronics Materiel (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Similar Supply Items to 5930-01-177-3773
Freight Information 5930-01-177-3773
5930-01-177-3773 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061300. A Sub NMFC of X. It has a NMFC Description of CIRCUIT BREAKER/SWITCH NOI. 5930-01-177-3773 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34410 which rates the freight between FCL and LCL. 5930-01-177-3773 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 658 for ocean manifesting and military sealift. 5930-01-177-3773 is not classified as a special type of cargo when transported by water. 5930-01-177-3773 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5930-01-177-3773
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- 0.25 lb or less, one dimension 2" or less, other dimensions less than 24"
- 85 to 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- --
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- --
- --
- --
- --
- --
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- See Method of Preservation
- --
Contracting Technical Data File (CTDF) 5930-01-177-3773 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
