5930-01-174-6024
Thermostatic Switch
5930011746024 011746024 MIL-PRF-24236/1 M24236/1-GLKKH MIL-S-24236/1
A switch that is actuated by changes in ambient temperature. Excludes CIRCUIT BREAKER; CONTROL, TEMPERATURE (as modified); FUSE (as modified); PROTECTOR, THERMAL-OVERLOAD, ELECTRICAL MOTOR; RELAY, THERMAL; and THERMOSTAT, FLOW CONTROL. See also CONTROL, TEMPERATURE (as modified) and REGULATOR, TEMPERATURE (as modified). View more Thermostatic Switch
November 2023
4
Marketplace 5930-01-174-6024
Request a Quotation from participating marketplace vendors
Updated Every 15 Minutes
Updated Every Day Updated Every Day
Updated Every Day Related Documents 5930-01-174-6024 5+ Documents (More...)
MIL-S-24236/1 SWITCH,THERMOSTATIC 5 EA NS Request Quotation MIL-PRF-24236/1 SWITCH,THERMOSTATIC 5 EA
MIL-PRF-24236/1 SWITCH,THERMOSTATIC RQST NS Request Quotation MIL-S-24236/1 SWITCH,THERMOSTATIC RQST
Restrictions 5930-01-174-6024
5930-01-174-6024 is a Thermostatic Switch that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item does not contain a precious metal.
Import and Export 5930-01-174-6024
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5930-01-174-6024
- US Army (A918)
- Effective Date:
- 1 Nov 2005
- Former MOE Rule:
- A196
- Supplementary Receivers:
- AZBFBD
- US Marine Corps (MC49)
- Effective Date:
- 1 Nov 2005
Approved Sources 5930-01-174-6024
- Part Number
- Manufacturer
- Status
- M24236/1-GLKKH
- Manufacturer
- 81349 - Military Specifications (Active)
- Definitive Standard
- Definitive Standard
- MIL-PRF-24236/1
- 81349 - Military Specifications (Active)
- Incomplete Standard
- Incomplete Standard
- MIL-S-24236/1
- 81349 - Military Specifications (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5930-01-174-6024
- Characteristic
- Specifications
- FIIG
- Specifications
- A048B0
- End Item Identification [AGAV]
- 2350-01-049-2695 Fighting Vehicle
- Body Height [ADAU]
- 0.437 Inches Maximum
- Contact Action Stimulus [CQGB]
- Increase
- Contact Adjustability [CTYC]
- Actuation Point Not Adjustable
- Contact Load Current Rating [CTHF]
- 2.0 Amperes Resistive Load First Voltage And 1.0 Amperes Inductive Load First Voltage And 0.5 Amperes Lamp Load First Voltage
- Contact Load Current Rating [CTHF]
- 5.0 Amperes Resistive Load Second Voltage And 2.5 Amperes Inductive Load Second Voltage And 1.0 Amperes Lamp Load Second Voltage
- Contact Load Current Rating [CTHF]
- 5.0 Amperes Resistive Load Third Voltage And 2.5 Amperes Inductive Load Third Voltage And 1.0 Amperes Lamp Load Third Voltage
- Contact Stimulus Rating [CTYX]
- 185.00 Actuation Point Nominal Degrees Fahrenheit And 150.00 Deactuation Point Nominal Degrees Fahrenheit
- Contact Voltage Rating In Volts [CTZB]
- 115.0 Ac At Sea Level First Voltage
- Contact Voltage Rating In Volts [CTZB]
- 28.0 Dc At Sea Level Second Voltage
- Contact Voltage Rating In Volts [CTZB]
- 28.0 Dc At Altitude Third Voltage
- Features Provided [CBBL]
- Hermetically Sealed Case
- Frequency In Hertz [FREQ]
- 60.0 First Voltage
- Media For Which Designed [MEDA]
- Gas Or Liquid
- Mounting Method [AXGY]
- Threaded Stud
- Nominal Thread Size [CQJX]
- 0.138 Inches Single Threaded Stud
- Nonpile-Up Contact Arrangement [CRLD]
- 1 Pole, Single Throw, Normally Closed, Momentary Action
- Operating Temp Rating [AWTN]
- -65.0 Deg Fahrenheit Minimum And 500.0 Deg Fahrenheit Maximum
- Style Designator [STYL]
- Disc
- Overall Diameter [ADAV]
- 0.540 Inches Minimum And 0.640 Inches Maximum
- Overall Height [ABKW]
- 0.867 Inches Nominal
- Specification/Standard Data [ZZZK]
- 81349-Mil-S-24236/1 Government Specification
- Temp Sensing Element Type [AKBY]
- Internal Sensor
- Terminal Type [CSCF]
- Tab, Solder Lug
- Test Data Document [TEST]
- 81349-Mil-S-24236 Specification (Includes Engineering Type Bulletins, Brochures,Etc., That Reflect Specification Type Data In Specification Format; Excludes Commercial Catalogs, Industry Directories, And Similar Trade Publications, Reflecting General Type Data On Certain Environmental And Performance Requirements And Test Conditions That Are Shown As "Typical", "Average", "Nominal", Etc.).
- Thread Class [AAJD]
- 2A Single Threaded Stud
- Thread Length [AASA]
- 0.187 Inches Nominal Single Threaded Stud
- Thread Series Designator [THSD]
- Unc Single Threaded Stud
- Thread Quantity Per Inch [CMLP]
- 32 Single Threaded Stud
Weapon Systems (WSDC) 5930-01-174-6024
DLA Procurement Analysis 5930-01-174-6024
- Last Stock Position:
- 31 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 5930-01-174-6024
Army
- Materiel Category and Inventory Manager:
- Q
- Electronics Materiel (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 5
- Critical Repair Part to a Combat Essential End Item
- Echelon Management:
- B2
- Operational Test:
- No Special Procedures
Similar Supply Items to 5930-01-174-6024
Freight Information 5930-01-174-6024
5930-01-174-6024 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061300. A Sub NMFC of X. It has a NMFC Description of CIRCUIT BREAKER/SWITCH NOI. 5930-01-174-6024 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34410 which rates the freight between FCL and LCL. 5930-01-174-6024 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 658 for ocean manifesting and military sealift. 5930-01-174-6024 is not classified as a special type of cargo when transported by water. 5930-01-174-6024 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
