5930-01-061-5877
Rotary Switch
5930010615877 010615877 LO2450 122304LJ KPN182
A switch actuated by a definite angular rotation of the switch shaft about its axis. For items having rated actuation travel and pressure characteristics, see SWITCH, SENSITIVE. Excludes RELAY, ROTARY; SWITCH, STEPPING; and SWITCH, TELEPHONE (as modified). View more Rotary Switch
November 2023
7
Marketplace 5930-01-061-5877
Request a Quotation from participating marketplace vendors
Related Documents 5930-01-061-5877 5+ Documents (More...)
Photo 1/3 5930-01-061-5877 Photo 2/3 NSN 5930-01-061-5877 (Identification) 3/3 - - - 1.
Day 5930-01-061-5877 RQST NE Updated Every Day 5930-01-061-5877 RQST Updated Every Day 5930-01-061-5877
Restrictions 5930-01-061-5877
5930-01-061-5877 is a Rotary Switch that does not have a nuclear hardened feature, but does have another critical feature or features such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
Import and Export 5930-01-061-5877
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5930-01-061-5877
- US Navy (N9BN)
- Effective Date:
- 1 Aug 2006
- Former MOE Rule:
- N9ND
- Supplementary Collaborators:
- GTHXHD
Approved Sources 5930-01-061-5877
- Part Number
- Manufacturer
- Status
- 122304LJ
- Manufacturer
- 82121 - Electro Switch Corp. (Active)
- Primary Buy
- Primary Buy
- KPN182
- 02750 - Eaton Aerospace Llc (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- LO2450
- 16236 - Dla Land And Maritime (Active)
- Advisory Reference
- Advisory Reference
Datasheet 5930-01-061-5877
- Characteristic
- Specifications
- FIIG
- Specifications
- A052B0
- Contact Load Current Rating [CTHF]
- 10.0 Amperes Resistive Load Ac At Sea Level
- Contact Switching Action [CSHW]
- Breaks Before Makes Each Section Rear
- Contact Voltage Rating In Volts [CQMK]
- 125.0 Ac At Sea Level
- Criticality Code Justification [CRTL]
- Feat
- Features Provided [CBBL]
- Actuator Knob
- First Flat Length [ABNB]
- 0.750 Inches Nominal Single Actuator
- Flat Height [ABNC]
- 0.219 Inches Nominal Single Actuator
- Mounting Facility Pattern [CQYJ]
- Four Position Rectangular 2Nd Mounting Facility
- Mounting Method [AXGY]
- Threaded Bushing W/Panel Seal 1St Mounting Facility
- Mounting Method [AXGY]
- Bracket 2Nd Mounting Facility And Threaded Hole 2Nd Mounting Facility
- Nominal Thread Size [CQJX]
- 0.190 Inches 2Nd Mounting Facility
- Nominal Thread Size [CQJX]
- 0.469 Inches 1St Mounting Facility
- Individual Section Quantity [AFBH]
- 4
- Knob Manufacturer Code [AFCQ]
- 82121
- Knob Manufacturer Part Number [AFCY]
- A
- Knob Special Markings [AFCZ]
- Arrow
- Longest Horizontal Distance Between Mounting Centers [AFDS]
- 1.641 Inches Nominal 2Nd Mounting Facility
- Longest Vertical Distance Between Mounting Centers [AFDV]
- 1.641 Inches Nominal 2Nd Mounting Facility
- Pole Quantity [AKPX]
- 1 Each Section Front
- Rotor Through Connection Quantity [CQTH]
- 1 Each Section
- Shaft Diameter [ABWV]
- 0.250 Inches Nominal Single Actuator
- Shaft Length [ABXF]
- 1.188 Inches Nominal Single Actuator
- Shaft Type [CRSJ]
- Round, Flatted, Threaded Hole Single Actuator
- Overall Height [ABKW]
- 2.500 Inches Nominal
- Overall Length [ABHP]
- 4.376 Inches Nominal
- Special Features [FEAT]
- Weapon System
- Style Designator [STYL]
- Tap, Circuit Selector
- Switch Actuator Indexing Position Quantity [CRJH]
- 3 Single Actuator
- Switch Actuator Momentary Position [CQQT]
- Clockwise Single Actuator And Counterclockwise Single Actuator
- Switch Actuator Stop Device Type [CTDN]
- Fixed Stop Single Actuator
- Switch Actuator Positioning Increment [CSLC]
- 90.0 Degrees Single Actuator
- Switch Contact Basic Design [AJZE]
- Nonpile-Up Symmetrical
- Terminal Type [CSCF]
- Tab W/Screw
- Thread Class [AAJD]
- 2A 1St Mounting Facility
- Thread Class [AAJD]
- 2B 2Nd Mounting Facility
- Thread Length [AASA]
- 0.438 Inches Nominal 1St Mounting Facility
- Thread Quantity Per Inch [CMLP]
- 24 2Nd Mounting Facility
- Thread Quantity Per Inch [CMLP]
- 32 1St Mounting Facility
- Thread Series Designator [THSD]
- Unc 2Nd Mounting Facility
- Thread Series Designator [THSD]
- Uns 1St Mounting Facility
- Throw Quantity [AKPY]
- 3 Each Section Rear
Weapon Systems (WSDC) 5930-01-061-5877
DLA Procurement Analysis 5930-01-061-5877
- Last Stock Position:
- 21 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 5930-01-061-5877
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5930-01-061-5877
Freight Information 5930-01-061-5877
5930-01-061-5877 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061300. A Sub NMFC of X. It has a NMFC Description of CIRCUIT BREAKER/SWITCH NOI. 5930-01-061-5877 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34410 which rates the freight between FCL and LCL. 5930-01-061-5877 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 72D for ocean manifesting and military sealift. 5930-01-061-5877 is not classified as a special type of cargo when transported by water. 5930-01-061-5877 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5930-01-061-5877
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- 0.25 lb or less, one dimension 2" or less, other dimensions less than 24"
- 85 to 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- --
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- --
- --
- --
- --
- --
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- See Method of Preservation
- --
Contracting Technical Data File (CTDF) 5930-01-061-5877 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- F
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
