5930-01-057-6815
Sensitive Switch
5930010576815 010576815 H11-1170-2 622EN118-R C8805-3-5 5930PL0651020 5930PL1610095
A switch with a quick-acting mechanism actuated by a highly delicate tactile contact. Includes membrane switch. Excludes SWITCH, FLEXIBLE; SWITCH, PRESSURE; and SWITCH, THERMOSTATIC. View more Sensitive Switch
November 2023
27
Marketplace 5930-01-057-6815
Request a Quotation from participating marketplace vendors
Related Documents 5930-01-057-6815 2+ Documents (More...)
Photo 1/4 5930-01-057-6815 Photo 2/4 NSN 5930-01-057-6815 (Identification) 3/4 NSN 5930-01-057-
3 EA NS Request Quotation Updated Every Day 5930-01-057-6815 RQST NE Updated Every Day 5930-01-057-6815
1170-1 SWITCH,SENSITIVE RQST NS Request Quotation https//www.nsnlookup.com /fsg-59/fsc-5930/us 5930-01-057-6815
Sensitive Switch 5930010576815 010576815 for $1 a day Upgrade your Account Upgrade 5930-01-057-
Restrictions 5930-01-057-6815
5930-01-057-6815 is a Sensitive Switch that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item does not contain a precious metal.
Import and Export 5930-01-057-6815
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5930-01-057-6815
- US Air Force (FUGX)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- FUTX
- Poland (WP01)
- Effective Date:
- 1 Jan 2007
- Israel (YD01)
- Effective Date:
- 1 Apr 1991
- Singapore (YJ01)
- Effective Date:
- 1 Apr 1991
- Belgium (ZB01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Netherlands (ZN01)
- Effective Date:
- 1 Apr 1991
- Portugal (ZP01)
- Effective Date:
- 1 Jul 1996
- Italy (ZR01)
- Effective Date:
- 1 Dec 2007
- Denmark (ZS01)
- Effective Date:
- 1 Apr 1991
- Norway (ZT01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Apr 2008
- Turkey (ZW01)
- Effective Date:
- 1 Dec 1995
Approved Sources 5930-01-057-6815
- Part Number
- Manufacturer
- Status
- H11-1170-2
- Manufacturer
- 81640 - Safran Power Usa, Llc (Active)
- Primary Buy
- Primary Buy
- 622EN118-R
- 91929 - Honeywell International Inc. (Active)
- Primary Buy
- Primary Buy
- 5930PL0651020
- 9009H - Jednolity Indeks Materialowy - (Active)
- NATO Reference
- NATO Reference
- 5930PL1610095
- 9009H - Jednolity Indeks Materialowy - (Active)
- NATO Reference
- NATO Reference
- C8805-3-5
- 81755 - Lockheed Martin Corporation (Active)
- Vendor Drawing
- Vendor Drawing
Datasheet 5930-01-057-6815
- Characteristic
- Specifications
- FIIG
- Specifications
- A053A0
- End Item Identification [AGAV]
- Gun Ventilation System Instl
- Actuator Free Position Height [AFUU]
- 0.970 Inches Minimum And 1.030 Inches Maximum
- Actuator Movement [CXQQ]
- 0.040 Pretravel Inches Nominal And 0.210 Overtravel Inches Nominal And 0.210 Differential Inches Nominal
- Actuator Roller Width [AFUW]
- 0.375 Inches Nominal
- Actuator Style [AFUQ]
- Roller Plunger
- Body Diameter [ABPM]
- 0.658 Inches Minimum And 0.718 Inches Maximum
- Body Length [ADAQ]
- 1.180 Inches Nominal
- Body Style [AAQL]
- Bushing Mounted
- Bushing Length [ABXD]
- 0.970 Inches Minimum And 1.030 Inches Maximum
- Switch Actuating Force [CSJN]
- 96.0 Ounces Minimum And 192.0 Ounces Maximum
- Switch Actuator Quantity [AFCG]
- 1
- Switch Release Force [CRRM]
- 4.0 Ounces Nominal
Weapon Systems (WSDC) 5930-01-057-6815
DLA Procurement Analysis 5930-01-057-6815
- Last Stock Position:
- 1 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 5930-01-057-6815
Air Force
- Fund:
- SF
- Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point
- Budget:
- 9
- 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors
- Aggregation Code:
- WF
- F-16 AIR COMBAT FIGHTER
- Price Validation Code:
- E
- The current standard price is an estimated price.
Estimated Price challenges are allowed but follow procedures in para 60.b. (3) of section L of this manual.
This code will be changed to a P code upon notification of a contract price or this code will be changed to an updated code upon determination of a valid price.
- Expendability
Recoverability
Repairability: - N
- Expendable. Condemn at User. Stock Fund (except Munitions).
NATO Stock Numbers Related to 5930-01-057-6815
Freight Information 5930-01-057-6815
5930-01-057-6815 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061300. A Sub NMFC of X. It has a NMFC Description of CIRCUIT BREAKER/SWITCH NOI. 5930-01-057-6815 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34410 which rates the freight between FCL and LCL. 5930-01-057-6815 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 72D for ocean manifesting and military sealift. 5930-01-057-6815 is not classified as a special type of cargo when transported by water. 5930-01-057-6815 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5930-01-057-6815
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- Over 10lb
- Less than 85G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- --
- --
- --
- --
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- Any Suitable Fiber Box
Procurement History 5930-01-057-6815 14 Records
- Contract
- Date
- CAGE
- Quantity
- Net Price
- Std Price
- CAGE
- SPE7M823P2691
- 07 Sep 2023
- Subscribe
- 24
- Subscribe
- Subscribe
- Subscribe
- SPE7M123P6971
- 12 Jul 2023
- Subscribe
- 22
- Subscribe
- Subscribe
- Subscribe
- SPE7M122V3207
- 07 Jan 2022
- Subscribe
- 15
- Subscribe
- Subscribe
- Subscribe
- SPE7M121V6657
- 13 Sep 2021
- Subscribe
- 40
- Subscribe
- Subscribe
- Subscribe
- SPE7M819P0318
- 14 Dec 2018
- Subscribe
- 50
- Subscribe
- Subscribe
- Subscribe
- SPE7M817P1290
- 12 Jan 2017
- Subscribe
- 70
- Subscribe
- Subscribe
- Subscribe
- SPE7M016V1209
- 28 Oct 2015
- Subscribe
- 33
- Subscribe
- Subscribe
- Subscribe
- SPE7M815V1508
- 13 Jul 2015
- Subscribe
- 35
- Subscribe
- Subscribe
- Subscribe
- SPE7M815V0803
- 09 Mar 2015
- Subscribe
- 22
- Subscribe
- Subscribe
- Subscribe
- SPE7M814V2152
- 12 Sep 2014
- Subscribe
- 20
- Subscribe
- Subscribe
- Subscribe
- SPE7M814V1283
- 07 Apr 2014
- Subscribe
- 21
- Subscribe
- Subscribe
- Subscribe
- SPE7M813V0900
- 12 Sep 2013
- Subscribe
- 16
- Subscribe
- Subscribe
- Subscribe
- SPE7M813M0469
- 19 Aug 2013
- Subscribe
- 18
- Subscribe
- Subscribe
- Subscribe
- SPM7M813V2126
- 07 Feb 2013
- Subscribe
- 16
- Subscribe
- Subscribe
- Subscribe
Contracting Technical Data File (CTDF) 5930-01-057-6815 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- L
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
