5930-01-054-7422
Toggle Switch
5930010547422 010547422 MIL-DTL-3950 104TL2-1N 8575K4-20 MS27789-21N MIL-S-3950 5930PL0650402 5930PL1825369
A switch which is externally actuated by a lever and whose contacts open and close with an instantaneous (snap) action; includes items having one or more momentary positions. Includes switches (snap action) which use mercury to bridge contacts, and assemblages of complete switches (snap action) having common actuators. Excludes SWITCH, LEVER; SWITCH, ROTARY; SWITCH, KNIFE; SWITCH, SENSITIVE; and SWITCH, BOX. View more Toggle Switch
November 2023
28
Marketplace 5930-01-054-7422
Request a Quotation from participating marketplace vendors
Updated Every Day Updated Every Day
Updated Every Day Related Documents 5930-01-054-7422 5+ Documents (More...)
MIL-DTL/3950 SWITCH,TOGGLE 3 EA NS Request Quotation MIL-S/3950 SWITCH,TOGGLE 3 EA NS Request Quotation
MIL-S-3950 SWITCH,TOGGLE 3 EA NS Request Quotation Updated Every Day 5930-01-054-7422 RQST NE Updated
MS27789-21N-NE A switch which is externally actuated by a lever and whose contacts open and close
Toggle Switch 5930010547422 010547422 Account Upgrade 5930-01-054-7422Toggle Switch5930010547422
Restrictions 5930-01-054-7422
5930-01-054-7422 is a Toggle Switch that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
Import and Export 5930-01-054-7422
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5930-01-054-7422
- US Air Force (FXGX)
- Effective Date:
- 1 Nov 2005
- Former MOE Rule:
- FXTX
- US Navy (N9BN)
- Effective Date:
- 1 Dec 2013
- Supplementary Collaborators:
- GG
- Poland (WP01)
- Effective Date:
- 1 Jan 2007
- Singapore (YJ01)
- Effective Date:
- 1 Apr 1991
- Belgium (ZB01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Netherlands (ZN01)
- Effective Date:
- 1 Sep 2014
- Denmark (ZS01)
- Effective Date:
- 1 Apr 1991
- Norway (ZT01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Apr 2008
- Turkey (ZW01)
- Effective Date:
- 1 Dec 1995
Approved Sources 5930-01-054-7422
- Part Number
- Manufacturer
- Status
- MS27789-21N
- Manufacturer
- 96906 - Military Standards (Active)
- Definitive Standard
- Definitive Standard
- MIL-DTL-3950
- 81349 - Military Specifications (Active)
- Incomplete Standard
- Incomplete Standard
- MIL-S-3950
- 81349 - Military Specifications (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 5930PL0650402
- 9009H - Jednolity Indeks Materialowy - (Active)
- NATO Reference
- NATO Reference
- 5930PL1825369
- 9009H - Jednolity Indeks Materialowy - (Active)
- NATO Reference
- NATO Reference
- 104TL2-1N
- 91929 - Honeywell International Inc. (Active)
- Advisory Reference
- Advisory Reference
- 8575K4-20
- 81640 - Safran Power Usa, Llc (Active)
- Advisory Reference
- Advisory Reference
Datasheet 5930-01-054-7422
- Characteristic
- Specifications
- FIIG
- Specifications
- A053A0
- Actuator Height [AFUS]
- 1.140 Inches Nominal
- Actuator Diameter [AFUR]
- 0.420 Inches Nominal
- Actuator Position-Action Relationship [AFUX]
- Up Position Maintained And Down Position Maintained And Center Position Maintained
- Actuator Position-Locking Relationship [AFUY]
- Up Position Locked Out And Down Position No Locking Action And Center Position No Locking Action
- Actuator Style [AFUQ]
- Round
- Body Height [ADAU]
- 1.706 Inches Maximum
- Body Length [ADAQ]
- 1.660 Inches Maximum
- Body Style [AAQL]
- Bushing Mount
- Body Width [ADAT]
- 1.340 Inches Maximum
- Bushing Length [ABXD]
- 0.470 Inches Nominal
- Contact Load Current Rating At Maximum Rated Voltage [CXQR]
- 7.500 Amperes Resistive Dc And 7.500 Amperes Inductive Dc And 5.000 Amperes Lamp Dc And 7.500 Amperes Resistive Ac And 7.500 Amperes Inductive Ac And 4.000 Amperes Lamp Ac
- Features Provided [CBBL]
- Actuator Seal
- Maximum Voltage Rating In Volts [AFXE]
- 115.0 Ac And 28.0 Dc
- Mounting Method [AXGY]
- Threaded Bushing
- Nominal Thread Size [CQJX]
- 0.469 Inches
- Nonpile-Up Contact Arrangement [CRLD]
- 4 Pole, Double Throw, Three Positions Maintained Single Switch Unit
- Inclosure Type [AKNA]
- Fully Inclosed
- Overall Height [ABKW]
- 3.316 Inches Nominal
- Overall Length [ABHP]
- 1.660 Inches Maximum
- Overall Width [ABMK]
- 1.340 Inches Maximum
- Specification/Standard Data [ZZZK]
- 96906-Ms27789 Government Standard
- Terminal Type And Quantity [TTQY]
- 12 Socket, Integrated Wire Termination
- Test Data Document [TEST]
- 81349-Mil-S-3950 Specification (Includes Engineering Type Bulletins, Brochures,Etc., That Reflect Specification Type Data In Specification Format; Excludes Commercial Catalogs, Industry Directories, And Similar Trade Publications, Reflecting General Type Data On Certain Environmental And Performance Requirements And Test Conditions That Are Shown As "Typical", "Average", "Nominal", Etc.).
- Thread Quantity Per Inch [CMLP]
- 32
- Thread Series Designator [THSD]
- Uns
Weapon Systems (WSDC) 5930-01-054-7422
DLA Procurement Analysis 5930-01-054-7422
- Last Stock Position:
- 84 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 5930-01-054-7422
Air Force
- Fund:
- SF
- Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point
- Budget:
- 9
- 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors
- Aggregation Code:
- EH
- ELECTRONIC COMPONENTS
- Price Validation Code:
- V
- The current standard price has been validated.
The item has been analyzed in conjunction with the Zero Overpricing Program and is in the accepted price range.
The item was procured under open competition and under the competitive arena the price is considered fair and reasonable.
ZOP or Standard price challenges are permissible but must be supported by adequate justification.
- Expendability
Recoverability
Repairability: - N
- Expendable. Condemn at User. Stock Fund (except Munitions).
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5930-01-054-7422
Freight Information 5930-01-054-7422
5930-01-054-7422 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061300. A Sub NMFC of X. It has a NMFC Description of CIRCUIT BREAKER/SWITCH NOI. 5930-01-054-7422 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34410 which rates the freight between FCL and LCL. 5930-01-054-7422 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 72D for ocean manifesting and military sealift. 5930-01-054-7422 is not classified as a special type of cargo when transported by water. 5930-01-054-7422 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5930-01-054-7422
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- Over 10lb
- Less than 85G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- --
- --
- --
- --
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- Any Suitable Fiber Box
Contracting Technical Data File (CTDF) 5930-01-054-7422 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- L
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
