5930-01-026-7672
Push Switch
5930010267672 010267672 2552867-6
A switch that is externally actuated by a device such as a push rod or button, which requires pushing for each actuation. The action may be momentary, with mechanical return. The actuating device may or may not be an integral part of the switch. The item may include provisions for mounting indicating lamp(s) or light emitting diode(s) in the actuator. Includes items consisting of individually separable switches that are physically interlocked, that have a common actuator, or are electrically connected. Excludes LIGHT-SWITCH; LIGHT-SWITCH ASSEMBLY; SWITCH, BEAM SELECTING, HEADLIGHT; SWITCH, FOOT; SWITCH, INTERLOCK; SWITCH, PRESSURE; SWITCH, PUSH-PULL; SWITCH, SENSITIVE and SWITCH ASSEMBLY. For devices which start, stop, reverse, select and/or regulate the speed of a motor, see STARTER, MOTOR and CONTROLLER, MOTOR. View more Push Switch
May 2023
6
Marketplace 5930-01-026-7672
Request a Quotation from participating marketplace vendors
Related Documents 5930-01-026-7672 1+ Documents (More...)
BUY NE FedMall Updated Every Day 5930-01-026-7672 RQST NE Updated Every Day 5930-01-026-7672 RQST
) https//www.nsnlookup.com /fsg-59/fsc-5930/us 5930-01-026-7672 Push Switch 5930010267672 010267672,2552867
Restrictions 5930-01-026-7672
5930-01-026-7672 is a Push Switch that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
Import and Export 5930-01-026-7672
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5930-01-026-7672
- US Navy (N9BN)
- Effective Date:
- 1 Nov 2005
- Former MOE Rule:
- N9ND
- Supplementary Collaborators:
- HD
- Australia (ZA01)
- Effective Date:
- 1 Oct 1997
Approved Sources 5930-01-026-7672
- Part Number
- Manufacturer
- Status
- 2552867-6
- Manufacturer
- 10001 - Navair And Navsea Managed Original (Active)
- Primary Buy
- Primary Buy
- 2552867-6
- 96182 - Safran Electronics & Defense (Active)
- Secondary Buy
- Secondary Buy
- 2552867-6
- 83986 - Durite Circuits (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5930-01-026-7672
- Characteristic
- Specifications
- FIIG
- Specifications
- A053A0
- Actuator Height [AFUS]
- 0.140 Inches Maximum
- Actuator Color [AFVA]
- White Single Actuator
- Actuator Inscription [AFVE]
- Split Mode Single Actuator
- Actuator Length [AFGK]
- 1.040 Inches Nominal
- Actuator Style [AFUQ]
- Rectangular
- Actuator Width [AFUT]
- 0.800 Inches Nominal
- Body Length [ADAQ]
- 1.200 Inches Maximum
- Body Style [AAQL]
- Panel Mount
- Body Width [ADAT]
- 0.960 Inches Nominal
- Case Material [ADTV]
- Metal
- Contact Load Current Rating At Maximum Rated Voltage [CXQR]
- 5.000 Amperes Resistive Dc And 3.000 Amperes Inductive Dc And 2.400 Amperes Lamp Dc And 5.000 Amperes Resistive Ac And 5.000 Amperes Inductive Ac And 1.500 Amperes Lamp Ac
- Features Provided [CBBL]
- Actuator Seal
- Maximum Voltage Rating In Volts [AFXE]
- 115.0 Ac And 28.0 Dc
- Mounting Method [AXGY]
- Panel
- Nonpile-Up Contact Arrangement [CRLD]
- 4 Pole, Double Throw, One Position Momentary Single Switch Unit
- Illuminated Actuator Color [AFVB]
- White Single Actuator
- Inclosure Type [AKNA]
- Fully Inclosed
- Overall Height [ABKW]
- 2.968 Inches Maximum
- Overall Length [ABHP]
- 1.200 Inches Nominal
- Overall Width [ABMK]
- 0.960 Inches Nominal
- Terminal Type And Quantity [TTQY]
- 5 Tab, Solder Lug And 12 Turret
DLA Procurement Analysis 5930-01-026-7672
Management Data 5930-01-026-7672
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5930-01-026-7672
Freight Information 5930-01-026-7672
5930-01-026-7672 has freight characteristics managed by the Food and Drug Administration (FDA).It has a National Motor Freight Classification (NMFC) of 061300. A Sub NMFC of X. It has a NMFC Description of CIRCUIT BREAKER/SWITCH NOI. 5930-01-026-7672 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34410 which rates the freight between FCL and LCL. 5930-01-026-7672 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 72D for ocean manifesting and military sealift. 5930-01-026-7672 is not classified as a special type of cargo when transported by water. 5930-01-026-7672 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5930-01-026-7672
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- 0.25 lb or less, one dimension 2" or less, other dimensions less than 24"
- 85 to 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- --
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- --
- --
- --
- --
- --
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- See Method of Preservation
- --
