5930-00-998-4246
Thermostatic Switch
5930009984246 009984246 21S4 2614E30 A409
A switch that is actuated by changes in ambient temperature. Excludes CIRCUIT BREAKER; CONTROL, TEMPERATURE (as modified); FUSE (as modified); PROTECTOR, THERMAL-OVERLOAD, ELECTRICAL MOTOR; RELAY, THERMAL; and THERMOSTAT, FLOW CONTROL. See also CONTROL, TEMPERATURE (as modified) and REGULATOR, TEMPERATURE (as modified). View more Thermostatic Switch
May 2023
8
Marketplace 5930-00-998-4246
Request a Quotation from participating marketplace vendors
Related Documents 5930-00-998-4246 5+ Documents (More...)
A409 SWITCH,THERMOSTATIC 285 EA NS Request Quotation Subscribe to View Vendor Details... 5930-00-998-
RQST NE Updated Every Day 5930-00-998-4246 RQST Updated Every Day 5930-00-998-4246 RQST NE Related
) https//www.nsnlookup.com /fsg-77/fsc-7730/dk 7730-22-285-0569 Tv 21 In 7730222850569222850569,TX-21S4
) https//www.nsnlookup.com /fsg-77/fsc-7730/dk 7730-22-285-0569 Tv 21 In 7730222850569222850569,TX-21S4
-20922409-262348-40E18-21S4-207348-40E18-21S4(207) An electrical fitting with electrical 5935-00-009-
-207348 Upgrade 5930-00-998-4246Thermostatic Switch5930009984246 009984246 21S4 -20 922409-262 https/
(207) 348-46E18-21S4-207 An electrical fitting with electrical contacts, constructed to be affixed to
CONNECTOR,PLUG,ELECTRICAL RQST NS Request Quotation Subscribe to View Vendor Details... 348-46E18-21S4
https//www.nsnlookup.com /fsg-77/fsc-7730/dk 7730-22-285-0569 Tv 21 In 7730222850569 222850569,TX-21S4
-20 922409-262 348-40E18-21S4-207 348-40E18-21S4(207) An electrical fitting with electrical contacts
Restrictions 5930-00-998-4246
5930-00-998-4246 is a Thermostatic Switch that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
Import and Export 5930-00-998-4246
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5930-00-998-4246
- US Navy (N9BN)
- Effective Date:
- 1 Nov 2005
- Former MOE Rule:
- N9ND
- Supplementary Collaborators:
- HD
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Australia (ZA01)
- Effective Date:
- 1 Apr 1991
- Italy (ZR01)
- Effective Date:
- 1 Jul 1997
- Turkey (ZW01)
- Effective Date:
- 1 Dec 2005
Approved Sources 5930-00-998-4246
- Part Number
- Manufacturer
- Status
- 21S4
- Manufacturer
- 99872 - Entron Industries Limited (Active)
- Primary Buy
- Primary Buy
- 2614E30
- 99872 - Entron Industries Limited (Active)
- Primary Buy
- Primary Buy
- A409
- 93410 - Essex Group Inc Controls Div (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5930-00-998-4246
- Characteristic
- Specifications
- FIIG
- Specifications
- A048B0
- Contact Action Stimulus [CQGB]
- Increase
- Contact Adjustability [CTYC]
- Actuation Point Not Adjustable
- Contact Load Current Rating [CTHF]
- 1.0 Amperes Resistive Load Single Voltage
- Contact Stimulus Rating [CTYX]
- 158.00 Actuation Point Nominal Degrees Fahrenheit And 138.00 Deactuation Point Nominal Degrees Fahrenheit
- Contact Voltage Rating In Volts [CTZB]
- 125.0 Ac At Sea Level Single Voltage
- Mounting Method [AXGY]
- Bracket
- Nonpile-Up Contact Arrangement [CRLD]
- 1 Pole, Single Throw, Normally Open, Momentary Action
- Overall Length [ABHP]
- 1.125 Inches Nominal
- Overall Height [ABKW]
- 0.305 Inches Nominal
- Overall Width [ABMK]
- 0.660 Inches Nominal
- Special Features [FEAT]
- Two 0.147 In. Dia Mtg Holesspaced 0.875 In. C To C
- Temp Sensing Element Type [AKBY]
- Internal Sensor
- Terminal Type [CSCF]
- Tab, Solder Lug
Weapon Systems (WSDC) 5930-00-998-4246
DLA Procurement Analysis 5930-00-998-4246
Management Data 5930-00-998-4246
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
NATO Stock Numbers Related to 5930-00-998-4246
Freight Information 5930-00-998-4246
5930-00-998-4246 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061300. A Sub NMFC of X. It has a NMFC Description of CIRCUIT BREAKER/SWITCH NOI. 5930-00-998-4246 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34410 which rates the freight between FCL and LCL. 5930-00-998-4246 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 658 for ocean manifesting and military sealift. 5930-00-998-4246 is not classified as a special type of cargo when transported by water. 5930-00-998-4246 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5930-00-998-4246
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- 0.25 lb or less, one dimension 2" or less, other dimensions less than 24"
- 85 to 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- A-A-1249, Paper, Tissue
- No Requirement
- Not Applicable
- --
- No special marking
- A-A-1249, Paper, Tissue
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- PPP-B-566 or PPP-B-676, Folding or Setup Box
