5930-00-890-4368
Rotary Switch
5930008904368 008904368 4996 11614140 11614140-1
A switch actuated by a definite angular rotation of the switch shaft about its axis. For items having rated actuation travel and pressure characteristics, see SWITCH, SENSITIVE. Excludes RELAY, ROTARY; SWITCH, STEPPING; and SWITCH, TELEPHONE (as modified). View more Rotary Switch
August 2025
7
Marketplace 5930-00-890-4368
Request a Quotation from participating marketplace vendors
Related Documents 5930-00-890-4368 3+ Documents (More...)
to View Vendor Details... 4996 SWITCH,ROTARY 11 EA NS Request Quotation Updated Every Day 5930-00-890
Documents 5930-00-890-4368 3+ Documents ( More... ) https//www.nsnlookup.com /fsg-59/fsc-5930/us 5930
Related Documents 5930-01-062-5630 2+ Documents https//www.nsnlookup.com /fsg-59/fsc-5930/us 5930-00-890-4368
Rotary Switch 5930008904368 008904368 https//www.nsnlookup.com /fsg-59/fsc-5930/us 5930 https//
Restrictions 5930-00-890-4368
5930-00-890-4368 is a Rotary Switch that does not have a nuclear hardened feature, but does have another critical feature or features such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item contains Silver.
Import and Export 5930-00-890-4368
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5930-00-890-4368
- US Army (A918)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- A196
- Supplementary Receivers:
- AZ
- US Navy (N9BN)
- Effective Date:
- 1 Dec 2013
- Supplementary Collaborators:
- GG
- Portugal (ZP01)
- Effective Date:
- 1 Jun 2000
Approved Sources 5930-00-890-4368
- Part Number
- Manufacturer
- Status
- 11614140
- Manufacturer
- 19207 - U S Army Tank Automotive Command (Active)
- Primary Buy
- Primary Buy
- 4996
- 0ZSM8 - Ucom, Inc. (Active)
- Secondary Buy
- Secondary Buy
- 11614140
- 23040 - Ford Motor Co Ford Parts And Service (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- 11614140
- 57526 - Ford Motor Company (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- 11614140-1
- 0ZSM8 - Ucom, Inc. (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 4996
- 81263 - Universal Components Corp (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- 11614140-1
- 19207 - U S Army Tank Automotive Command (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5930-00-890-4368
- Characteristic
- Specifications
- FIIG
- Specifications
- A052B0
- Contact Load Current Rating [CTHF]
- 20.0 Amperes Resistive Load Dc At Sea Level
- Contact Voltage Rating In Volts [CQMK]
- 30.0 Dc At Sea Level
- Criticality Code Justification [CRTL]
- Feat
- End Item Identification [AGAV]
- Semi-Trailer, 5000 Gal, Refueler, 4X4, M970 Trailer, Semi, Tank; 5000 Gal, Bulk
- Mounting Method [AXGY]
- Threaded Bushing Single Mounting Facility
- Nominal Thread Size [CQJX]
- 0.500 Inches Single Mounting Facility
- Nonturn Device Radius [AEFP]
- 0.610 Inches Minimum At 3:00 O'clock And 0.640 Inches Maximum At 3:00 O'clock
- Nonturn Device Type [AFDC]
- Tab At 3:00 O'clock
- Individual Section Quantity [AFBH]
- 1
- Precious Material And Location [PMLC]
- Contact Surfaces Silver
- Precious Material [PRMT]
- Silver
- Shaft Length [ABXF]
- 0.360 Inches Minimum Single Actuator And 0.390 Inches Maximum Single Actuator
- Shaft Diameter [ABWV]
- 0.310 Inches Minimum Single Actuator And 0.314 Inches Maximum Single Actuator
- Shaft Type [CRSJ]
- Round Single Actuator
- Overall Diameter [ADAV]
- 1.780 Inches Nominal
- Overall Length [ABHP]
- 3.570 Inches Nominal
- Special Features [FEAT]
- Shaft Has A Tapped Hole. Weapon System Essential
- Style Designator [STYL]
- Snap Or Line
- Switch Actuator Indexing Position Quantity [CRJH]
- 3 Single Actuator
- Switch Actuator Momentary Position [CQQT]
- Counterclockwise Single Actuator
- Switch Actuator Stop Device Type [CTDN]
- Fixed Stop Single Actuator
- Switch Contact Basic Design [AJZE]
- Nonpile-Up Nonsymmetrical
- Terminal Type [CSCF]
- Wire Lead
- Thread Class [AAJD]
- 2A Single Mounting Facility
- Thread Length [AASA]
- 0.560 Inches Nominal Single Mounting Facility
- Thread Series Designator [THSD]
- Unf Single Mounting Facility
Weapon Systems (WSDC) 5930-00-890-4368
DLA Procurement Analysis 5930-00-890-4368
- Last Stock Position:
- 53 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 5930-00-890-4368
Army
- Materiel Category and Inventory Manager:
- Q
- Electronics Materiel (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5930-00-890-4368
Freight Information 5930-00-890-4368
5930-00-890-4368 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061360. A Sub NMFC of X. It has a NMFC Description of COILS/YOKES FOCUS/DEFLECTION TV. 5930-00-890-4368 is rated as class 85 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34430 which rates the freight between FCL and LCL. 5930-00-890-4368 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 72D for ocean manifesting and military sealift. 5930-00-890-4368 is not classified as a special type of cargo when transported by water. 5930-00-890-4368 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5930-00-890-4368
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- 0.25 lb or less, one dimension 2" or less, other dimensions less than 24"
- 85 to 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- MIL-DTL-17667, Type I, Neutral Wrapping Paper, Flat
- A-A-1898, Grade II, Water Resistant Cellulosic Cushioning
- --
- --
- No special marking
- MIL-DTL-17667, Type I, Neutral Wrapping Paper, Flat
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- PPP-B-566 or PPP-B-676, Folding or Setup Box
