5930-00-790-3884
Rotary Switch
5930007903884 007903884 1250071PC3371 31301LF
A switch actuated by a definite angular rotation of the switch shaft about its axis. For items having rated actuation travel and pressure characteristics, see SWITCH, SENSITIVE. Excludes RELAY, ROTARY; SWITCH, STEPPING; and SWITCH, TELEPHONE (as modified). View more Rotary Switch
May 2023
6
Marketplace 5930-00-790-3884
Request a Quotation from participating marketplace vendors
Related Documents 5930-00-790-3884 5+ Documents (More...)
5930-00-790-3884 1+ Documents ( More... ) https//www.nsnlookup.com /fsg-59/fsc-5930/us 5930-00-790-3884
RQST Updated Every Day 5930-00-790-3884 RQST NE Related Documents 5930-00-790-3884 1+ Documents
Restrictions 5930-00-790-3884
5930-00-790-3884 is a Rotary Switch that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
Import and Export 5930-00-790-3884
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5930-00-790-3884
- Italy (ZR01)
- Effective Date:
- 1 Jul 1997
Approved Sources 5930-00-790-3884
- Part Number
- Manufacturer
- Status
- 1250071PC3371
- Manufacturer
- 10001 - Navair And Navsea Managed Original (Active)
- Primary Buy
- Primary Buy
- 31301LF
- 82121 - Electro Switch Corp. (Active)
- Primary Buy
- Primary Buy
Datasheet 5930-00-790-3884
- Characteristic
- Specifications
- FIIG
- Specifications
- A052B0
- Style Designator [STYL]
- Tap, Circular, Bushing Mount
- Overall Length [ABHP]
- 2.155 Inches Nominal
- Overall Diameter [ADAV]
- 2.000 Inches Nominal
- Individual Section Quantity [AFBH]
- 1
- Switch Contact Basic Design [AJZE]
- Nonpile-Up Symmetrical
- Pole Quantity [AKPX]
- 1 Each Section Periphery
- Throw Quantity [AKPY]
- 5 Each Section Periphery
- Contact Switching Action [CSHW]
- Breaks Before Makes Each Section Periphery
- Contact Voltage Rating In Volts [CQMK]
- 125.0 Ac At Sea Level
- Contact Voltage Rating In Volts [CQMK]
- 30.0 Dc At Sea Level
- Contact Load Current Rating [CTHF]
- 5.0 Amperes Resistive Load Ac At Sea Level
- Contact Load Current Rating [CTHF]
- 5.0 Amperes Resistive Load Dc At Sea Level
- Switch Actuator Indexing Position Quantity [CRJH]
- 5 Single Actuator
- Switch Actuator Positioning Increment [CSLC]
- 45.0 Degrees Single Actuator
- Switch Actuator Stop Device Type [CTDN]
- Fixed Stop Single Actuator
- Shaft Type [CRSJ]
- Round, Flatted Single Actuator
- First Flat Length [ABNB]
- 0.437 Inches Nominal Single Actuator
- Flat Height [ABNC]
- 0.216 Inches Nominal Single Actuator
- Shaft Diameter [ABWV]
- 0.250 Inches Nominal Single Actuator
- Shaft Length [ABXF]
- 1.093 Inches Nominal Single Actuator
- Terminal Type [CSCF]
- Tab W/Screw
- Mounting Method [AXGY]
- Threaded Bushing Single Mounting Facility
- Thread Series Designator [THSD]
- Uns Single Mounting Facility
- Nominal Thread Size [CQJX]
- 0.469 Inches Single Mounting Facility
- Thread Class [AAJD]
- 2A Single Mounting Facility
- Thread Quantity Per Inch [CMLP]
- 32 Single Mounting Facility
- Thread Length [AASA]
- 0.468 Inches Nominal Single Mounting Facility
- Features Provided [CBBL]
- Actuator Knob
Similar Supply Items to 5930-00-790-3884
Freight Information 5930-00-790-3884
5930-00-790-3884 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061360. A Sub NMFC of X. It has a NMFC Description of COILS/YOKES FOCUS/DEFLECTION TV. 5930-00-790-3884 is rated as class 85 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34430 which rates the freight between FCL and LCL. 5930-00-790-3884 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 658 for ocean manifesting and military sealift. 5930-00-790-3884 is not classified as a special type of cargo when transported by water. 5930-00-790-3884 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5930-00-790-3884
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- 0.25 lb or less, one dimension 2" or less, other dimensions less than 24"
- 85 to 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- --
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- MIL-PRF-121, Greaseproof, Waterproof Barrier
- No Requirement
- Not Applicable
- PPP-B-566 or PPP-B-676, Folding or Setup Box
- No special marking
- MIL-PRF-121, Greaseproof, Waterproof Barrier
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- Any Suitable Fiber Box
