5930-00-699-9438

Rotary Switch

5930006999438 006999438 MIL-DTL-13623/1 SAW-6999438 4776B 1998078 816047 B7829 0624A0399 3029296-5 189095 HCF12497 X55210 SE575E 4202629 79Z1522 MS39060 73029296 3029296 177MAM1 5T1517 TC15-1444 929134 60089 R25231 MIL-DTL-13623/1-2 1998009

A switch actuated by a definite angular rotation of the switch shaft about its axis. For items having rated actuation travel and pressure characteristics, see SWITCH, SENSITIVE. Excludes RELAY, ROTARY; SWITCH, STEPPING; and SWITCH, TELEPHONE (as modified). View more Rotary Switch

Managed by United States

NSN Created on 1 Jan 1961

Data Last Changed
August 2025

NATO Update Count
82

NATO Data Quality

5930-00-699-9438 SWITCH,ROTARY 5930006999438 006999438 1/2 — 5930-00-699-9438 Photo 1/2

STYL Style 12 for 5930-00-699-9438 2/2 — NSN 5930-00-699-9438 (Identification) 2/2

Marketplace 5930-00-699-9438

Need Help?
Request a Quotation from participating marketplace vendors

Subscribe to View Vendor Details...

MS39060-2 SWITCH,ROTARY 4 EA NS

Subscribe to View Vendor Details...

5930-00-699-9438 SWITCH,ROTARY 138 EA NS

Subscribe to View Vendor Details...

4202629 SWITCH,ROTARY 4 EA NS

5930-00-699-9438 SWITCH,ROTARY 5 EA NS

X55210 SWITCH,ROTARY 4 EA NS

MIL-S-13623/1-2 SWITCH,ROTARY 4 EA NS

4776-B SWITCH,ROTARY 1 EA NS

MS39060-2 SWITCH,ROTARY 4 EA NS

Subscribe to View Vendor Details...

47768 SWITCH,ROTARY 1 EA NS

Subscribe to View Vendor Details...

MS39060-2 SWITCH,ROTARY 2 EA NS

4776B SWITCH,ROTARY 2 EA NS

Subscribe to View Vendor Details...

MS39060 SWITCH,ROTARY 6 EA NS

Subscribe to View Vendor Details...

0624A0399 SWITCH,ROTARY 3 EA NS

MS-39060-2 SWITCH,ROTARY 1 EA NS

MS39060-2 SWITCH,ROTARY 21 EA NS

Subscribe to View Vendor Details...

28689606 SWITCH,ROTARY 89 EA NS

8380699MS39060-2 SWITCH,ROTARY 4 EA NS

Subscribe to View Vendor Details...

MS39060-2 SWITCH,ROTARY 7 EA NS

Subscribe to View Vendor Details...

MS39060-2 SWITCH,ROTARY 404 EA NS

Subscribe to View Vendor Details...

MS39060-2 SWITCH,ROTARY 1 EA NS

Subscribe to View Vendor Details...

5930-00-699-9438 SWITCH IGNITION 124 EA NS

Subscribe to View Vendor Details...

MS39060-2 SWITCH,ROTARY 3 EA NS

Subscribe to View Vendor Details...

MS39060-2 SWITCH,ROTARY 2 EA NS

8380699 SWITCH,ROTARY 1 EA NS

Subscribe to View Vendor Details...

4776-B SWITCH,ROTARY 5 EA NS

Subscribe to View Vendor Details...

MS39060-2 SWITCH,ROTARY 1 EA NS

Subscribe to View Vendor Details...

04776B SWITCH,ROTARY 54 EA NS

4776-B SWITCH,ROTARY 1 EA NS

Subscribe to View Vendor Details...

1549159 SWITCH,ROTARY 124 EA NS

006999438.5930 SWITCH,ROTARY 606 EA NS

Subscribe to View Vendor Details...

4776B SWITCH,ROTARY 8 EA NS

5930-00-699-9438 RQST NE

Updated Every Day

5930-00-699-9438 RQST

Updated Every Day

5930-00-699-9438 RQST NE

Restrictions 5930-00-699-9438

5930-00-699-9438 is a Rotary Switch that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item does not contain a precious metal.

Import and Export 5930-00-699-9438

Schedule B: Subscribe to View Schedule B
HTS Code: Subscribe to View HTS Code

End Users 5930-00-699-9438

US Army (A918)
Effective Date:: 1 Apr 2006
Former MOE Rule:: A196
Supplementary Receivers:: AZCTCLBD; AMC 1 AMSC G IMC Z IMCACTY CD

US Air Force (FXGX)
Effective Date:: 1 Apr 2006
Former MOE Rule:: FXTX; AMC 1 AMSC G IMC Z IMCACTY SX

US Marine Corps (MC49)
Effective Date:: 1 Apr 2006
Former MOE Rule:: MC13; AMC 1 AMSC G IMC Z IMCACTY PA

US Navy (N9BN)
Effective Date:: 1 Apr 2006
Former MOE Rule:: NIND
Supplementary Collaborators:: GTHD; AMC 1 AMSC G IMC Z IMCACTY GH

Austria (WB01)
Effective Date:: 1 Feb 2005

Lithuania (WI01)
Effective Date:: 1 Jun 2001

Poland (WP01)
Effective Date:: 1 Oct 2006

Brazil (YA01)
Effective Date:: 1 Jan 2002

Spain (YB01)
Effective Date:: 1 Apr 1991

Columbia (YC01)
Effective Date:: 1 Jul 2015

Israel (YD01)
Effective Date:: 1 Aug 2016

Singapore (YJ01)
Effective Date:: 1 Apr 1991

Kuwait (YK01)
Effective Date:: 1 Feb 2015

Morocco (YP01)
Effective Date:: 1 Nov 2008

Canada (ZC01)
Effective Date:: 1 Apr 1991

New Zealand (ZE01)
Effective Date:: 1 Apr 1991

France (ZF01)
Effective Date:: 1 Jun 2015

Republic of Korea (ZH01)
Effective Date:: 1 Apr 1991

Netherlands (ZN01)
Effective Date:: 1 Apr 1991

Portugal (ZP01)
Effective Date:: 1 Apr 1991

Denmark (ZS01)
Effective Date:: 1 Apr 1991

Greece (ZU01)
Effective Date:: 1 Apr 1991

Turkey (ZW01)
Effective Date:: 1 Nov 1998

Approved Sources 5930-00-699-9438

Part Number
Manufacturer
Status
MIL-DTL-13623/1-2: 81349 - Military Specifications (Active); Definitive Standard; RNCC 2 RNVC 2 DAC E
MIL-DTL-13623/1: 81349 - Military Specifications (Active); Incomplete Standard; RNCC 4 RNVC 1 DAC E
SAW-6999438: 1Y875 - Southern Automotive Wholesalers, Inc (Active); Incomplete Secondary Reference; RNCC 5 RNVC 1 DAC 5
4776B: 0ZSM8 - Ucom, Inc. (Active); Incomplete Secondary Reference; RNCC 5 RNVC 1 DAC 5
1998009: 16764 - General Motors Corp Delco Remy Div (Replaced); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
8002810: 61465 - Garwood/Feller Inc Garwood Winch Div (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
MS39060-2: 96906 - Military Standards (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 3
1998009: 24617 - General Motors Corp (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
MIL-S-13623: 81349 - Military Specifications (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 3
MIL-S-13623/1-2: 81349 - Military Specifications (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC E
5930006999438: SCY13 - E.C.A Etablissement (Replaced); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 9
4202629: 34161 - Koehring Co (Obsolete); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
8380699: 19207 - U S Army Tank Automotive Command (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
1998078: 24617 - General Motors Corp (Active); Advisory Reference; RNCC C RNVC 1 DAC 5
816047: 02280 - American Hoist And Derrick Co (Obsolete); Advisory Reference; RNCC C RNVC 1 DAC 5
B7829: 46717 - Pettibone Llc (Obsolete); Advisory Reference; RNCC C RNVC 1 DAC 4
0624A0399: 55207 - Arrow-Master, Incorporated (Active); Advisory Reference; RNCC C RNVC 1 DAC 5
3029296-5: 89926 - New Holland Construction (Active); Advisory Reference; RNCC C RNVC 1 DAC 3
1998078: 16764 - General Motors Corp Delco Remy Div (Replaced); Advisory Reference; RNCC C RNVC 1 DAC 5
189095: 29510 - Komatsu American Intl Co (Replaced); Advisory Reference; RNCC C RNVC 1 DAC 5
HCF12497: 40152 - Vme Americas Inc Sub Of Vme Group N (Replaced); Advisory Reference; RNCC C RNVC 1 DAC 5
X55210: 66717 - Wurlitzer Co The (Obsolete); Advisory Reference; RNCC C RNVC 1 DAC 5
SE575E: 03677 - Anthony York Co (Obsolete); Advisory Reference; RNCC C RNVC 1 DAC 5
4202629: 8E499 - Koehring Cranes And Excavators Inc (Obsolete); Advisory Reference; RNCC C RNVC 1 DAC 5
79Z1522: 27315 - Morris Material Handling, Inc. (Active); Advisory Reference; RNCC C RNVC 1 DAC 5
MS39060: 36024 - Libby Power Systems, Llc (Active); Advisory Reference; RNCC C RNVC 1 DAC 5
73029296: 6N299 - Agco Corp (Active); Advisory Reference; RNCC C RNVC 1 DAC 6
3029296: 0AHU0 - Kalmar Ac Inc (Active); Advisory Reference; RNCC C RNVC 1 DAC 5
177MAM1: 05415 - Linde Lift Truck Corp. (Replaced); Advisory Reference; RNCC C RNVC 1 DAC 5
5T1517: 99832 - Scott Huber Essick A Co Of Figgie (Obsolete); Advisory Reference; RNCC C RNVC 1 DAC 5
TC15-1444: 03677 - Anthony York Co (Obsolete); Advisory Reference; RNCC C RNVC 1 DAC 5
B7829: 13841 - Tiffin Parts, L.L.C. (Active); Advisory Reference; RNCC C RNVC 1 DAC 6
929134: 38018 - Manitowoc Engineering Co Division (Active); Advisory Reference; RNCC C RNVC 1 DAC 5
60089: 16004 - Davey Compressor Co Div Of Keco (Replaced); Advisory Reference; RNCC C RNVC 1 DAC 2
R25231: 10988 - Cnh Industrial America Llc (Active); Advisory Reference; RNCC C RNVC 1 DAC 5

Datasheet 5930-00-699-9438

Characteristic
Specifications
FIIG: A052B0
Contact Load Current Rating [CTHF]: 10.0 Amperes Resistive Load Dc At Sea Level And 10.0 Amperes Inductive Load Dc At Sea Level And 5.0 Amperes Lamp Load Dc At Sea Level
Contact Voltage Rating In Volts [CQMK]: 28.0 Dc At Sea Level
First Flat Length [ABNB]: 0.190 Inches Nominal Single Actuator
Hazardous Locations/Environmental Protection [ABFE]: Watertight
Mounting Method [AXGY]: Threaded Bushing Single Mounting Facility
Nominal Thread Size [CQJX]: 0.500 Inches Single Mounting Facility
Nonturn Device Radius [AEFP]: 0.625 Inches Nominal At 3:00 O'clock
Nonturn Device Type [AFDC]: Tab At 3:00 O'clock
Individual Section Quantity [AFBH]: 1
Shaft Diameter [ABWV]: 0.310 Inches Minimum Single Actuator And 0.314 Inches Maximum Single Actuator
Shaft Type [CRSJ]: Round, Parallel Flatted Single Actuator
Shaft Length [ABXF]: 0.380 Inches Nominal Single Actuator
Overall Diameter [ADAV]: 1.750 Inches Nominal
Overall Length [ABHP]: 3.520 Inches Nominal
Special Features [FEAT]: Threaded Hole In Shaft
Width Between Flats [AATB]: 0.214 Inches Minimum Single Actuator And 0.217 Inches Maximum Single Actuator
Specification/Standard Data [ZZZK]: 96906-Ms39060 Government Standard
Style Designator [STYL]: Snap Or Line
Switch Actuator Indexing Position Quantity [CRJH]: 2 Single Actuator
Switch Actuator Positioning Increment [CSLC]: 45.0 Degrees Single Actuator
Switch Contact Basic Design [AJZE]: Nonpile-Up Nonsymmetrical
Terminal Type [CSCF]: Connector, Receptacle
Test Data Document [TEST]: 81349-Mil-S-13623 Specification (Includes Engineering Type Bulletins, Brochures,Etc., That Reflect Specification Type Data In Specification Format; Excludes Commercial Catalogs, Industry Directories, And Similar Trade Publications, Reflecting General Type Data On Certain Environmental And Performance Requirements And Test Conditions That Are Shown As "Typical", "Average", "Nominal", Etc.).
Thread Class [AAJD]: 2A Single Mounting Facility
Thread Length [AASA]: 0.560 Inches Nominal Single Mounting Facility
Thread Series Designator [THSD]: Unf Single Mounting Facility

Weapon Systems (WSDC) 5930-00-699-9438

Subscribe
View WSDC

Subscribe to View Weapon System Codes...

Subscribe
View Data

DLA Procurement Analysis 5930-00-699-9438

Last Stock Position:: 384 In Stock
DLA Administrative Lead Time:: Subscribe
DLA Production Lead Time:: Subscribe

Subscribe to View DLA Inventory and Forecast...

Management Data 5930-00-699-9438

Subscribe
View Prices

Effective Date: Organization; Unit of Issue; Unit Price; Qty Unit Pack
Oct 2022: Department of the Navy (DN); EA; Subscribe; 1
Oct 2021: Department of the Air Force (DF); EA; Subscribe; 1
Apr 2021: Department of the Air Force (DF); EA; Subscribe; 1
Feb 2021: US Marine Corps (DM); EA; Subscribe; 1
Oct 2019: Department of the Army (DA); EA; Subscribe; 1

Army

Materiel Category and Inventory Manager:

Q: Electronics Materiel (DLA/GSA Items)

Appropriation and Budget Activity:

2: Stock Fund Secondary Items

Management Inventory Segment:

2: Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.

Weapons System / End Item / Homogeneous Group:

00: DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item

Accounting Requirements:

X: Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.

Air Force

Fund:

SF: Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point

Budget:

9: 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors

Aggregation Code:

EH: ELECTRONIC COMPONENTS

Price Validation Code:

V: The current standard price has been validated.
The item has been analyzed in conjunction with the Zero Overpricing Program and is in the accepted price range.
The item was procured under open competition and under the competitive arena the price is considered fair and reasonable.
ZOP or Standard price challenges are permissible but must be supported by adequate justification.

Expendability Recoverability Repairability:

N: Expendable. Condemn at User. Stock Fund (except Munitions).

Navy

Cognizance:

9B: Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg

Marine Corps

Stores Account:

1: Stock Fund Account Item

Combat Essentiality:

5: Critical Repair Part to a Combat Essential End Item

Echelon Management:

B2

Material Identification:

B: Consumable Repair Parts

Operational Test:

: No Special Procedures

Similar Supply Items to 5930-00-699-9438

Freight Information 5930-00-699-9438

5930-00-699-9438 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061300. A Sub NMFC of X. It has a NMFC Description of CIRCUIT BREAKER/SWITCH NOI. 5930-00-699-9438 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34410 which rates the freight between FCL and LCL. 5930-00-699-9438 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 72D for ocean manifesting and military sealift. 5930-00-699-9438 is not classified as a special type of cargo when transported by water. 5930-00-699-9438 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.

Packaging Data 5930-00-699-9438

Responsible Activity
Packaging Data Source: Primary Inventory Control Activity (PICA); --

Item Pack Level (Unpackaged)

Item Size
Item Weight
Characteristics
Weight/Dimensions Category
Fragility
Item Preservation: --; --; --; --; --

Unit Pack Level (Packaged)

Quantity per Pack
Unit Size
Unit Weight
Unit Cube
Preservation Method
Cleaning/Drying: 1; --; --; --; --; Any Suitable Process

Preservation Material
Wrapping Material
Cushioning/Dunnage
Cushioning Thickness
Container
Special Marking: No Requirement; --; --; --; --; No special marking

Intermediate Pack Level

Quantity of Unit Packs
Container: Any Suitable Fiber Box

Procurement History 5930-00-699-9438 Most Recent 60 Records

Subscribe
View Prices

Contract: Date; CAGE; Quantity; Net Price; Std Price
SPE7M118F8A15: 29 Aug 2018; Subscribe; 1; Subscribe; Subscribe
SPE7M118F7U62: 28 Aug 2018; Subscribe; 3; Subscribe; Subscribe
SPE7M118F6A50: 14 Aug 2018; Subscribe; 1; Subscribe; Subscribe
SPE7M118F97XF: 21 Jun 2018; Subscribe; 1; Subscribe; Subscribe
SPE7M118F87UF: 05 Jun 2018; Subscribe; 80; Subscribe; Subscribe
SPE7M118F81MY: 23 May 2018; Subscribe; 10; Subscribe; Subscribe
SPE7M118F4646: 13 Oct 2017; Subscribe; 1; Subscribe; Subscribe
SPE7L117D001263MK: 21 Sep 2017; Subscribe; 1; Subscribe; Subscribe
SPE7L117D001246XR: 22 Aug 2017; Subscribe; 1; Subscribe; Subscribe
SPE7L117D001213ZM: 28 Jun 2017; Subscribe; 5; Subscribe; Subscribe
SPE7L117D001212YB: 27 Jun 2017; Subscribe; 1; Subscribe; Subscribe
SPE7L117D001205ES: 13 Jun 2017; Subscribe; 1; Subscribe; Subscribe
SPE7L117D001224T3: 07 Apr 2017; Subscribe; 1; Subscribe; Subscribe
SPE7L117D001212H0: 29 Mar 2017; Subscribe; 39; Subscribe; Subscribe
SPE7L117D0012464A: 10 Feb 2017; Subscribe; 43; Subscribe; Subscribe
SPE7L117D00128897: 04 Jan 2017; Subscribe; 1; Subscribe; Subscribe
SPE7L117D00126857: 23 Dec 2016; Subscribe; 1; Subscribe; Subscribe
SPE7L117D00123608: 14 Dec 2016; Subscribe; 1; Subscribe; Subscribe
SPE7L116D000349XP: 21 Nov 2016; Subscribe; 1; Subscribe; Subscribe
SPE7L116D000344AH: 10 Nov 2016; Subscribe; 1; Subscribe; Subscribe
SPE7L116D000330YE: 19 Oct 2016; Subscribe; 1; Subscribe; Subscribe
SPE7L116D000324MD: 03 Oct 2016; Subscribe; 1; Subscribe; Subscribe
SPE7L116D000322MQ: 27 Sep 2016; Subscribe; 1; Subscribe; Subscribe
SPE7L116D000306PL: 07 Sep 2016; Subscribe; 34; Subscribe; Subscribe
SPE7L116D000394G9: 18 Aug 2016; Subscribe; 1; Subscribe; Subscribe
SPE7L116D000378B4: 07 Aug 2016; Subscribe; 1; Subscribe; Subscribe
SPE7L116D0003990J: 07 Jun 2016; Subscribe; 2; Subscribe; Subscribe
SPE7L116D00031940: 26 Feb 2016; Subscribe; 22; Subscribe; Subscribe
SPE7L115D001145EG: 15 Jan 2016; Subscribe; 1; Subscribe; Subscribe
SPE7L115D001143UJ: 13 Jan 2016; Subscribe; 1; Subscribe; Subscribe
SPE7L115D001118VT: 13 Nov 2015; Subscribe; 1; Subscribe; Subscribe
SPE7L115D001115FE: 07 Nov 2015; Subscribe; 1; Subscribe; Subscribe
SPE7L115D001103EX: 08 Oct 2015; Subscribe; 35; Subscribe; Subscribe
SPE7L115D001191T4: 23 Sep 2015; Subscribe; 2; Subscribe; Subscribe
SPE7L115D001178N9: 16 Sep 2015; Subscribe; 1; Subscribe; Subscribe
SPE7L115D001156C4: 31 Aug 2015; Subscribe; 2; Subscribe; Subscribe
SPE7L115D001113Y7: 28 Jul 2015; Subscribe; 1; Subscribe; Subscribe
SPE7L115D0011992V: 20 Jul 2015; Subscribe; 2; Subscribe; Subscribe
SPE7L115D0011957P: 17 Jul 2015; Subscribe; 2; Subscribe; Subscribe
SPE7L115D0011870A: 10 Jul 2015; Subscribe; 4; Subscribe; Subscribe
SPE7L115D0011168W: 14 May 2015; Subscribe; 20; Subscribe; Subscribe
SPE7L115D0011095B: 08 May 2015; Subscribe; 60; Subscribe; Subscribe
SPE7L114D000265VB: 20 Mar 2015; Subscribe; 1; Subscribe; Subscribe
SPE7L114D000264DA: 18 Mar 2015; Subscribe; 40; Subscribe; Subscribe
SPE7L114D000242VM: 12 Feb 2015; Subscribe; 2; Subscribe; Subscribe
SPE7L114D000242KF: 11 Feb 2015; Subscribe; 1; Subscribe; Subscribe
SPE7L114D000231NA: 27 Jan 2015; Subscribe; 1; Subscribe; Subscribe
SPE7L114D000224EN: 13 Jan 2015; Subscribe; 1; Subscribe; Subscribe
SPE7L114D000221WM: 08 Jan 2015; Subscribe; 1; Subscribe; Subscribe
SPE7L114D000219QY: 31 Dec 2014; Subscribe; 15; Subscribe; Subscribe
SPE7L114D000256T8: 15 Oct 2014; Subscribe; 10; Subscribe; Subscribe
SPE7L114D0002990S: 28 Aug 2014; Subscribe; 1; Subscribe; Subscribe
SPE7L114D0002983X: 28 Aug 2014; Subscribe; 1; Subscribe; Subscribe
SPE7L114D0002616J: 07 Aug 2014; Subscribe; 12; Subscribe; Subscribe
SPM7LX12D900567EW: 25 Feb 2013; Subscribe; 2; Subscribe; Subscribe
SPM7LX12D900566KY: 21 Feb 2013; Subscribe; 1; Subscribe; Subscribe
SPM7LX12D900565WB: 20 Feb 2013; Subscribe; 1; Subscribe; Subscribe
SPM7LX12D9005645Z: 12 Feb 2013; Subscribe; 1; Subscribe; Subscribe
SPM7LX12D900563YJ: 12 Feb 2013; Subscribe; 1; Subscribe; Subscribe
SPM7LX12D900562VG: 07 Feb 2013; Subscribe; 1; Subscribe; Subscribe

Contracting Technical Data File (CTDF) 5930-00-699-9438 October 2021

Criticality and Quality

Critical Item Code:: X
Flight Safety:
Life Support:
Certified Samples:
Serialization:
First Article Test (FAT):
Certificate of Quality Compliance:
Production Lot Testing:
Special Testing:
Qualified Products List (QPL):

Commercial Properties

Government Furnished Material:
Government Furnished Tooling:
Government Furnished Property:
Price Evaluation Code:
Diminshing Manufacturing Sources:
Warranty:
Commerical Off The Shelf (COTS):
End Item Application:
Auctioning Candidate:
Source of Procurement:
Contract Option:

Restrictions

Boeing Rights Guard:
Export Controlled:
Controlled Technical Data Package (TDP):
Restricted Technical Data Package (TDP):
Contains Classified Material
Weapons System Indicator Code (WSIC):: F

Packaging Requirements

Packaging Determination Table:
Packaging Review Code:
Special Packaging Instruction Number (SPIN):
Special Packaging Instruction Number Revision:
Special Packaging Instruction Number Date:
Pallet Reference Number Required:

Subscribe
View CTDF

Subscribe to View CTDF Details...

Marketplace 5930-00-699-9438

Related Documents 5930-00-699-9438 5+ Documents (More...)

Restrictions 5930-00-699-9438

Import and Export 5930-00-699-9438

End Users 5930-00-699-9438

Approved Sources 5930-00-699-9438

Datasheet 5930-00-699-9438

Weapon Systems (WSDC) 5930-00-699-9438

DLA Procurement Analysis 5930-00-699-9438

Management Data 5930-00-699-9438

Army

Air Force

Navy

Marine Corps

Similar Supply Items to 5930-00-699-9438

Freight Information 5930-00-699-9438

Packaging Data 5930-00-699-9438

Item Pack Level (Unpackaged)

Unit Pack Level (Packaged)

Intermediate Pack Level

Procurement History 5930-00-699-9438 Most Recent 60 Records

Contracting Technical Data File (CTDF) 5930-00-699-9438 October 2021

Criticality and Quality

Commercial Properties

Restrictions

Packaging Requirements
