5930-00-688-9882
Thermostatic Switch
5930006889882 006889882 MIL-DTL-12285/1 7771274-1 6401404 M12285/1-5 13205E3534 506AJ MIL-S-12285/1
A switch that is actuated by changes in ambient temperature. Excludes CIRCUIT BREAKER; CONTROL, TEMPERATURE (as modified); FUSE (as modified); PROTECTOR, THERMAL-OVERLOAD, ELECTRICAL MOTOR; RELAY, THERMAL; and THERMOSTAT, FLOW CONTROL. See also CONTROL, TEMPERATURE (as modified) and REGULATOR, TEMPERATURE (as modified). View more Thermostatic Switch
Managed by United States
NSN Created on 1 Jan 1961
Data Last Changed
May 2025
May 2025
NATO Update Count
41
41
NATO Data Quality
Marketplace 5930-00-688-9882
Need Help?
Request a Quotation from participating marketplace vendors
Request a Quotation from participating marketplace vendors
Related Documents 5930-00-688-9882 5+ Documents (More...)
MIL-DTL-12285/1 7771274-1 6401404 M12285/1-5 13205E3534 506AJ MIL-S-12285/1 A switch that is actuated
RQST NE Updated Every Day 5930-00-688-9882 RQST Updated Every Day 5930-00-688-9882 RQST NE Related
RQST Updated Every Day 5930-00-688-9882 RQST NE Related RQST Updated Every Day 5930-00-688-9882
RQST NE Updated Every Day 5930-00-688-9882 RQST Updated Every Day 5930-00-688-9882 RQST NE Related
RQST Updated Every Day 5930-00-688-9882 RQST NE Related RQST Updated Every Day 5930-00-688-9882
a day Upgrade your Account Upgrade 5930-01-143-6762Thermostatic Switch5930011436762 011436762 MIL-DTL-12285/1
M12285/1-4 MIL-S-12285/1 A switch that is actuated by changes in ambient temperature.
Thermostatic Switch 5930006889882 006889882, 7771274-1 6401404 M12285/1-5 13205E3534 506AJ MIL-S
M12285/1-4 MIL-S-12285/1 A switch that is actuated by changes in ambient temperature.
Thermostatic Switch 5930006889882 006889882, 7771274-1 6401404 M12285/1-5 13205E3534 506AJ MIL-S
a day Upgrade your Account Upgrade 5930-00-477-1116Thermostatic Switch5930004771116 004771116 MIL-DTL-12285/1
7771274-6 M12285/1-6 59304771116 MIL-S-12285/1 10087158 M1228516 A switch that is actuated by
MIL-DTL-12285/1 7771274 -12285/1 https//www.nsnlookup.com M12285/1-10 MIL-S-12285/1 A switch that is
7771274-6 M12285/1-6 59304771116 MIL-S-12285/1 10087158 M1228516 A switch that is actuated by
MIL-DTL-12285/1 7771274 -12285/1 https//www.nsnlookup.com M12285/1-10 MIL-S-12285/1 A switch that is
a day Upgrade your Account Upgrade 5930-00-881-9397Thermostatic Switch5930008819397 008819397 MIL-DTL-12285/1
www.nsnlookup.com /fsg-59/fsc-5920/uk 5920-99-956-3679 https//www.nsnlookup.com /fsg-59/fsc-5930/us 5930-00-688-9882
Thermostatic Switch 5930006889882 006889882, 7771274-1 6401404 M12285/1-5 13205E3534 506AJ MIL-S
www.nsnlookup.com /fsg-59/fsc-5920/uk 5920-99-956-3679 https//www.nsnlookup.com /fsg-59/fsc-5930/us 5930-00-688-9882
Thermostatic Switch 5930006889882 006889882, 7771274-1 6401404 M12285/1-5 13205E3534 506AJ MIL-S
a day Upgrade your Account Upgrade 5930-00-902-0193Thermostatic Switch5930009020193 009020193 MIL-S-12285/1
MIL-S-12285/1 Upgrade 5930-01-153-7559Thermostatic Switch5930011537559 011537559 MIL-DTL-12285/1 M12285
/1-10 MIL-S-12285/1 Thermostatic Switch 5930009020193009020193 day Upgrade your Account Upgrade 5930-
MIL-S-12285/1 Upgrade 5930-01-153-7559Thermostatic Switch5930011537559 011537559 MIL-DTL-12285/1 M12285
/1-10 MIL-S-12285/1 Thermostatic Switch 5930009020193009020193 day Upgrade your Account Upgrade 5930-
Restrictions 5930-00-688-9882
5930-00-688-9882 is a Thermostatic Switch that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
Import and Export 5930-00-688-9882
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5930-00-688-9882
- US Army (A918)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- A196
- Supplementary Receivers:
- AZCLBD
- US Air Force (FXGX)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- FXTX
- US Marine Corps (MC49)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- MC13
- US Navy (N9BN)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- N9ND
- Supplementary Collaborators:
- HD
- Austria (WB01)
- Effective Date:
- 1 Feb 2005
- Lithuania (WI01)
- Effective Date:
- 1 Jun 2001
- Brazil (YA01)
- Effective Date:
- 1 Mar 2001
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Israel (YD01)
- Effective Date:
- 1 Aug 2016
- Singapore (YJ01)
- Effective Date:
- 1 Apr 1991
- Morocco (YP01)
- Effective Date:
- 1 Nov 2008
- Australia (ZA01)
- Effective Date:
- 1 Apr 2012
- Belgium (ZB01)
- Effective Date:
- 1 Apr 1991
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
- New Zealand (ZE01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Portugal (ZP01)
- Effective Date:
- 1 Apr 1991
- Denmark (ZS01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Aug 1995
- Turkey (ZW01)
- Effective Date:
- 1 Aug 2004
Approved Sources 5930-00-688-9882
- Part Number
- Manufacturer
- Status
- M12285/1-5
- Manufacturer
- 81349 - Military Specifications (Active)
- Definitive Standard
- Definitive Standard
- MIL-DTL-12285/1
- 81349 - Military Specifications (Active)
- Incomplete Standard
- Incomplete Standard
- 5930006889882
- SCY13 - E.C.A Etablissement (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- MIL-S-12285/1
- 81349 - Military Specifications (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 5930006889882
- A00AM - E.C.A Etablissement Central Des (Active)
- NATO Reference
- NATO Reference
- 7771274-1
- 19207 - U S Army Tank Automotive Command (Active)
- Advisory Reference
- Advisory Reference
- 6401404
- 30379 - Euclid Inc (Obsolete)
- Advisory Reference
- Advisory Reference
- 6401404
- 97907 - Terex Corp (Obsolete)
- Advisory Reference
- Advisory Reference
- 13205E3534
- 97403 - Cecom Lr Center (Active)
- Transferred
- Transferred
- 506AJ
- 57733 - Stewart-Warner Corporation (Active)
- Transferred
- Transferred
Datasheet 5930-00-688-9882
- Characteristic
- Specifications
- FIIG
- Specifications
- A048B0
- Body Diameter [ABPM]
- 0.610 Inches Maximum
- Body Length [ADAQ]
- 1.390 Inches Nominal
- Contact Action Stimulus [CQGB]
- Increase
- Contact Adjustability [CTYC]
- Deactuation Point Not Adjustable And Actuation Point Not Adjustable
- Contact Load Current Rating [CTHF]
- 1.0 Amperes Resistive Load Single Voltage
- Contact Stimulus Rating [CTYX]
- 245.00 Actuation Point Nominal Degrees Fahrenheit And 215.00 Deactuation Point Nominal Degrees Fahrenheit
- Contact Voltage Rating In Volts [CTZB]
- 27.0 Dc At Sea Level Single Voltage
- Media For Which Designed [MEDA]
- Gas Or Liquid
- Mounting Method [AXGY]
- Threaded Bushing
- Nominal Thread Size [CQJX]
- 0.500 Inches Single Threaded Bushing
- Nonpile-Up Contact Arrangement [CRLD]
- 1 Pole, Single Throw, Normally Open, Momentary Action
- Overall Length [ABHP]
- 3.150 Inches Maximum
- Style Designator [STYL]
- Cylindrical W/Flange
- Width Across Flats [ASDB]
- 0.875 Inches Minimum And 0.940 Inches Maximum
- Specification/Standard Data [ZZZK]
- 81349-Mil-S-12285/1 Government Specification
- Temp Sensing Element Type [AKBY]
- Internal Sensor
- Terminal Type [CSCF]
- Connector, Receptacle
- Test Data Document [TEST]
- 81349-Mil-S-12285 Specification (Includes Engineering Type Bulletins, Brochures,Etc., That Reflect Specification Type Data In Specification Format; Excludes Commercial Catalogs, Industry Directories, And Similar Trade Publications, Reflecting General Type Data On Certain Environmental And Performance Requirements And Test Conditions That Are Shown As "Typical", "Average", "Nominal", Etc.).
- Thread Class [AAJD]
- 3B Single Threaded Bushing
- Thread Length [AASA]
- 0.760 Inches Nominal Single Threaded Bushing
- Thread Quantity Per Inch [CMLP]
- 14 Single Threaded Bushing
- Thread Series Designator [THSD]
- Nptf Single Threaded Bushing
Weapon Systems (WSDC) 5930-00-688-9882
DLA Procurement Analysis 5930-00-688-9882
- Last Stock Position:
- 121 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 5930-00-688-9882
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Jan 2023
- Defense Logistics Agency (DS)
- EA
- Subscribe
- 1
- EA
- Oct 2022
- US Marine Corps (DM)
- EA
- Subscribe
- 1
- EA
- Oct 2021
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
- Apr 2021
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
- Oct 2020
- US Marine Corps (DM)
- EA
- Subscribe
- 1
- EA
- Mar 2020
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
Army
- Materiel Category and Inventory Manager:
- Q
- Electronics Materiel (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 5
- Critical Repair Part to a Combat Essential End Item
- Echelon Management:
- B2
- Material Identification:
- T
- Maintenance Float Secondary Non-depot Reparables
- Operational Test:
- No Special Procedures
Similar Supply Items to 5930-00-688-9882
Freight Information 5930-00-688-9882
5930-00-688-9882 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 063160. A Sub NMFC of Z. It has a NMFC Description of SWITCH BOXES/ELEC ENCLOSURES. 5930-00-688-9882 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 35205 which rates the freight between FCL and LCL. 5930-00-688-9882 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 72D for ocean manifesting and military sealift. 5930-00-688-9882 is not classified as a special type of cargo when transported by water. 5930-00-688-9882 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5930-00-688-9882
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Bare Metal Item
- Over 10lb
- Less than 85G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- 5.0" H x 2.0" W x 2.0" L
- --
- --
- --
- Any Suitable Process
- 5.0" H x 2.0" W x 2.0" L
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- --
- --
- --
- --
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- Any Suitable Fiber Box
Procurement History 5930-00-688-9882 1 Records
Contracting Technical Data File (CTDF) 5930-00-688-9882 October 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- F
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
