5930-00-683-1626

Toggle Switch

5930006831626 006831626 MIL-DTL-3950 MS24523-30 8500K11SW1BN1000 644221006 46200-009-11 SC4023 65246BX 21TL1-6 MILS3950 5930PL0951458

A switch which is externally actuated by a lever and whose contacts open and close with an instantaneous (snap) action; includes items having one or more momentary positions. Includes switches (snap action) which use mercury to bridge contacts, and assemblages of complete switches (snap action) having common actuators. Excludes SWITCH, LEVER; SWITCH, ROTARY; SWITCH, KNIFE; SWITCH, SENSITIVE; and SWITCH, BOX. View more Toggle Switch

Managed by United States

NSN Created on 1 Jan 1963

Data Last Changed
November 2023

NATO Update Count
67

NATO Data Quality

5930-00-683-1626 SWITCH,TOGGLE 5930006831626 006831626 1/3 — 5930-00-683-1626 Photo 1/3

AAQL Style 5P for 5930-00-683-1626 2/3 — NSN 5930-00-683-1626 (Identification) 2/3

AFUQ Style 25 for 5930-00-683-1626 3/3 — NSN 5930-00-683-1626 (Identification) 3/3

Marketplace 5930-00-683-1626

Need Help?
Request a Quotation from participating marketplace vendors

Subscribe to View Vendor Details...

MS24523-30 SWITCH,TOGGLE 1 EA NS

Subscribe to View Vendor Details...

MS24523-30 SWITCH,TOGGLE 99 EA NS

Subscribe to View Vendor Details...

MS24523-30 SWITCH,TOGGLE RQST NS

Subscribe to View Vendor Details...

MS24523-30 SWITCH,TOGGLE 1 EA NS

Subscribe to View Vendor Details...

8500K11SW1BN1000 SWITCH,TOGGLE 1 EA NS

Subscribe to View Vendor Details...

MIL-S-3950 SWITCH,TOGGLE 151 EA NS

MS24523-30 SWITCH,TOGGLE 88 EA NS

Subscribe to View Vendor Details...

MS24523-30 Switch Toggle 845 EA NE

Subscribe to View Vendor Details...

1TL1-6 SWITCH,TOGGLE 1 EA NS

Subscribe to View Vendor Details...

5930-00-683-1626 SWITCH TOGGLE 1 EA NS

Subscribe to View Vendor Details...

MS24523-30 SWITCH,TOGGLE 1 EA NS

Subscribe to View Vendor Details...

MS24523-30 SWITCH,TOGGLE 6 EA NS

Subscribe to View Vendor Details...

MILS3950 SWITCH,TOGGLE 1 EA NS

MIL-S-3950 SWITCH,TOGGLE 11 EA NS

Subscribe to View Vendor Details...

MS24523-30 SWITCH,TOGGLE 7777 EA NS

Subscribe to View Vendor Details...

1549159 SWITCH,TOGGLE 1 EA NS

Subscribe to View Vendor Details...

8500K11 SWITCH,TOGGLE 1 EA NS

Updated Every Day

5930-00-683-1626 RQST NE

Updated Every Day

5930-00-683-1626 RQST

Updated Every Day

5930-00-683-1626 RQST NE

Restrictions 5930-00-683-1626

5930-00-683-1626 is a Toggle Switch that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item does not contain a precious metal.

Import and Export 5930-00-683-1626

Schedule B: Subscribe to View Schedule B
HTS Code: Subscribe to View HTS Code

End Users 5930-00-683-1626

US Army (A918)
Effective Date:: 1 Aug 2006
Former MOE Rule:: A196
Supplementary Receivers:: AJCTCLBFBDAZ; AMC 1 AMSC T IMC Z IMCACTY CD

US Air Force (FXGX)
Effective Date:: 1 Aug 2006
Former MOE Rule:: FXTX; AMC 1 AMSC T IMC Z IMCACTY SX

NASA (G860)
Effective Date:: 1 Jun 1994; AMC 0 AMSC 0 AAC C

US Marine Corps (MC49)
Effective Date:: 1 Aug 2006
Former MOE Rule:: MC13; AMC 1 AMSC T IMC Z IMCACTY PA

US Navy (N9BN)
Effective Date:: 1 Aug 2006
Former MOE Rule:: NIND
Supplementary Collaborators:: GTKEJBHXHD; AMC 1 AMSC T IMC Z IMCACTY GH

Austria (WB01)
Effective Date:: 1 Feb 2005

Slovenia (WL01)
Effective Date:: 1 Jan 2007

Poland (WP01)
Effective Date:: 1 Dec 2005

Brazil (YA01)
Effective Date:: 1 Sep 2000

Spain (YB01)
Effective Date:: 1 Apr 1991

Columbia (YC01)
Effective Date:: 1 Jul 2015

Israel (YD01)
Effective Date:: 1 Jun 2016

Singapore (YJ01)
Effective Date:: 1 Apr 1991

Kuwait (YK01)
Effective Date:: 1 Jan 2015

Morocco (YP01)
Effective Date:: 1 Nov 2008

Malaysia (YW01)
Effective Date:: 1 Jul 1994

Thailand (YY01)
Effective Date:: 1 Feb 2015

Australia (ZA01)
Effective Date:: 1 Apr 1991

Belgium (ZB01)
Effective Date:: 1 Apr 1991

Canada (ZC01)
Effective Date:: 1 Apr 1991

New Zealand (ZE01)
Effective Date:: 1 Apr 1991

France (ZF01)
Effective Date:: 1 Apr 1991

Germany (ZG01)
Effective Date:: 1 Apr 1991

Republic of Korea (ZH01)
Effective Date:: 1 Apr 1991

Netherlands (ZN01)
Effective Date:: 1 Apr 1991

Portugal (ZP01)
Effective Date:: 1 Aug 1997

Italy (ZR01)
Effective Date:: 1 Jul 1997

Denmark (ZS01)
Effective Date:: 1 Apr 1991

Norway (ZT01)
Effective Date:: 1 Apr 1991

Greece (ZU01)
Effective Date:: 1 Apr 1991

Turkey (ZW01)
Effective Date:: 1 Aug 1993

NATO Maintenance and Supply Agency (ZX01)
Effective Date:: 1 Apr 1991

Approved Sources 5930-00-683-1626

Part Number
Manufacturer
Status
MS24523-30: 96906 - Military Standards (Active); Definitive Standard; RNCC 2 RNVC 2 DAC E
MIL-DTL-3950: 81349 - Military Specifications (Active); Incomplete Standard; RNCC 4 RNVC 1 DAC E
MS24523-30: 0FW39 - Bae Systems Tactical Vehicle Systems (Active); Incomplete Secondary Reference; RNCC 5 RNVC 1 DAC 6
MS24523-30: 6M266 - Wesco Aircraft Hardware Corp. (Active); Incomplete Secondary Reference; RNCC 5 RNVC 1 DAC 6
MS24523-30: A9271 - Goriziane Group Spa (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 5
MILS3950: 81349 - Military Specifications (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 3
5930006831626: SCY13 - E.C.A Etablissement (Replaced); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 9
5930PL0951458: 9009H - Jednolity Indeks Materialowy - (Active); NATO Reference; RNCC 6 RNVC 9 DAC 9
8500K11SW1BN1000: 81640 - Safran Power Usa, Llc (Active); Advisory Reference; RNCC C RNVC 1 DAC 6
644221006: 55901 - Dare Electronics, Inc. (Active); Advisory Reference; RNCC C RNVC 1 DAC 9
MS24523-30: 81349 - Military Specifications (Active); Advisory Reference; RNCC C RNVC 1 DAC 6
46200-009-11: 31245 - Terex Usa, Llc (Active); Advisory Reference; RNCC C RNVC 1 DAC 6
SC4023: 32707 - Telair International Incorporated (Active); Advisory Reference; RNCC C RNVC 1 DAC 6
65246BX: 45152 - Oshkosh Corp (Active); Advisory Reference; RNCC C RNVC 1 DAC 5
21TL1-6: 91929 - Honeywell International Inc. (Active); Transferred; RNCC E RNVC 8 DAC 1

Datasheet 5930-00-683-1626

Characteristic
Specifications
FIIG: A053A0
End Item Identification [AGAV]: Mrap - Common Nsn - Used On 2 Mrap Variants And 134 Other Weapon Systems Including 21N - Nuclear Reactors Program
Actuator Height [AFUS]: 0.665 Inches Minimum And 0.695 Inches Maximum
Actuator Diameter [AFUR]: 0.237 Inches Minimum And 0.243 Inches Maximum
Actuator Position-Action Relationship [AFUX]: Up Position Maintained And Down Position Momentary
Actuator Style [AFUQ]: Round
Body Height [ADAU]: 0.890 Inches Minimum And 0.930 Inches Maximum
Body Length [ADAQ]: 1.270 Inches Maximum
Body Style [AAQL]: Bushing Mount
Body Width [ADAT]: 0.635 Inches Maximum
Bushing Length [ABXD]: 0.455 Inches Minimum And 0.485 Inches Maximum
Contact Load Current Rating At Maximum Rated Voltage [CXQR]: 15.000 Amperes Resistive Dc And 10.000 Amperes Inductive Dc And 4.000 Amperes Lamp Dc And 15.000 Amperes Resistive Ac And 7.000 Amperes Inductive Ac And 2.000 Amperes Lamp Ac
Features Provided [CBBL]: Actuator Seal
Hazardous Locations/Environmental Protection [ABFE]: Vaportight
Maximum Voltage Rating In Volts [AFXE]: 115.0 Ac And 28.0 Dc
Mounting Method [AXGY]: Threaded Bushing
Nominal Thread Size [CQJX]: 0.469 Inches
Nonpile-Up Contact Arrangement [CRLD]: 1 Pole, Single Throw, Normally Open, Momentary Action Single Switch Unit
Inclosure Type [AKNA]: Fully Inclosed
Overall Length [ABHP]: 1.270 Nominal Centimeters
Terminal Type And Quantity [TTQY]: 2 Screw
Test Data Document [TEST]: 81349-Mils-3950 Specification (Includes Engineering Type Bulletins, Brochures,Etc., That Reflect Specification Type Data In Specification Format; Excludes Commercial Catalogs, Industry Directories, And Similar Trade Publications, Reflecting General Type Data On Certain Environmental And Performance Requirements And Test Conditions That Are Shown As "Typical", "Average", "Nominal", Etc.).
Thread Quantity Per Inch [CMLP]: 32
Thread Series Designator [THSD]: Uns

Weapon Systems (WSDC) 5930-00-683-1626

Subscribe
View WSDC

Subscribe to View Weapon System Codes...

Subscribe
View Data

DLA Procurement Analysis 5930-00-683-1626

Last Stock Position:: 616 In Stock
DLA Administrative Lead Time:: Subscribe
DLA Production Lead Time:: Subscribe

Subscribe to View DLA Inventory and Forecast...

Management Data 5930-00-683-1626

Subscribe
View Prices

Effective Date: Organization; Unit of Issue; Unit Price; Qty Unit Pack
Dec 2022: US Coast Guard (GP); EA; Subscribe; 1
Oct 2022: US Marine Corps (DM); EA; Subscribe; 1
Nov 2021: US Coast Guard (GP); EA; Subscribe; 1
Oct 2021: Department of the Air Force (DF); EA; Subscribe; 1
Oct 2020: Department of the Air Force (DF); EA; Subscribe; 1
Mar 2020: Department of the Air Force (DF); EA; Subscribe; 1

Army

Materiel Category and Inventory Manager:

Q: Electronics Materiel (DLA/GSA Items)

Appropriation and Budget Activity:

2: Stock Fund Secondary Items

Management Inventory Segment:

2: Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.

Weapons System / End Item / Homogeneous Group:

4V: Communications System Agency and Satellite Communications Agency Equipment
Baseband Satellite Communication

Accounting Requirements:

X: Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.

Air Force

Fund:

SF: Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point

Budget:

9: 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors

Aggregation Code:

EH: ELECTRONIC COMPONENTS

Price Validation Code:

N: The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
The price has not been analyzed or reviewed for accuracy.
ZOP or Standard price challenges are permissible but must be supported with adequate justification. However, if coded for Local Purchase (LP) or Fabrication/Manufacture as indicated with an (LM) Acquisition Advice Code of “L” or “F”, then it must be evaluated locally where purchased or fabricated.

Expendability Recoverability Repairability:

N: Expendable. Condemn at User. Stock Fund (except Munitions).

Navy

Cognizance:

9B: Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg

Marine Corps

Stores Account:

1: Stock Fund Account Item

Combat Essentiality:

5: Critical Repair Part to a Combat Essential End Item

Echelon Management:

B2

Material Identification:

B: Consumable Repair Parts

Operational Test:

: No Special Procedures

Physical Category:

1: Bin

NATO Stock Numbers Related to 5930-00-683-1626

5930-14-578-1032 5930-23-112-5648 5930-99-764-3816 5930-12-322-6990 5930-12-180-1747 5930-99-748-6845 5930-99-735-7282 5930-12-178-3021 5930-12-302-2300 5930-99-750-8514 5930-40-000-3303 5930-99-804-9567 5930-57-441-2467 5930-99-470-0665 5930-12-352-3812 5930-21-898-8042 5930-99-631-5449 5930-99-713-1225

Freight Information 5930-00-683-1626

5930-00-683-1626 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061300. A Sub NMFC of X. It has a NMFC Description of CIRCUIT BREAKER/SWITCH NOI. 5930-00-683-1626 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34410 which rates the freight between FCL and LCL. 5930-00-683-1626 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 72D for ocean manifesting and military sealift. 5930-00-683-1626 is not classified as a special type of cargo when transported by water. 5930-00-683-1626 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.

Packaging Data 5930-00-683-1626

Responsible Activity
Packaging Data Source: Primary Inventory Control Activity (PICA); --

Item Pack Level (Unpackaged)

Item Size
Item Weight
Characteristics
Weight/Dimensions Category
Fragility
Item Preservation: --; --; --; Over 10lb; Less than 85G; Special Requirement

Unit Pack Level (Packaged)

Quantity per Pack
Unit Size
Unit Weight
Unit Cube
Preservation Method
Cleaning/Drying: 1; --; --; --; --; --

Preservation Material
Wrapping Material
Cushioning/Dunnage
Cushioning Thickness
Container
Special Marking: --; --; --; --; --; No special marking

Intermediate Pack Level

Quantity of Unit Packs
Container: See Method of Preservation; --

Procurement History 5930-00-683-1626 1 Records

Subscribe
View Prices

Contract: Date; CAGE; Quantity; Net Price; Std Price
SPE7M822P3617: 15 Jul 2022; Subscribe; 23; Subscribe; Subscribe

Contracting Technical Data File (CTDF) 5930-00-683-1626 October 2021

Criticality and Quality

Critical Item Code:: X
Flight Safety:
Life Support:
Certified Samples:
Serialization:
First Article Test (FAT):
Certificate of Quality Compliance:
Production Lot Testing:
Special Testing:
Qualified Products List (QPL):

Commercial Properties

Government Furnished Material:
Government Furnished Tooling:
Government Furnished Property:
Price Evaluation Code:
Diminshing Manufacturing Sources:
Warranty:
Commerical Off The Shelf (COTS):
End Item Application:
Auctioning Candidate:
Source of Procurement:
Contract Option:

Restrictions

Boeing Rights Guard:
Export Controlled:
Controlled Technical Data Package (TDP):
Restricted Technical Data Package (TDP):
Contains Classified Material
Weapons System Indicator Code (WSIC):: F

Packaging Requirements

Packaging Determination Table:
Packaging Review Code:: N
Special Packaging Instruction Number (SPIN):
Special Packaging Instruction Number Revision:
Special Packaging Instruction Number Date:
Pallet Reference Number Required:

Subscribe
View CTDF

Subscribe to View CTDF Details...

Marketplace 5930-00-683-1626

Related Documents 5930-00-683-1626 5+ Documents (More...)

Restrictions 5930-00-683-1626

Import and Export 5930-00-683-1626

End Users 5930-00-683-1626

Approved Sources 5930-00-683-1626

Datasheet 5930-00-683-1626

Weapon Systems (WSDC) 5930-00-683-1626

DLA Procurement Analysis 5930-00-683-1626

Management Data 5930-00-683-1626

Army

Air Force

Navy

Marine Corps

NATO Stock Numbers Related to 5930-00-683-1626

Freight Information 5930-00-683-1626

Packaging Data 5930-00-683-1626

Item Pack Level (Unpackaged)

Unit Pack Level (Packaged)

Intermediate Pack Level

Procurement History 5930-00-683-1626 1 Records

Contracting Technical Data File (CTDF) 5930-00-683-1626 October 2021

Criticality and Quality

Commercial Properties

Restrictions

Packaging Requirements
