5930-00-636-1302
Sensitive Switch
5930006361302 006361302 7984111 2CE21
A switch with a quick-acting mechanism actuated by a highly delicate tactile contact. Includes membrane switch. Excludes SWITCH, FLEXIBLE; SWITCH, PRESSURE; and SWITCH, THERMOSTATIC. View more Sensitive Switch
January 2023
15
Marketplace 5930-00-636-1302
Request a Quotation from participating marketplace vendors
Related Documents 5930-00-636-1302 5+ Documents (More...)
(Identification) 1/2 NSN 5930-00-636-1302 (Identification) 2/2 - - 1.
RQST NE Updated Every Day 5930-00-636-1302 RQST Updated Every Day 5930-00-636-1302 RQST NE Related
Sensitive Switch 5930006361302 006361302 Updated Every Day 5930-00-636-1302 RQST NE Related https
Sensitive Switch 5930006361302 006361302 Day 5930-00-636-1302 RQST NE Related https https https
Sensitive Switch 5930006361302 006361302 Every Day 5930-00-636-1302 RQST NE Related https https
Sensitive Switch 5930006361302 006361302 cable assembly, special purpose, electrical. https https
Restrictions 5930-00-636-1302
5930-00-636-1302 is a Sensitive Switch that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
Import and Export 5930-00-636-1302
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5930-00-636-1302
- Austria (WB01)
- Effective Date:
- 1 Feb 2005
- Spain (YB01)
- Effective Date:
- 1 Feb 1994
- Greece (ZU01)
- Effective Date:
- 1 Aug 1995
- Turkey (ZW01)
- Effective Date:
- 1 Sep 2009
Approved Sources 5930-00-636-1302
- Part Number
- Manufacturer
- Status
- 2CE21
- Manufacturer
- 91929 - Honeywell International Inc. (Active)
- Primary Buy
- Primary Buy
- 7984111
- 19207 - U S Army Tank Automotive Command (Active)
- Secondary Buy
- Secondary Buy
- 2CE21
- 84523 - First Industrial Corp (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5930-00-636-1302
- Characteristic
- Specifications
- FIIG
- Specifications
- A053A0
- Actuator Free Position Height [AFUU]
- 1.318 Inches Nominal
- Actuator Diameter [AFUR]
- 0.330 Inches Nominal
- Actuator Style [AFUQ]
- Round
- Body Style [AAQL]
- Hole Mounted
- Center To Center Distance Between Housing Mounting Facilities Parallel To Length [AFWH]
- 2.625 Inches Nominal
- Center To Center Distance Between Housing Mounting Facilities Parallel To Width [AFWJ]
- 0.875 Inches Nominal
- Contact Load Current Rating At Maximum Rated Voltage [CXQR]
- 3.000 Amperes Resistive Dc
- Housing Length [AFWD]
- 3.440 Inches Nominal
- Housing Width [AFWE]
- 1.440 Inches Nominal
- Maximum Voltage Rating In Volts [AFXE]
- 28.0 Dc
- Nonpile-Up Contact Arrangement [CRLD]
- 1 Pole, Double Throw, One Position Momentary Single Switch Unit
- Inclosure Type [AKNA]
- Fully Inclosed
- Overall Height [ABKW]
- 4.240 Inches Nominal
- Overall Length [ABHP]
- 3.500 Inches Nominal
- Overall Width [ABMK]
- 1.440 Inches Nominal
- Switch Actuating Force [CSJN]
- 28.0 Ounces Minimum And 60.0 Ounces Maximum
- Terminal Type And Quantity [TTQY]
- 1 Cable W/Connector
Similar Supply Items to 5930-00-636-1302
Freight Information 5930-00-636-1302
5930-00-636-1302 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061300. A Sub NMFC of X. It has a NMFC Description of CIRCUIT BREAKER/SWITCH NOI. 5930-00-636-1302 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. 5930-00-636-1302 is rated as class 77.5 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 34410 which rates the freight between FCL and LCL. 5930-00-636-1302 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 658 for ocean manifesting and military sealift. 5930-00-636-1302 is not classified as a special type of cargo when transported by water. 5930-00-636-1302 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
