5930-00-548-8582
Rotary Switch
5930005488582 005488582 02617P 25058-53 682A
A switch actuated by a definite angular rotation of the switch shaft about its axis. For items having rated actuation travel and pressure characteristics, see SWITCH, SENSITIVE. Excludes RELAY, ROTARY; SWITCH, STEPPING; and SWITCH, TELEPHONE (as modified). View more Rotary Switch
January 2023
8
Marketplace 5930-00-548-8582
Request a Quotation from participating marketplace vendors
Related Documents 5930-00-548-8582 5+ Documents (More...)
RQST NE Updated Every Day 5930-00-548-8582 RQST Updated Every Day 5930-00-548-8582 RQST NE Related Documents
5930-00-548-8582 5+ Documents ( More... ) https//www.nsnlookup.com /fsg-59/fsc-5930/us 5930-00-548-8582
15-077-4039 Chiave A Tubo 1045150774039 150774039,682A 506-4067 Part NumberManufacturerStatus27417F-682A
-548-8582 Rotary Switch 5930005488582 005488582,02617P 27-051-1259 https//www.nsnlookup.com /fsg-59/
G.05581-682A INSULATOR,SPECIAL 15 EA NS Request Quotation Updated Every Day 5970-01-072-7222 RQST NE
G.05581-682A INSULATOR,SPECIAL 15 EA NS Request Quotation https//www.nsnlookup.com /fsg-62/fsc-6210/
your web browser . 8010-99-545-0861Lacquer8010995450861 995450861 F65150 01743-00011 101743-00011 682A
Rotary Switch 5930005488582 005488582,02617P Upgrade your Account Upgrade 5930-00-548-8582Rotary
enable JavaScript in your web browser . 6220-27-051 -1259Electric Floodlight6220270511259 270511259YR-682A
enable JavaScript in your web browser . 6220-27-051 -1259Electric Floodlight6220270511259 270511259YR-682A
Restrictions 5930-00-548-8582
5930-00-548-8582 is a Rotary Switch that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
End Users 5930-00-548-8582
- Greece (ZU01)
- Effective Date:
- 1 Aug 1995
Approved Sources 5930-00-548-8582
- Part Number
- Manufacturer
- Status
- 02617P
- Manufacturer
- 15556 - Ricoh Americas Corporation (Active)
- Primary Buy
- Primary Buy
- 25058-53
- 76854 - Electro Switch Corp. (Active)
- Primary Buy
- Primary Buy
- 682A
- 79219 - Waters Conley Co (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5930-00-548-8582
- Characteristic
- Specifications
- FIIG
- Specifications
- A052B0
- Style Designator [STYL]
- Semi-Circular Wafer, Bushing Mount
- Overall Length [ABHP]
- 1.813 Inches Nominal
- Overall Height [ABKW]
- 1.438 Inches Nominal
- Overall Width [ABMK]
- 1.375 Inches Nominal
- Individual Section Quantity [AFBH]
- 1
- Switch Contact Basic Design [AJZE]
- Nonpile-Up Symmetrical
- Pole Quantity [AKPX]
- 1 Single Section Rear
- Throw Quantity [AKPY]
- 5 Single Section Rear
- Contact Switching Action [CSHW]
- Makes Before Breaks Single Section Rear
- Switch Actuator Indexing Position Quantity [CRJH]
- 5 Single Actuator
- Switch Actuator Positioning Increment [CSLC]
- 30.0 Degrees Single Actuator
- Shaft Type [CRSJ]
- Round Single Actuator
- Shaft Diameter [ABWV]
- 0.250 Inches Nominal Single Actuator
- Shaft Length [ABXF]
- 0.875 Inches Nominal Single Actuator
- Terminal Type [CSCF]
- Tab, Solder Lug
- Mounting Method [AXGY]
- Threaded Bushing Single Mounting Facility
- Thread Series Designator [THSD]
- Unef Single Mounting Facility
- Nominal Thread Size [CQJX]
- 0.375 Inches Single Mounting Facility
- Thread Length [AASA]
- 0.375 Inches Nominal Single Mounting Facility
NATO Stock Numbers Related to 5930-00-548-8582
Freight Information 5930-00-548-8582
5930-00-548-8582 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061300. A Sub NMFC of X. It has a NMFC Description of CIRCUIT BREAKER/SWITCH NOI. 5930-00-548-8582 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34410 which rates the freight between FCL and LCL. 5930-00-548-8582 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 723 for ocean manifesting and military sealift. 5930-00-548-8582 is not classified as a special type of cargo when transported by water. 5930-00-548-8582 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5930-00-548-8582
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- 0.25 lb or less, one dimension 2" or less, other dimensions less than 24"
- 85 to 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- --
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- No Requirement
- Not Applicable
- PPP-B-566 or PPP-B-676, Folding or Setup Box
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- Any Suitable Fiber Box
