5930-00-409-0785
Rotary Switch
5930004090785 004090785 11664684 1071 D832 01071
A switch actuated by a definite angular rotation of the switch shaft about its axis. For items having rated actuation travel and pressure characteristics, see SWITCH, SENSITIVE. Excludes RELAY, ROTARY; SWITCH, STEPPING; and SWITCH, TELEPHONE (as modified). View more Rotary Switch
Managed by United States
NSN Created on 22 Jul 1970
Data Last Changed
August 2025
August 2025
NATO Update Count
30
30
NATO Data Quality
Marketplace 5930-00-409-0785
Need Help?
Request a Quotation from participating marketplace vendors
Request a Quotation from participating marketplace vendors
Related Documents 5930-00-409-0785 5+ Documents (More...)
https//www.nsnlookup.com
/fsg-59/fsc-5930/us
/fsg-59/fsc-5930/us
5930-00-409-0785 Rotary Switch 5930004090785 004090785,
11664684 1071 D832 01071 A switch actuated by a definite angular rotation of the switch shaft about
-1L Germany (DE) 4. 8010 https -5930/us 5930-00-409-0785 Rotary https//www.nsnlookup.com /fsg-80 D832
Products Thinner 8010123927173,D832-1L ,D832 Products Thinner 8010123927173,D832-1L Paint ,D832-1L https
-1L Germany (DE) 4. 8010 https -5930/us 5930-00-409-0785 Rotary https//www.nsnlookup.com /fsg-80 D832
Products Thinner 8010123927173,D832-1L ,D832 Products Thinner 8010123927173,D832-1L Paint ,D832-1L https
Subscribe to View Vendor Details... 1309 SWITCH https//www.nsnlookup.com /fsg-59/fsc-5930/us 5930-00-409-0785
Rotary Switch 5930004090785 004090785, Items to 5930-00-409-0785 5930-00-152-8212 5930-00-306-0823
Items to 5930-01-098-6743 5930-00-152-8212 5930-00-306-0823 5930-00-269-9825 5930-00-207-9422 5930-00-409-0785
Rotary Switch 5930004090785 004090785, Items to 5930-00-409-0785 5930-00-152-8212 5930-00-306-0823
Items to 5930-01-098-6743 5930-00-152-8212 5930-00-306-0823 5930-00-269-9825 5930-00-207-9422 5930-00-409-0785
,D832-1L Paint Products Thinner 8010123927173 ,D832 -1L Paint Products Thinner 8010123927173 ,D832-1L
8010123927173,D832-1L Paint Products ,D832-1L Germany (DE) 4. -1L D832 -1L Paint Products /fsg Paint
Products Thinner 8010123927173,D832-1L ,D832 Products Thinner 8010123927173,D832-1L Paint ,D832-1L https
8010123927173,D832-1L Paint Products ,D832-1L Germany (DE) 4. -1L D832 -1L Paint Products /fsg Paint
Products Thinner 8010123927173,D832-1L ,D832 Products Thinner 8010123927173,D832-1L Paint ,D832-1L https
-1L Thinner 8010123927173,D832-1L Paint Products ,D832-1L Germany (DE) 4. -1L D832 -1L Paint Products
Switch 5930142160473142160473,D832 8145143678621 143678621,832,D832 ,D832 how to enable JavaScript ,
D832-1L Paint Products Thinner -1L D832 -1L Paint Products Thinner 8010123927173 ,D832-1L Germany (DE
Switch 5930142160473142160473,D832 8145143678621 143678621,832,D832 ,D832 how to enable JavaScript ,
D832-1L Paint Products Thinner -1L D832 -1L Paint Products Thinner 8010123927173 ,D832-1L Germany (DE
Items to 9999-22-605-7557 5930-00-152-8212 5930-00-306-0823 5930-00-269-9825 5930-00-207-9422 5930-00-409-0785
Restrictions 5930-00-409-0785
5930-00-409-0785 is a Rotary Switch that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
Import and Export 5930-00-409-0785
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5930-00-409-0785
- US Army (A918)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- A196
- Supplementary Receivers:
- AZCLBD
- US Air Force (FXGX)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- FXTX
- US Marine Corps (MC49)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- MC13
- US Navy (N9BN)
- Effective Date:
- 1 Dec 2013
- Supplementary Collaborators:
- GG
- Columbia (YC01)
- Effective Date:
- 1 Jul 2015
- Kuwait (YK01)
- Effective Date:
- 1 Jan 2015
- Morocco (YP01)
- Effective Date:
- 1 Nov 2008
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
- New Zealand (ZE01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Portugal (ZP01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Aug 1995
- Turkey (ZW01)
- Effective Date:
- 1 Nov 2005
Approved Sources 5930-00-409-0785
- Part Number
- Manufacturer
- Status
- 11664684
- Manufacturer
- 19207 - U S Army Tank Automotive Command (Active)
- Primary Buy
- Primary Buy
- 1071
- 0ZSM8 - Ucom, Inc. (Active)
- Secondary Buy
- Secondary Buy
- 11664684
- 1Y875 - Southern Automotive Wholesalers, Inc (Active)
- Secondary Buy
- Secondary Buy
- 5930004090785
- SCY13 - E.C.A Etablissement (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- 1071
- 81263 - Universal Components Corp (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- D832
- 81263 - Universal Components Corp (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- 01071
- 81263 - Universal Components Corp (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- 5930004090785
- A00AM - E.C.A Etablissement Central Des (Active)
- NATO Reference
- NATO Reference
Datasheet 5930-00-409-0785
- Characteristic
- Specifications
- FIIG
- Specifications
- A052B0
- Cam Actuated Switch Contact Arrangement [CQYS]
- 1 Pole, Single Throw, Both Positions Maintained Single Switch Single Section Rear
- Contact Load Current Rating [CTHF]
- 40.0 Amperes Resistive Load Dc At Sea Level And 20.0 Amperes Inductive Load Dc At Sea Level
- Contact Voltage Rating In Volts [CQMK]
- 30.0 Dc At Sea Level
- Contact Switching Action [CSHW]
- Breaks Before Makes Single Section Rear
- Features Provided [CBBL]
- Cam Actuated
- Hazardous Locations/Environmental Protection [ABFE]
- Dustproof
- Mounting Method [AXGY]
- Threaded Bushing Single Mounting Facility
- Nominal Thread Size [CQJX]
- 0.500 Inches Single Mounting Facility
- Nonturn Device Radius [AEFP]
- 0.610 Inches Minimum At 3:00 O'clock And 0.640 Inches Maximum At 3:00 O'clock
- Nonturn Device Type [AFDC]
- Pin At 3:00 O'clock
- Individual Section Quantity [AFBH]
- 1
- Shaft Diameter [ABWV]
- 0.250 Inches Nominal Single Actuator
- Shaft Type [CRSJ]
- Round Single Actuator
- Shaft Length [ABXF]
- 0.375 Inches Nominal Single Actuator
- Overall Diameter [ADAV]
- 1.780 Inches Maximum
- Overall Length [ABHP]
- 3.655 Inches Nominal
- Style Designator [STYL]
- Snap Or Line
- Switch Actuator Indexing Position Quantity [CRJH]
- 2 Single Actuator
- Switch Actuator Positioning Increment [CSLC]
- 45.0 Degrees Single Actuator
- Switch Actuator Stop Device Type [CTDN]
- Fixed Stop Single Actuator
- Switch Contact Basic Design [AJZE]
- Nonpile-Up Nonsymmetrical
- Terminal Type [CSCF]
- Connector, Plug
- Thread Class [AAJD]
- 2A Single Mounting Facility
- Thread Length [AASA]
- 0.560 Inches Nominal Single Mounting Facility
- Thread Series Designator [THSD]
- Unf Single Mounting Facility
Weapon Systems (WSDC) 5930-00-409-0785
DLA Procurement Analysis 5930-00-409-0785
- Last Stock Position:
- 38 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 5930-00-409-0785
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Oct 2022
- Defense Logistics Agency (DS)
- EA
- Subscribe
- 1
- EA
- Oct 2021
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
- Apr 2021
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
- Feb 2021
- US Marine Corps (DM)
- EA
- Subscribe
- 1
- EA
- Feb 2020
- Department of the Army (DA)
- EA
- Subscribe
- 1
- EA
Army
- Materiel Category and Inventory Manager:
- Q
- Electronics Materiel (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Air Force
- Fund:
- SF
- Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point
- Budget:
- 9
- 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors
- Aggregation Code:
- EH
- ELECTRONIC COMPONENTS
- Price Validation Code:
- V
- The current standard price has been validated.
The item has been analyzed in conjunction with the Zero Overpricing Program and is in the accepted price range.
The item was procured under open competition and under the competitive arena the price is considered fair and reasonable.
ZOP or Standard price challenges are permissible but must be supported by adequate justification.
- Expendability
Recoverability
Repairability: - N
- Expendable. Condemn at User. Stock Fund (except Munitions).
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 5
- Critical Repair Part to a Combat Essential End Item
- Echelon Management:
- B2
- Material Identification:
- B
- Consumable Repair Parts
- Operational Test:
- No Special Procedures
Similar Supply Items to 5930-00-409-0785
Freight Information 5930-00-409-0785
5930-00-409-0785 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061300. A Sub NMFC of X. It has a NMFC Description of CIRCUIT BREAKER/SWITCH NOI. 5930-00-409-0785 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34410 which rates the freight between FCL and LCL. 5930-00-409-0785 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 72D for ocean manifesting and military sealift. 5930-00-409-0785 is not classified as a special type of cargo when transported by water. 5930-00-409-0785 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5930-00-409-0785
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- Over 10lb
- Less than 85G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- --
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- --
- --
- --
- --
- --
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- See Method of Preservation
- --
Procurement History 5930-00-409-0785 2 Records
Contracting Technical Data File (CTDF) 5930-00-409-0785 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- F
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
