5930-00-252-3454
Sensitive Switch
5930002523454 002523454 DXGB5
A switch with a quick-acting mechanism actuated by a highly delicate tactile contact. Includes membrane switch. Excludes SWITCH, FLEXIBLE; SWITCH, PRESSURE; and SWITCH, THERMOSTATIC. View more Sensitive Switch
January 2023
8
Marketplace 5930-00-252-3454
Request a Quotation from participating marketplace vendors
Related Documents 5930-00-252-3454 1+ Documents (More...)
United States (US) 4. 5930-00-252-3454 Marketplace Restrictions Approved Sources Datasheet Management
Every Day 5930-00-252-3454 RQST Updated Every Day 5930-00-252-3454 RQST NE Related Documents 5930-00-
Restrictions 5930-00-252-3454
5930-00-252-3454 is a Sensitive Switch that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
Import and Export 5930-00-252-3454
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5930-00-252-3454
- Portugal (ZP01)
- Effective Date:
- 1 Apr 1991
Approved Sources 5930-00-252-3454
- Part Number
- Manufacturer
- Status
- DXGB5
- Manufacturer
- 80411 - Robertshaw Controls Co New Stanton (Obsolete)
- Original Design
- Original Design
Datasheet 5930-00-252-3454
- Characteristic
- Specifications
- FIIG
- Specifications
- A053A0
- Actuator Height [AFUS]
- 0.781 Inches Nominal
- Actuator Adapter Style [AFVV]
- Pushbutton
- Actuator Diameter [AFUR]
- 0.500 Inches Nominal
- Actuator Movement [CXQQ]
- 0.125 Pretravel Inches Maximum And 0.094 Overtravel Inches Minimum And 0.050 Differential Inches Maximum
- Body Width [ADAT]
- 0.875 Inches Nominal
- Center To Center Distance Between Adapter Mounting Facilities Parallel To Length [AFVY]
- 2.250 Inches Nominal
- Center To Center Distance Between Mounting Facilities Parallel To Length [ABKQ]
- 2.250 Inches Nominal
- Contact Load Current Rating At Maximum Rated Voltage [CXQR]
- 30.000 Amperes Resistive Dc
- Maximum Voltage Rating In Volts [AFXE]
- 28.0 Dc
- Nominal Thread Size [CQJX]
- 0.138 Inches
- Switch Actuating Force [CSJN]
- 48.0 Ounces Maximum
- Terminal Type And Quantity [TTQY]
- 2 Screw
- Thread Series Designator [THSD]
- Unf
NATO Stock Numbers Related to 5930-00-252-3454
Freight Information 5930-00-252-3454
5930-00-252-3454 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061300. A Sub NMFC of X. It has a NMFC Description of CIRCUIT BREAKER/SWITCH NOI. 5930-00-252-3454 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. 5930-00-252-3454 is rated as class 77.5 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 34410 which rates the freight between FCL and LCL. 5930-00-252-3454 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 658 for ocean manifesting and military sealift. 5930-00-252-3454 is not classified as a special type of cargo when transported by water. 5930-00-252-3454 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
