5930-00-249-2927
Rotary Switch
5930002492927 002492927 12Z13116-1062 1413 512011PIECE3
A switch actuated by a definite angular rotation of the switch shaft about its axis. For items having rated actuation travel and pressure characteristics, see SWITCH, SENSITIVE. Excludes RELAY, ROTARY; SWITCH, STEPPING; and SWITCH, TELEPHONE (as modified). View more Rotary Switch
May 2023
15
Marketplace 5930-00-249-2927
Request a Quotation from participating marketplace vendors
Related Documents 5930-00-249-2927 5+ Documents (More...)
Photo 1/3 5930-00-249-2927 Photo 2/3 NSN 5930-00-249-2927 (Identification) 3/3 - - - 1.
1413 SWITCH,ROTARY 13 EA NS Request Quotation Updated Every Day 5930-00-249-2927 RQST NE Updated Every
Restrictions 5930-00-249-2927
5930-00-249-2927 is a Rotary Switch that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item contains Silver.
Import and Export 5930-00-249-2927
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5930-00-249-2927
- US Navy (N9BN)
- Effective Date:
- 1 Nov 2005
- Former MOE Rule:
- NIND
- Supplementary Collaborators:
- HD
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
- Germany (ZG01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Denmark (ZS01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
Approved Sources 5930-00-249-2927
- Part Number
- Manufacturer
- Status
- 12Z13116-1062
- Manufacturer
- 94135 - Naval Ordnance Standards (Active)
- Definitive Standard
- Definitive Standard
- 1413
- 71590 - Crl Components Inc (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- 512011PIECE3
- 10001 - Navair And Navsea Managed Original (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5930-00-249-2927
- Characteristic
- Specifications
- FIIG
- Specifications
- A052B0
- Contact Load Current Rating [CTHF]
- 2.3 Amperes Resistive Load Dc At Sea Level
- Contact Load Current Rating [CTHF]
- 350.0 Milliamperes Resistive Load Ac At Sea Level
- Contact Voltage Rating In Volts [CQMK]
- 28.0 Dc At Sea Level
- Contact Switching Action [CSHW]
- Breaks Before Makes Each Section Rear
- Contact Voltage Rating In Volts [CQMK]
- 115.0 Ac At Sea Level
- Mounting Method [AXGY]
- Threaded Bushing Single Mounting Facility
- Nominal Thread Size [CQJX]
- 0.375 Inches Single Mounting Facility
- Nonturn Device Radius [AEFP]
- 0.531 Inches Nominal At 9:00 O'clock
- Nonturn Device Type [AFDC]
- Tab At 9:00 O'clock
- Individual Section Quantity [AFBH]
- 2
- Pole Quantity [AKPX]
- 1 Each Section Rear
- Precious Material And Location [PMLC]
- Clips And Rotor Surfaces Silver
- Precious Material [PRMT]
- Silver
- Shaft Diameter [ABWV]
- 0.250 Inches Nominal Single Actuator
- Shaft Type [CRSJ]
- Round Single Actuator
- Shaft Length [ABXF]
- 1.875 Inches Nominal Single Actuator
- Overall Height [ABKW]
- 1.875 Inches Nominal
- Overall Length [ABHP]
- 3.687 Inches Nominal
- Overall Width [ABMK]
- 1.718 Inches Nominal
- Style Designator [STYL]
- Circular Wafer, Bushing Mount
- Switch Actuator Indexing Position Quantity [CRJH]
- 12 Single Actuator
- Switch Actuator Positioning Increment [CSLC]
- 30.0 Degrees Single Actuator
- Switch Actuator Stop Device Type [CTDN]
- Adjustable Stop Single Actuator
- Switch Contact Basic Design [AJZE]
- Nonpile-Up Symmetrical
- Terminal Type [CSCF]
- Clip
- Thread Class [AAJD]
- 2A Single Mounting Facility
- Thread Length [AASA]
- 0.375 Inches Nominal Single Mounting Facility
- Thread Series Designator [THSD]
- Unef Single Mounting Facility
- Throw Quantity [AKPY]
- 11 Each Section Rear
DLA Procurement Analysis 5930-00-249-2927
Management Data 5930-00-249-2927
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5930-00-249-2927
Freight Information 5930-00-249-2927
5930-00-249-2927 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061300. A Sub NMFC of X. It has a NMFC Description of CIRCUIT BREAKER/SWITCH NOI. 5930-00-249-2927 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34410 which rates the freight between FCL and LCL. 5930-00-249-2927 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 72D for ocean manifesting and military sealift. 5930-00-249-2927 is not classified as a special type of cargo when transported by water. 5930-00-249-2927 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5930-00-249-2927
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- 0.25 lb or less, one dimension 2" or less, other dimensions less than 24"
- 85 to 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- MIL-PRF-121, Greaseproof, Waterproof Barrier
- No Requirement
- Not Applicable
- PPP-B-566 or PPP-B-676, Folding or Setup Box
- No special marking
- MIL-PRF-121, Greaseproof, Waterproof Barrier
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- Any Suitable Fiber Box
