5930-00-235-9753
Rotary Switch
5930002359753 002359753 2A251 A6045
A switch actuated by a definite angular rotation of the switch shaft about its axis. For items having rated actuation travel and pressure characteristics, see SWITCH, SENSITIVE. Excludes RELAY, ROTARY; SWITCH, STEPPING; and SWITCH, TELEPHONE (as modified). View more Rotary Switch
Managed by United States
NSN Created on 1 Jan 1963
Data Last Changed
May 2023
May 2023
NATO Update Count
14
14
NATO Data Quality
Marketplace 5930-00-235-9753
Need Help?
Request a Quotation from participating marketplace vendors
Request a Quotation from participating marketplace vendors
Related Documents 5930-00-235-9753 5+ Documents (More...)
2A251 A6045 A switch actuated by a definite angular rotation of the switch shaft about its axis.
Photo 1/3 5930-00-235-9753 Photo 2/3 NSN 5930-00-235-9753 (Identification) 3/3 - - - 1.
Photo 1/3 5930-00-235-9753 Photo 2/3 NSN 5930-00-235-9753 (Identification) 3/3 - - - 1. 5930-00-235-9753
Photo 1/3 5930-00-235-9753 Photo 2/3 NSN 5930-00-235-9753 (Identification) 3/3 - - - 1.
Photo 1/3 5930-00-235-9753 Photo 2/3 NSN 5930-00-235-9753 (Identification) 3/3 - - - 1. 5930-00-235-9753
JavaScript in your web browser . 5120-00-012-3427Trunion Tool5120000123427 000123427 A16045 755226 A6045
https//www.nsnlookup.com /fsg-62/fsc-6220/uk 6220-99-110-4185 Light Transmitting Indicating Panel,A6045
Tool5120000123427 000123427A16045755226A6045 Documents 5120-00-012-3427 3+ Documents ( More... ) Panel,A6045
https//www.nsnlookup.com /fsg-62/fsc-6220/uk 6220-99-110-4185 Light Transmitting Indicating Panel,A6045
Tool5120000123427 000123427A16045755226A6045 Documents 5120-00-012-3427 3+ Documents ( More... ) Panel,A6045
-9753Rotary Switch5930002359753 002359753 2A251 A6045 https//www.nsnlookup.com /fsg-62/fsc-6220/uk 6220
-99-110-4185 Light Transmitting Indicating Panel,A6045 /fsg-62/fsc-6220/uk 6220-99 Indicating Panel,A6045
Light Transmitting Indicating Panel,A6045 us 5930-00- A6045 https//www.nsnlookup.com /fsg https https
-99-110-4185 Light Transmitting Indicating Panel,A6045 /fsg-62/fsc-6220/uk 6220-99 Indicating Panel,A6045
Light Transmitting Indicating Panel,A6045 us 5930-00- A6045 https//www.nsnlookup.com /fsg https https
A6045-8-1 VALVE,SAFETY RELIEF 1 EA NS Request Quotation Subscribe to View Vendor Details...
us 5930-00- A6045 https//www.nsnlookup.com /fsg https//www.nsnlookup.com /fsg-48/fsc-4820/us 4820-00
A6045-8-1 VALVE,SAFETY RELIEF 1 EA NS Request Quotation https//www.nsnlookup.com /fsg-59/fsc-5930/us
us 5930-00- A6045 https//www.nsnlookup.com /fsg https//www.nsnlookup.com /fsg-48/fsc-4820/us 4820-00
A6045-8-1 VALVE,SAFETY RELIEF 1 EA NS Request Quotation https//www.nsnlookup.com /fsg-59/fsc-5930/us
Upgrade your Account Upgrade 4720-01-194-0036Nonmetallic Hose Assembly4720011940036 011940036 12352510 A6045
A6045-1 HOSE ASSEMBLY,NONMETALLIC 8 EA NS Request Quotation Updated Every Day A6045-1 RQST NE Updated
A6045-1 HOSE ASSEMBLY,NONMETALLIC 8 EA NS Request Quotation Updated Every Day A6045-1 RQST NE Updated
A6045-1 HOSE ASSEMBLY,NONMETALLIC 8 EA NS Request Quotation Updated Every Day A6045-1 RQST NE Updated
A6045-1 HOSE ASSEMBLY,NONMETALLIC 8 EA NS Request Quotation Updated Every Day A6045-1 RQST NE Updated
Restrictions 5930-00-235-9753
5930-00-235-9753 is a Rotary Switch that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
Import and Export 5930-00-235-9753
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5930-00-235-9753
- Italy (ZR01)
- Effective Date:
- 1 Jul 1997
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
Approved Sources 5930-00-235-9753
- Part Number
- Manufacturer
- Status
- 2A251
- Manufacturer
- 64648 - Wells-Gardner Electronics Corp (Active)
- Primary Buy
- Primary Buy
- A6045
- 71450 - Cts Corp (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- A6045
- 58756 - Cts Corp Electromechanical Div (Active)
- Advisory Reference
- Advisory Reference
Datasheet 5930-00-235-9753
- Characteristic
- Specifications
- FIIG
- Specifications
- A052B0
- Style Designator [STYL]
- Circular Wafer, Bushing Mount
- Overall Length [ABHP]
- 1.092 Inches Nominal
- Overall Diameter [ADAV]
- 1.125 Inches Nominal
- Individual Section Quantity [AFBH]
- 1
- Switch Contact Basic Design [AJZE]
- Nonpile-Up Symmetrical
- Pole Quantity [AKPX]
- 2 Single Section Front
- Throw Quantity [AKPY]
- 1 Single Section Front
- Contact Switching Action [CSHW]
- Breaks Before Makes Single Section Front
- Contact Voltage Rating In Volts [CQMK]
- 250.0 Highest Dc Voltage Rating At Sea Level
- Contact Voltage Rating In Volts [CQMK]
- 125.0 Lowest Dc Voltage Rating At Sea Level
- Contact Load Current Rating [CTHF]
- 1.0 Amperes Resistive Load Highest Dc Voltage Rating At Sea Level
- Contact Load Current Rating [CTHF]
- 2.0 Amperes Resistive Load Lowest Dc Voltage Rating At Sea Level
- Switch Actuator Momentary Position [CQQT]
- Counterclockwise Single Actuator
- Switch Actuator Indexing Position Quantity [CRJH]
- 2 Single Actuator
- Switch Actuator Positioning Increment [CSLC]
- 30.0 Degrees Single Actuator
- Shaft Type [CRSJ]
- Round, Flatted Single Actuator
- First Flat Length [ABNB]
- 0.250 Inches Nominal Single Actuator
- Flat Height [ABNC]
- 0.156 Inches Nominal Single Actuator
- Shaft Diameter [ABWV]
- 0.250 Inches Nominal Single Actuator
- Shaft Length [ABXF]
- 0.530 Inches Nominal Single Actuator
- Terminal Type [CSCF]
- Tab, Solder Lug
- Nonturn Device Type [AFDC]
- Tab At 3:00 O'clock
- Nonturn Device Radius [AEFP]
- 0.531 Inches Nominal At 3:00 O'clock
- Mounting Method [AXGY]
- Threaded Bushing Single Mounting Facility
- Thread Series Designator [THSD]
- Unef Single Mounting Facility
- Nominal Thread Size [CQJX]
- 0.375 Inches Single Mounting Facility
- Thread Class [AAJD]
- 2A Single Mounting Facility
- Thread Length [AASA]
- 0.187 Inches Nominal Single Mounting Facility
- Features Provided [CBBL]
- Metallic Inclosure
- Shaft Flat/Slot Angular Location [CQRQ]
- 135.0 Degrees From Nonturn Device Single Actuator
NATO Stock Numbers Related to 5930-00-235-9753
5930-41-001-6146 5930-12-342-1839 5930-21-891-8276 5930-21-844-0127 5930-99-395-9799 5930-14-565-4166 5930-99-536-0281 5930-12-367-7479 5930-99-496-1274 5930-12-334-3833 5930-99-428-3184 5930-12-358-0877 5930-25-106-6986 5930-66-128-8047 5930-99-617-3172 5930-12-193-8530 5930-99-945-7012 5930-21-861-2112
Freight Information 5930-00-235-9753
5930-00-235-9753 has freight characteristics.. 5930-00-235-9753 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
Packaging Data 5930-00-235-9753
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- 0.25 lb or less, one dimension 2" or less, other dimensions less than 24"
- 85 to 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- --
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- No Requirement
- Not Applicable
- PPP-B-566 or PPP-B-676, Folding or Setup Box
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- Any Suitable Fiber Box
