5930-00-224-4937
Knife Switch
5930002244937 002244937 A-1142 1CL1A250V30A2 WS871 1142
A switch using hinged blades for contacts which enter or embrace fixed contact clips. Includes switches which have a movable blade which swivels to permit contact with each of several fixed contact clips. See also SWITCH, BOX. View more Knife Switch
May 2023
8
Marketplace 5930-00-224-4937
Request a Quotation from participating marketplace vendors
Related Documents 5930-00-224-4937 5+ Documents (More...)
A-1142 A-11421CL1A250V30A2WS8711142 A switch using hinged blades for contacts which enter or embrace
Knife Switch 5930002244937002244937,A-1142 Upgrade your Account Upgrade 5930-00-224-4937Knife https
https//www.nsnlookup.com /fsg-59/fsc-5930/us 5930-00-553-6693 Knife Switch 5930005536693005536693,WS871
Knife Switch 5930002244937 002244937,A-1142 Upgrade your Account Upgrade 5930-00-224-4937Knife
-06 1142-06 REV H An electrical fitting with electrical contacts constructed to be affixed to the end
Knife Switch 5930002244937 002244937,A-1142 Upgrade your Account Upgrade 5930-00-224-4937Knife
https//www.nsnlookup.com /fsg-53/fsc-5365/us 5365-01-451-4026 Machine Thread Bushing 5365014514026 A-1142
Knife Switch 5930002244937 002244937,A-1142 Upgrade your Account Upgrade 5930-00-224-4937Knife
www.nsnlookup.com /fsg-66/fsc-6625/us 6625-00-888-3498 Arbitrary Scale Meter 6625008883498008883498 1142
Knife Switch 5930002244937 002244937,A-1142 Upgrade your Account Upgrade 5930-00-224-4937Knife
Restrictions 5930-00-224-4937
5930-00-224-4937 is a Knife Switch that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
Import and Export 5930-00-224-4937
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5930-00-224-4937
- US Air Force (FXGX)
- Effective Date:
- 1 Nov 2005
- Former MOE Rule:
- FXTX
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
Approved Sources 5930-00-224-4937
- Part Number
- Manufacturer
- Status
- A-1142
- Manufacturer
- 58308 - Filnor Inc (Active)
- Primary Buy
- Primary Buy
- 1142
- 58308 - Filnor Inc (Active)
- Secondary Buy
- Secondary Buy
- 1CL1A250V30A2
- 81348 - Federal Specifications Promulgated (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- WS871
- 81348 - Federal Specifications Promulgated (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 1142
- 05684 - Square D Company (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5930-00-224-4937
- Characteristic
- Specifications
- FIIG
- Specifications
- A053A0
- Body Height [ADAU]
- 3.531 Inches Nominal
- Body Length [ADAQ]
- 6.812 Inches Nominal
- Body Style [AAQL]
- Hole Mounted
- Body Width [ADAT]
- 2.156 Inches Nominal
- Center To Center Distance Between Mounting Facilities Parallel To Length [ABKQ]
- 5.531 Inches Nominal
- Contact Load Current Rating At Maximum Rated Voltage [CXQR]
- 30.000 Amperes Resistive Dc And 30.000 Amperes Resistive Ac
- Maximum Voltage Rating In Volts [AFXE]
- 250.0 Ac And 250.0 Dc
- Mounting Method [AXGY]
- Panel
- Terminal Type And Quantity [TTQY]
- 4 Threaded Stud
DLA Procurement Analysis 5930-00-224-4937
Management Data 5930-00-224-4937
Air Force
- Fund:
- SF
- Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point
- Budget:
- 9
- 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors
- Aggregation Code:
- EH
- ELECTRONIC COMPONENTS
- Price Validation Code:
- N
- The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
The price has not been analyzed or reviewed for accuracy.
ZOP or Standard price challenges are permissible but must be supported with adequate justification. However, if coded for Local Purchase (LP) or Fabrication/Manufacture as indicated with an (LM) Acquisition Advice Code of “L” or “F”, then it must be evaluated locally where purchased or fabricated.
- Expendability
Recoverability
Repairability: - N
- Expendable. Condemn at User. Stock Fund (except Munitions).
NATO Stock Numbers Related to 5930-00-224-4937
Freight Information 5930-00-224-4937
5930-00-224-4937 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061300. A Sub NMFC of X. It has a NMFC Description of CIRCUIT BREAKER/SWITCH NOI. 5930-00-224-4937 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34410 which rates the freight between FCL and LCL. 5930-00-224-4937 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 72D for ocean manifesting and military sealift. 5930-00-224-4937 is not classified as a special type of cargo when transported by water. 5930-00-224-4937 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5930-00-224-4937
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- 0.25 lb or less, one dimension 2" or less, other dimensions less than 24"
- 85 to 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- MIL-P-130, Laminated and Creped Wrapping Paper
- A-A-1051, Paperboard Cushioning
- --
- PPP-B-566 or PPP-B-676, Folding or Setup Box
- No special marking
- MIL-P-130, Laminated and Creped Wrapping Paper
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- Any Suitable Fiber Box
Contracting Technical Data File (CTDF) 5930-00-224-4937 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
