5930-00-209-6210
Rotary Switch
5930002096210 002096210 10128821 240707F2
A switch actuated by a definite angular rotation of the switch shaft about its axis. For items having rated actuation travel and pressure characteristics, see SWITCH, SENSITIVE. Excludes RELAY, ROTARY; SWITCH, STEPPING; and SWITCH, TELEPHONE (as modified). View more Rotary Switch
May 2023
12
Marketplace 5930-00-209-6210
Request a Quotation from participating marketplace vendors
Related Documents 5930-00-209-6210 5+ Documents (More...)
Photo 1/3 5930-00-209-6210 Photo 2/3 NSN 5930-00-209-6210 (Identification) 3/3 - - - 1.
RQST NE Updated Every Day 5930-00-209-6210 RQST Updated Every Day 5930-00-209-6210 RQST NE Related Documents
Restrictions 5930-00-209-6210
5930-00-209-6210 is a Rotary Switch that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item contains Silver.
Import and Export 5930-00-209-6210
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5930-00-209-6210
- Spain (YB01)
- Effective Date:
- 1 Sep 2008
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Nov 2005
Approved Sources 5930-00-209-6210
- Part Number
- Manufacturer
- Status
- 10128821
- Manufacturer
- 18876 - Us Army Aviation And Missile Command (Active)
- Primary Buy
- Primary Buy
- 240707F2
- 76854 - Electro Switch Corp. (Active)
- Secondary Buy
- Secondary Buy
Datasheet 5930-00-209-6210
- Characteristic
- Specifications
- FIIG
- Specifications
- A052B0
- Contact Load Current Rating [CTHF]
- 2.0 Amperes Resistive Load Dc At Sea Level
- Contact Load Current Rating [CTHF]
- 1.0 Amperes Resistive Load Ac At Sea Level
- Contact Voltage Rating In Volts [CQMK]
- 28.0 Dc At Sea Level
- Contact Switching Action [CSHW]
- Breaks Before Makes Each Section Rear
- Contact Voltage Rating In Volts [CQMK]
- 110.0 Ac At Sea Level
- Mounting Method [AXGY]
- Threaded Bushing Single Mounting Facility
- Nominal Thread Size [CQJX]
- 0.375 Inches Single Mounting Facility
- Nonturn Device Radius [AEFP]
- 0.500 Inches Minimum At 3:00 O'clock And 0.560 Inches Maximum At 3:00 O'clock
- Nonturn Device Type [AFDC]
- Tab At 3:00 O'clock
- Individual Section Quantity [AFBH]
- 2
- Pole Quantity [AKPX]
- 2 Each Section Rear
- Precious Material And Location [PMLC]
- Contacts And Rotor Silver
- Precious Material [PRMT]
- Silver
- Shaft Diameter [ABWV]
- 0.248 Inches Minimum Single Actuator And 0.250 Inches Maximum Single Actuator
- Shaft Length [ABXF]
- 0.500 Inches Nominal Single Actuator
- Shaft Type [CRSJ]
- Round Single Actuator
- Overall Height [ABKW]
- 1.280 Inches Minimum And 1.340 Inches Maximum
- Overall Length [ABHP]
- 2.000 Inches Nominal
- Overall Width [ABMK]
- 1.220 Inches Minimum And 1.280 Inches Maximum
- Style Designator [STYL]
- Circular Wafer, Bushing Mount
- Switch Actuator Indexing Position Quantity [CRJH]
- 3 Single Actuator
- Switch Actuator Positioning Increment [CSLC]
- 30.0 Degrees Single Actuator
- Switch Actuator Stop Device Type [CTDN]
- Fixed Stop Single Actuator
- Switch Contact Basic Design [AJZE]
- Nonpile-Up Nonsymmetrical
- Terminal Type [CSCF]
- Tab, Solder Lug
- Thread Length [AASA]
- 0.220 Inches Minimum Single Mounting Facility And 0.280 Inches Maximum Single Mounting Facility
- Thread Series Designator [THSD]
- Unef Single Mounting Facility
- Throw Quantity [AKPY]
- 3 Each Section Rear
DLA Procurement Analysis 5930-00-209-6210
Management Data 5930-00-209-6210
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Mar 1983
- Defense Logistics Agency (DS)
- EA
- Subscribe
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- Defense Logistics Agency (DS)
- I
- V
- Discontinued Without Replacement
- V
Similar Supply Items to 5930-00-209-6210
Freight Information 5930-00-209-6210
5930-00-209-6210 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061300. A Sub NMFC of X. It has a NMFC Description of CIRCUIT BREAKER/SWITCH NOI. 5930-00-209-6210 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34410 which rates the freight between FCL and LCL. 5930-00-209-6210 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 72D for ocean manifesting and military sealift. 5930-00-209-6210 is not classified as a special type of cargo when transported by water. 5930-00-209-6210 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Contracting Technical Data File (CTDF) 5930-00-209-6210 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Y
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
