5930-00-067-6657
Pressure Switch
5930000676657 000676657 9013ASG11
A switch which is actuated by changes in pressure of any gas or liquid or by changes in a vacuum acting upon its sensing element. Excludes BAROSWITCH; SWITCH, PRESSURE-THERMOSTATIC; and SWITCH, SENSITIVE. View more Pressure Switch
May 2023
8
Marketplace 5930-00-067-6657
Request a Quotation from participating marketplace vendors
Related Documents 5930-00-067-6657 5+ Documents (More...)
or by changes in a 5930-00-067-6657 RQST Updated Every Day 5930-00-067-6657 RQST NE Related Documents
5930-00-067-6657 Datasheet Management 5930-00-067-6657 RQST Updated Every Day 5930-00-067-6657 RQST
Upgrade your Account Upgrade 5930-00-258-6719Pressure https//www.nsnlookup.com /fsg-59/fsc-5930/us 5930-00-067-6657
Pressure Switch 5930000676657 000676657 Day 5930-00-067-6657 RQST NE Related Documents https//www.nsnlookup.com
Restrictions 5930-00-067-6657
5930-00-067-6657 is a Pressure Switch that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
Import and Export 5930-00-067-6657
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5930-00-067-6657
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Jul 2005
Approved Sources 5930-00-067-6657
- Part Number
- Manufacturer
- Status
- 9013ASG11
- Manufacturer
- 56365 - Schneider Electric Usa, Inc. (Active)
- Original Design
- Original Design
Datasheet 5930-00-067-6657
- Characteristic
- Specifications
- FIIG
- Specifications
- A048B0
- Contact Action Stimulus [CQGB]
- Increase
- Contact Adjustability [CTYC]
- Deactuation Point Adjustable And Actuation Point Adjustable
- Contact Adjustment Range [CTYM]
- +25.00 To 250.00 Actuation Point Pounds Per Square Inch And +26.00/+45.00 Deactuation Point Pounds Per Square Inch
- Contact Voltage Rating In Volts [CTZB]
- 32.0 Ac At Sea Level Single Voltage
- Mounting Facility Pattern [CQYJ]
- Four Position Rectangular
- Mounting Method [AXGY]
- Bracket
- Nominal Thread Size [CQJX]
- 0.250 Inches Single Pressure Connection
- Longest Vertical Distance Between Mounting Centers [AFDV]
- 4.000 Inches Nominal
- Longest Horizontal Distance Between Mounting Centers [AFDS]
- 3.750 Inches Nominal
- Pressure Connector Type [CTZL]
- Plain, Threaded Internal Single Connection
- Pressure Switch Type [AJZC]
- Gage
- Overall Height [ABKW]
- 3.375 Inches Nominal
- Overall Length [ABHP]
- 6.750 Inches Nominal
- Overall Width [ABMK]
- 5.313 Inches Nominal
- Terminal Type [CSCF]
- Screw
- Thread Quantity Per Inch [CMLP]
- 18 Single Pressure Connection
- Thread Series Designator [THSD]
- Npt Single Pressure Connection
DLA Procurement Analysis 5930-00-067-6657
Management Data 5930-00-067-6657
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Aug 2007
- Defense Logistics Agency (DS)
- EA
- Subscribe
- 1
- EA
- Oct 2006
- Department of the Navy (DN)
- EA
- Subscribe
- 1
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- Department of the Navy (DN)
- N
- V
- Discontinued W/O Replacement
- V
- Defense Logistics Agency (DS)
- I
- Z
- Discontinued-Use 5930-00-387-2562
- Z
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5930-00-067-6657
Freight Information 5930-00-067-6657
5930-00-067-6657 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061300. A Sub NMFC of X. It has a NMFC Description of CIRCUIT BREAKER/SWITCH NOI. 5930-00-067-6657 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34410 which rates the freight between FCL and LCL. 5930-00-067-6657 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 658 for ocean manifesting and military sealift. 5930-00-067-6657 is not classified as a special type of cargo when transported by water. 5930-00-067-6657 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5930-00-067-6657
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- 0.25 lb or less, one dimension 2" or less, other dimensions less than 24"
- 85 to 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- MIL-DTL-17667, Neutral Wrapping Paper
- ASTM-D4727, Fiberboard used as Pads, Cells, Die-cuts or Sleeves
- --
- ASTM-D5118, Type CF, Class Domestic, Corrugated Fiberboard Box
- No special marking
- MIL-DTL-17667, Neutral Wrapping Paper
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- Any Suitable Fiber Box
