5930-00-060-6884
Push Switch
5930000606884 000606884 A26260
A switch that is externally actuated by a device such as a push rod or button, which requires pushing for each actuation. The action may be momentary, with mechanical return. The actuating device may or may not be an integral part of the switch. The item may include provisions for mounting indicating lamp(s) or light emitting diode(s) in the actuator. Includes items consisting of individually separable switches that are physically interlocked, that have a common actuator, or are electrically connected. Excludes LIGHT-SWITCH; LIGHT-SWITCH ASSEMBLY; SWITCH, BEAM SELECTING, HEADLIGHT; SWITCH, FOOT; SWITCH, INTERLOCK; SWITCH, PRESSURE; SWITCH, PUSH-PULL; SWITCH, SENSITIVE and SWITCH ASSEMBLY. For devices which start, stop, reverse, select and/or regulate the speed of a motor, see STARTER, MOTOR and CONTROLLER, MOTOR. View more Push Switch
May 2023
8
Marketplace 5930-00-060-6884
Request a Quotation from participating marketplace vendors
Related Documents 5930-00-060-6884 5+ Documents (More...)
5930-00-060-6884 3+ Documents ( More... ) https//www.nsnlookup.com /fsg-59/fsc-5930/us 5930-00-060-6884
Push Switch 5930000606884000606884,A26260 RQST NE Updated Every Day 5930-00-060-6884 RQST Updated Every
Every Day 2540-27-007-5052 RQST NE Restrictions https//www.nsnlookup.com /fsg-59/fsc-5930/us 5930-00-060-6884
Push Switch 5930000606884 000606884,A26260 for $1 a day Upgrade your Account Upgrade 5930 https
Restrictions 5930-00-060-6884
5930-00-060-6884 is a Push Switch that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
Import and Export 5930-00-060-6884
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5930-00-060-6884
- Italy (ZR01)
- Effective Date:
- 1 Apr 1991
Approved Sources 5930-00-060-6884
- Part Number
- Manufacturer
- Status
- A26260
- Manufacturer
- 39739 - Scott Fetzer Company, The (Active)
- Primary Buy
- Primary Buy
Datasheet 5930-00-060-6884
- Characteristic
- Specifications
- FIIG
- Specifications
- A053A0
- Contact Load Current Rating At Maximum Rated Voltage [CXQR]
- 3.000 Amperes Resistive Ac
- Maximum Voltage Rating In Volts [AFXE]
- 600.0 Ac
- Nonpile-Up Contact Arrangement [CRLD]
- 2 Pole, Single Throw, Normally Closed, Double Break, Momentary Action Single Switch Unit
- Switch Actuator Quantity [AFCG]
- 1
- Terminal Type And Quantity [TTQY]
- 4 Screw
Similar Supply Items to 5930-00-060-6884
Freight Information 5930-00-060-6884
5930-00-060-6884 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061300. A Sub NMFC of X. It has a NMFC Description of CIRCUIT BREAKER/SWITCH NOI. 5930-00-060-6884 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. 5930-00-060-6884 is rated as class 77.5 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 34410 which rates the freight between FCL and LCL. 5930-00-060-6884 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 658 for ocean manifesting and military sealift. 5930-00-060-6884 is not classified as a special type of cargo when transported by water. 5930-00-060-6884 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
