5930-00-027-0284
Thermostatic Switch
5930000270284 000270284 32410-2MOD3(PLUS 190F) GT830AA3 22417-4 32410-2-185
A switch that is actuated by changes in ambient temperature. Excludes CIRCUIT BREAKER; CONTROL, TEMPERATURE (as modified); FUSE (as modified); PROTECTOR, THERMAL-OVERLOAD, ELECTRICAL MOTOR; RELAY, THERMAL; and THERMOSTAT, FLOW CONTROL. See also CONTROL, TEMPERATURE (as modified) and REGULATOR, TEMPERATURE (as modified). View more Thermostatic Switch
May 2023
8
Marketplace 5930-00-027-0284
Request a Quotation from participating marketplace vendors
Related Documents 5930-00-027-0284 5+ Documents (More...)
Photo 1/3 5930-00-027-0284 Photo 2/3 NSN 5930-00-027-0284 (Identification) 3/3 - - - 1.
BUY NE FedMall Updated Every Day 5930-00-027-0284 RQST NE Updated Every Day 5930-00-027-0284 RQST
Thermostatic Switch 5930000270284 000270284 for $1 a day Upgrade your Account Upgrade 5930-00-027
-0284Thermostatic Switch5930000270284 000270284 32410 -2MOD3(PLUS 190F) GT830AA3 22417-4 32410-2-185
Restrictions 5930-00-027-0284
5930-00-027-0284 is a Thermostatic Switch that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
Import and Export 5930-00-027-0284
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5930-00-027-0284
- US Navy (N9BN)
- Effective Date:
- 1 Nov 2005
- Former MOE Rule:
- NIND
- Supplementary Collaborators:
- KE
- Australia (ZA01)
- Effective Date:
- 1 Apr 1991
Approved Sources 5930-00-027-0284
- Part Number
- Manufacturer
- Status
- 22417-4
- Manufacturer
- 10412 - Whittaker Corp (Obsolete)
- Original Design
- Original Design
- 32410-2-185
- 73168 - Kidde Technologies, Inc (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 32410-2MOD3(PLUS 190F)
- 73168 - Kidde Technologies, Inc (Active)
- Advisory Reference
- Advisory Reference
- GT830AA3
- 26512 - Northrop Grumman Systems Corporation (Active)
- Advisory Reference
- Advisory Reference
Datasheet 5930-00-027-0284
- Characteristic
- Specifications
- FIIG
- Specifications
- A048B0
- Body Length [ADAQ]
- 0.251 Inches Nominal
- Contact Action Stimulus [CQGB]
- Decrease
- Contact Adjustability [CTYC]
- Deactuation Point Not Adjustable And Actuation Point Not Adjustable
- Contact Load Current Rating [CTHF]
- 2.0 Amperes Resistive Load Second Voltage
- Contact Load Current Rating [CTHF]
- 2.5 Amperes Resistive Load First Voltage
- Contact Stimulus Rating [CTYX]
- 185.00 Actuation Point Nominal Degrees Fahrenheit And 190.00 Deactuation Point Nominal Degrees Fahrenheit
- Contact Voltage Rating In Volts [CTZB]
- 115.0 Ac At Sea Level First Voltage
- Contact Voltage Rating In Volts [CTZB]
- 28.0 Dc At Sea Level Second Voltage
- Frequency In Hertz [FREQ]
- 60.0 Single Voltage
- Media For Which Designed [MEDA]
- Gas Or Liquid
- Mounting Method [AXGY]
- Clip
- Nonpile-Up Contact Arrangement [CRLD]
- 1 Pole, Single Throw, Normally Open, Momentary Action
- Overall Length [ABHP]
- 0.440 Inches Maximum
- Style Designator [STYL]
- Rectangular
- Overall Height [ABKW]
- 0.417 Inches Maximum
- Overall Width [ABMK]
- 0.776 Inches Nominal
- Temp Sensing Element Type [AKBY]
- Internal Sensor
- Terminal Type [CSCF]
- Tab, Solder Lug
Weapon Systems (WSDC) 5930-00-027-0284
DLA Procurement Analysis 5930-00-027-0284
Management Data 5930-00-027-0284
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5930-00-027-0284
Freight Information 5930-00-027-0284
5930-00-027-0284 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061300. A Sub NMFC of X. It has a NMFC Description of CIRCUIT BREAKER/SWITCH NOI. 5930-00-027-0284 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34410 which rates the freight between FCL and LCL. 5930-00-027-0284 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 658 for ocean manifesting and military sealift. 5930-00-027-0284 is not classified as a special type of cargo when transported by water. 5930-00-027-0284 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5930-00-027-0284
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- 0.25 lb or less, one dimension 2" or less, other dimensions less than 24"
- 85 to 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- A-A-1249, Paper, Tissue
- PPP-C-795, Cellular Plastic Film Cushioning; or A-A-3129, Open Cell Plastic Cushioning; or PPP-C-1797, Polypropylene Foam Cushioning; or A-A-59136, Polyethylene Foam Cushioning
- --
- --
- No special marking
- A-A-1249, Paper, Tissue
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- PPP-B-566 or PPP-B-676, Folding or Setup Box
