5925-00-549-5362
Circuit Breaker
5925005495362 005495362 454D507G07 ETN1076 S6205-3232365REVCCLASSALB1-35AMP
A device with means other than fuses for automatically opening the circuit in which it is installed when the current varies from the predetermined value for which the device is set. May include provisions for manual operation. At least one set of contacts must be in series with the actuating element(s). A combination of semiconductor and passive devices may be used in lieu of contacts. For automatically operated items in which the actuating (tripping) element and contacts are not in series, see RELAY (as modified). For items which are operated both manually and automatically but the actuating elements and contact are not in series, see RELAY-SWITCH. Excludes CIRCUIT BREAKER BOX and magneto "breaker" assemblies. See also SWITCH (as modified); and CONTROLLER. View more Circuit Breaker
May 2023
34
Marketplace 5925-00-549-5362
Request a Quotation from participating marketplace vendors
Related Documents 5925-00-549-5362 5+ Documents (More...)
Photo 1/2 NSN 5925-00-549-5362 (Identification) 2/2 - - 1.
RQST NE Updated Every Day 5925-00-549-5362 RQST Updated Every Day 5925-00-549-5362 RQST NE Related
/fsg-59/fsc-5920/it
Circuit Breaker 5925005495362 005495362 5925-00-549-5362Circuit Breaker5925005495362 005495362
454D507G07 ETN1076 S6205-3232365REVCCLASSALB1-35AMP 5925-00-549-5362 Circuit Breaker 5925005495362005495362
Restrictions 5925-00-549-5362
5925-00-549-5362 is a Circuit Breaker that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item contains Silver.
Import and Export 5925-00-549-5362
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5925-00-549-5362
- Brazil (YA01)
- Effective Date:
- 1 Jan 2002
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Thailand (YY01)
- Effective Date:
- 1 Feb 2015
- Australia (ZA01)
- Effective Date:
- 1 Apr 1991
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Portugal (ZP01)
- Effective Date:
- 1 Apr 1991
- Italy (ZR01)
- Effective Date:
- 1 Jul 1997
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Nov 1998
Approved Sources 5925-00-549-5362
- Part Number
- Manufacturer
- Status
- S6205-3232365REVCCLASSALB1-35AMP
- Manufacturer
- 80064 - Naval Ship Systems Command (Active)
- Primary Buy
- Primary Buy
- 454D507G07
- 89946 - Eaton Corporation (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- ETN1076
- 30086 - L3harris Maritime Power & Energy (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
Datasheet 5925-00-549-5362
- Characteristic
- Specifications
- FIIG
- Specifications
- A030A0
- Actuator Function [CPRW]
- Trip-Reset
- Actuator Position Designation [CPRX]
- At Pole One
- Body Height [ADAU]
- 2.313 Inches Nominal
- Body Length [ADAQ]
- 3.500 Inches Nominal
- Body Style [AAQL]
- Single Pole Type
- Body Width [ADAT]
- 0.969 Inches Nominal
- Boss Height [AJEC]
- 0.188 Inches Nominal
- Case Material [ADTV]
- Plastic
- Circuit Protection Type [CPRH]
- Overcurrent Single Location
- Fragility Factor [AFJN]
- Moderately Rugged
- Frequency In Hertz [FREQ]
- 400.0 Single Location
- Maximum Continuous Load Current Rating Per Pole [CPLM]
- 35.0 Amperes Ac Single Location And 35.0 Amperes Dc Single Location
- Maximum Interrupting Capacity Current Type And Rating Per Pole In Amps [CPRG]
- 5000.0 Ac Single Location And 2500.0 Dc Single Location
- Mounting Facility Type And Quantity [AXHR]
- 1 Terminal And 1 Clip
- Operating Voltage Type And Rating Per Pole In Volts [CPRF]
- 120.0 Ac Single Location And 125.0 Dc Single Location
- Inclosure Protection Type For Which Designed [CQXF]
- Shockproof And Vibrationproof
- Main Contact Tripping Mechanism Type [CPRR]
- Trip Free
- Manual Actuator Type And Quantity [CPRT]
- 1 Toggle
- Pole Quantity [AKPX]
- 1
- Precious Material And Location [PMLC]
- Contact Surfaces Silver
- Precious Material [PRMT]
- Silver
- Reset Method [CPRQ]
- Manual
- Special Handling Feature [BBRJ]
- Magnetic
- Trip Delay Time In Seconds Per Rated Continuous Current [CQWN]
- 10.000 Minimum At 200 Pct Single Location And 210.000 Maximum At 200 Pct Single Location
- Trip Release Ambient Temp Rating [CRCF]
- 50.0 Deg Celsius Nominal Single Location
- Trip Release Characteristic [CPRL]
- Time Delay Single Location
- Trip Release Method [CPRJ]
- Thermal-Magnetic Single Location
- Ultimate Trip Rating Of Continuous Current Rating Per Pole In Percent [CPRN]
- 138.0 Single Location
- Storage Type [BBRG]
- General Purpose Warehouse
- Terminal Type And Quantity [TTQY]
- 1 Compression And 1 Quick Disconnect, Female
- Test Data Document [TEST]
- 81349-Mil-C-17588 Specification (Includes Engineering Type Bulletins, Brochures,Etc., That Reflect Specification Type Data In Specification Format; Excludes Commercial Catalogs, Industry Directories, And Similar Trade Publications, Reflecting General Type Data On Certain Environmental And Performance Requirements And Test Conditions That Are Shown As "Typical", "Average", "Nominal", Etc.).
Similar Supply Items to 5925-00-549-5362
Freight Information 5925-00-549-5362
5925-00-549-5362 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061300. A Sub NMFC of X. It has a NMFC Description of CIRCUIT BREAKER/SWITCH NOI. 5925-00-549-5362 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34410 which rates the freight between FCL and LCL. 5925-00-549-5362 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 658 for ocean manifesting and military sealift. 5925-00-549-5362 is not classified as a special type of cargo when transported by water. 5925-00-549-5362 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5925-00-549-5362
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- 0.25 lb or less, one dimension 2" or less, other dimensions less than 24"
- 85 to 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- --
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- PPP-C-795, Cellular Plastic Film Cushioning; or A-A-3129, Open Cell Plastic Cushioning; or PPP-C-1797, Polypropylene Foam Cushioning; or A-A-59136, Polyethylene Foam Cushioning
- --
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
- --
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- Any Suitable Fiber Box
