5925-00-154-0317
Circuit Breaker
5925001540317 001540317 AM1516MG3-50-32-2DC
A device with means other than fuses for automatically opening the circuit in which it is installed when the current varies from the predetermined value for which the device is set. May include provisions for manual operation. At least one set of contacts must be in series with the actuating element(s). A combination of semiconductor and passive devices may be used in lieu of contacts. For automatically operated items in which the actuating (tripping) element and contacts are not in series, see RELAY (as modified). For items which are operated both manually and automatically but the actuating elements and contact are not in series, see RELAY-SWITCH. Excludes CIRCUIT BREAKER BOX and magneto "breaker" assemblies. See also SWITCH (as modified); and CONTROLLER. View more Circuit Breaker
May 2023
11
Marketplace 5925-00-154-0317
Request a Quotation from participating marketplace vendors
Related Documents 5925-00-154-0317 5+ Documents (More...)
RQST NE Updated Every Day 5925-00-154-0317 RQST Updated Every Day 5925-00-154-0317 RQST NE Related Documents
5925-00-154-0317 1+ Documents ( More... ) https//www.nsnlookup.com /fsg-59/fsc-5925/us 5925-00-154-0317
Restrictions 5925-00-154-0317
5925-00-154-0317 is a Circuit Breaker that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
Import and Export 5925-00-154-0317
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5925-00-154-0317
- Germany (ZG01)
- Effective Date:
- 1 Apr 1991
Approved Sources 5925-00-154-0317
- Part Number
- Manufacturer
- Status
- AM1516MG3-50-32-2DC
- Manufacturer
- 74193 - Eaton Corp Heinemann Products (Obsolete)
- Original Design
- Original Design
Datasheet 5925-00-154-0317
- Characteristic
- Specifications
- FIIG
- Specifications
- A030A0
- Actuator Function [CPRW]
- Trip-Reset
- Arc Quenching Method [APNQ]
- Magnetic Blowout
- Body Length [ADAQ]
- 3.719 Inches Nominal
- Body Style [AAQL]
- Single Pole Type
- Body Width [ADAT]
- 0.990 Inches Nominal
- Boss Height [AJEC]
- 0.156 Inches Nominal
- Case Material [ADTV]
- Plastic
- Center To Center Distance Between Terminals Parallel To Length [AEBP]
- 3.063 Inches Nominal
- Circuit Protection Type [CPRH]
- Overcurrent Single Location
- Distance Between Centerlines Of Mounting Facilities Parallel To Body Length [AEBY]
- 2.750 Inches Nominal
- Fragility Factor [AFJN]
- Moderately Rugged
- Maximum Continuous Load Current Rating Per Pole [CPLM]
- 50.0 Amperes Dc Single Location
- Maximum Interrupting Capacity Current Type And Rating Per Pole In Amps [CPRG]
- 5000.0 Dc Single Location
- Mounting Facility Type And Quantity [AXHR]
- 2 Threaded Hole
- Mounting Surface To Terminal End Distance [AJWX]
- 3.239 Inches Nominal
- Nominal Thread Size [CQJX]
- 0.138 Inches
- Operating Voltage Type And Rating Per Pole In Volts [CPRF]
- 32.0 Dc Single Location
- Inclosure Protection Type For Which Designed [CQXF]
- Fungus Resistant And Moisture Resistant
- Internal Trip Release Configuration [CPSM]
- Series Trip Single Location
- Main Contact Tripping Mechanism Type [CPRR]
- Trip Free
- Manual Actuator Type And Quantity [CPRT]
- 1 Toggle
- Pole Quantity [AKPX]
- 1
- Reset Method [CPRQ]
- Manual
- Special Handling Feature [BBRJ]
- Magnetic
- Trip Delay Time In Seconds Per Rated Continuous Current [CQWN]
- 2.500 Minimum At 200 Pct Single Location And 8.500 Maximum At 200 Pct Single Location
- Trip Release Characteristic [CPRL]
- Time Delay Single Location
- Trip Release Method [CPRJ]
- Magnetic-Hydraulic Single Location
- Ultimate Trip Rating Of Continuous Current Rating Per Pole In Percent [CPRN]
- 150.0 Single Location
- Storage Type [BBRG]
- General Purpose Warehouse
- Terminal Type And Quantity [TTQY]
- 2 Threaded Stud
- Thread Quantity Per Inch [CMLP]
- 32
- Thread Series Designator [THSD]
- Unc
Similar Supply Items to 5925-00-154-0317
Freight Information 5925-00-154-0317
5925-00-154-0317 has freight characteristics managed by Germany.It has a National Motor Freight Classification (NMFC) of 061300. A Sub NMFC of X. It has a NMFC Description of CIRCUIT BREAKER/SWITCH NOI. 5925-00-154-0317 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. 5925-00-154-0317 is rated as class 77.5 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 34410 which rates the freight between FCL and LCL. 5925-00-154-0317 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 658 for ocean manifesting and military sealift. 5925-00-154-0317 is not classified as a special type of cargo when transported by water. 5925-00-154-0317 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
