5920-01-506-4786
Block Fuseholder
5920015064786 015064786 UK5-HESI ORDER NO. 30 04 10 0 SB-050040-LM FIND NO 21
A fuseholder in which the fuseholder stud and/or clips and insulation are mounted on a flat base. Excludes FUSEHOLDER, RECEPTACLE. View more Block Fuseholder
November 2023
6
Marketplace 5920-01-506-4786
Request a Quotation from participating marketplace vendors
Related Documents 5920-01-506-4786 5+ Documents (More...)
Photo 1/7 5920-01-506-4786 Photo 2/7 5920-01-506-4786 Photo 3/7 5920-01-506-4786 Photo 4/7 5920
UK5-HESI FUSEHOLDER,BLOCK 14 EA NS Request Quotation Updated Every Day 5920-01-506-4786 RQST NE Updated
Block Fuseholder 5920015064786 015064786 for $1 a day Upgrade your Account Upgrade 5920-01-506-
4786Block Fuseholder5920015064786 015064786 UK5-HESI UK5-HESI FUSEHOLDER,BLOCK 2 EA NS Request Quotation
/fsg-59/fsc-5940/us
Block Fuseholder 5920015064786 015064786 HESI FUSEHOLDER,BLOCK 2 EA NS Request Quotation https/
Restrictions 5920-01-506-4786
5920-01-506-4786 is a Block Fuseholder that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item does not contain a precious metal.
Import and Export 5920-01-506-4786
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5920-01-506-4786
- US Navy (N9BN)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- N9ND
- Supplementary Collaborators:
- GTHXHD
- Australia (ZA01)
- Effective Date:
- 1 Jun 2013
- Republic of Korea (ZH01)
- Effective Date:
- 1 Jan 2015
- Netherlands (ZN01)
- Effective Date:
- 1 Dec 2005
- Portugal (ZP01)
- Effective Date:
- 1 Jan 2016
Approved Sources 5920-01-506-4786
- Part Number
- Manufacturer
- Status
- UK5-HESI
- Manufacturer
- 5Y407 - Phoenix Contact Development And (Active)
- Primary Buy
- Primary Buy
- ORDER NO. 30 04 10 0
- 5Y407 - Phoenix Contact Development And (Active)
- Secondary Buy
- Secondary Buy
- SB-050040-LM FIND NO 21
- 09JX9 - Alcatel-Lucent Usa Inc. (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5920-01-506-4786
- Characteristic
- Specifications
- FIIG
- Specifications
- A014A0
- Fuse Accommodation Quantity [AGUE]
- 1
- Current Carrying Rating In Amps [CQJL]
- 7.0
- Voltage In Volts [ELEC]
- 600.0
- Fuse Terminal Type Accommodated [CSNM]
- Ferrule
- Terminal Type And Quantity [TTQY]
- 2 Ferrule
- Body Style [AAQL]
- Snap On Style
- Overall Length [ABHP]
- 72.5 Millimeters Nominal
- Overall Height [ABKW]
- 56.5 Millimeters Nominal
- Overall Width [ABMK]
- 8.2 Millimeters Nominal
- Accommodated Fuse Length [AGUJ]
- 20.0 Millimeters Nominal
- Accommodated Ferrule Diameter [AGUK]
- 5.0 Millimeters Nominal
- Special Features [FEAT]
- Mounting On Din Rail
- End Item Identification [AGAV]
- An/Fcc-100(V), 7613103 (53711), Voice Ancillary Ican Cvn76
Weapon Systems (WSDC) 5920-01-506-4786
DLA Procurement Analysis 5920-01-506-4786
- Last Stock Position:
- 18 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 5920-01-506-4786
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5920-01-506-4786
Freight Information 5920-01-506-4786
5920-01-506-4786 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 062060. A Sub NMFC of Z. It has a NMFC Description of FUSES NOI IN BOXES. 5920-01-506-4786 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34740 which rates the freight between FCL and LCL. 5920-01-506-4786 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 658 for ocean manifesting and military sealift. 5920-01-506-4786 is not classified as a special type of cargo when transported by water. 5920-01-506-4786 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5920-01-506-4786
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Electrical Instrument
- 0.25 lb or less, one dimension 2" or less, other dimensions less than 24"
- 85 to 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- No Requirement
- Not Applicable
- Bags made of material conforming to MIL-P-130, MIL-DTL-17667, MIL-PRF-121, or any material authorized by MIL-DTL-117. Closure may be by staples, tape, adhesive or heat seal
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
Procurement History 5920-01-506-4786 1 Records
Contracting Technical Data File (CTDF) 5920-01-506-4786 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- F
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
