5920-01-057-7370
Lightning Arrester
5920010577370 010577370 801706-2 2021-16
A protective device to provide a discharge path for lightning between line and line, and/or line and ground. See also PROTECTOR, TELEPHONE. View more Lightning Arrester
May 2023
11
Marketplace 5920-01-057-7370
Request a Quotation from participating marketplace vendors
Related Documents 5920-01-057-7370 1+ Documents (More...)
Photo 1/4 5920-01-057-7370 Photo 2/4 5920-01-057-7370 Photo 3/4 5920-01-057-7370 Photo 4/4 - -
Quotation Updated Every Day 5920-01-057-7370 RQST NE Updated Every Day 5920-01-057-7370 RQST Updated
Restrictions 5920-01-057-7370
5920-01-057-7370 is a Lightning Arrester that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
Import and Export 5920-01-057-7370
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5920-01-057-7370
- US Air Force (FXGX)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- FXTX
- Spain (YB01)
- Effective Date:
- 1 Oct 1996
- Germany (ZG01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Nov 1994
Approved Sources 5920-01-057-7370
- Part Number
- Manufacturer
- Status
- 801706-2
- Manufacturer
- 96214 - Raytheon Company (Active)
- Primary Buy
- Primary Buy
- 2021-16
- 23663 - Joslyn Products (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5920-01-057-7370
- Characteristic
- Specifications
- FIIG
- Specifications
- T214-C
- Overall Length [ABHP]
- 4.230 Inches Nominal
- Overall Diameter [ADAV]
- 0.312 Inches Nominal
- Mounting Method [ADJH]
- Terminals, Wire Lead
- Mounting Configuration [ALGC]
- One 0.032 In. Dia Wire Lead At Each End
- Body Material [AAFZ]
- Ceramic
- Usage Design [ALBY]
- Indoor
- Arrester Type [AQAP]
- Gas
- Breakdown Voltage [AQAQ]
- 150.000 Volts Nominal
- Terminal Type [AARB]
- Wire Lead
- Terminal Quantity [AARA]
- 2
DLA Procurement Analysis 5920-01-057-7370
Management Data 5920-01-057-7370
Similar Supply Items to 5920-01-057-7370
Freight Information 5920-01-057-7370
5920-01-057-7370 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 062380. A Sub NMFC of X. It has a NMFC Description of LIGHTNING ARRESTERS/PARTS NOI. 5920-01-057-7370 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34900 which rates the freight between FCL and LCL. 5920-01-057-7370 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 658 for ocean manifesting and military sealift. 5920-01-057-7370 is not classified as a special type of cargo when transported by water. 5920-01-057-7370 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5920-01-057-7370
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- 0.25 lb or less, one dimension 2" or less, other dimensions less than 24"
- 85 to 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- PPP-C-795, Cellular Plastic Film Cushioning; or A-A-3129, Open Cell Plastic Cushioning; or PPP-C-1797, Polypropylene Foam Cushioning; or A-A-59136, Polyethylene Foam Cushioning
- --
- --
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
