5920-00-574-7510
Extractor Post Fuseholder
5920005747510 005747510 HCMDEJLQWRZ B7475389P4
A fuseholder in which the clips or contacts for electrical connection to the fuse are mounted in a tubular body or similar inclosure which surrounds the fuse. It generally contains a removable cap or knob. It includes in-the-line type and those designated as miniature type FUSEHOLDER (as modified). View more Extractor Post Fuseholder
May 2023
14
Marketplace 5920-00-574-7510
Request a Quotation from participating marketplace vendors
Related Documents 5920-00-574-7510 1+ Documents (More...)
Photo 1/4 5920-00-574-7510 Photo 2/4 NSN 5920-00-574-7510 (Identification) 3/4 NSN 5920-00-574-
5920-00-574-7510 1+ Documents ( More... ) https//www.nsnlookup.com /fsg-59/fsc-5920/us 5920-00-574-7510
Restrictions 5920-00-574-7510
5920-00-574-7510 is a Extractor Post Fuseholder that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
Import and Export 5920-00-574-7510
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5920-00-574-7510
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Nov 2005
Approved Sources 5920-00-574-7510
- Part Number
- Manufacturer
- Status
- HCMDEJLQWRZ
- Manufacturer
- 71400 - Cooper Bussmann, Llc (Active)
- Primary Buy
- Primary Buy
- B7475389P4
- 24446 - General Electric Company (Active)
- Secondary Buy
- Secondary Buy
- B7475389P4
- 89473 - General Electric Distributing Corp (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5920-00-574-7510
- Characteristic
- Specifications
- FIIG
- Specifications
- A014A0
- Accommodated Ferrule Diameter [AGUK]
- 0.150 Inches Nominal
- Accommodated Fuse Length [AGUJ]
- 1.250 Inches Nominal
- Body Material [AAFZ]
- Plastic, Phenolic, Mil-M-14, Type Cfg
- Body Style [AAQL]
- Bushing Mounted Type
- Bushing Diameter [ABKH]
- 0.625 Inches Nominal
- Bushing Hole Diameter [AGVF]
- 0.625 Inches Minimum And 0.635 Inches Maximum
- Bushing Thread Length [AGUU]
- 0.469 Inches Nominal
- Cap Diameter [AGUV]
- 0.750 Inches Nominal
- Contact Material [AFRG]
- Beryllium Copper
- Contact Surface Treatment [AFRH]
- Nickel Plated
- Current Carrying Rating In Amps [CQJL]
- 18.0
- Fuse Terminal Type Accommodated [CSNM]
- Ferrule
- Environmental Protection [ADZC]
- Dripproof
- Flatted Side Bushing Hole Length [AGVH]
- 0.585 Inches Minimum And 0.595 Inches Maximum
- Mounting Hole Style [AEVB]
- Bushing Mounting
- Mounting Hole Quantity [ABTJ]
- 1
- Fuse Accommodation Quantity [AGUE]
- 1
- Length From Front Protrusion To Mounting Surface [AGUT]
- 0.688 Inches Nominal
- Overall Diameter [ADAV]
- 0.812 Inches Nominal
- Overall Length [ABHP]
- 2.453 Inches Maximum
- Voltage In Volts [ELEC]
- 250.0
- Terminal Type And Quantity [TTQY]
- 2 Tab, Solder Lug
- Terminal Material [ABDM]
- Brass
- Terminal Surface Treatment [ABDN]
- Tin Plated
Similar Supply Items to 5920-00-574-7510
Freight Information 5920-00-574-7510
5920-00-574-7510 has freight characteristics.. 5920-00-574-7510 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
Packaging Data 5920-00-574-7510
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- 0.25 lb or less, one dimension 2" or less, other dimensions less than 24"
- 85 to 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- --
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- MIL-P-130, Laminated and Creped Wrapping Paper
- No Requirement
- Not Applicable
- --
- No special marking
- MIL-P-130, Laminated and Creped Wrapping Paper
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- PPP-B-566 or PPP-B-676, Folding or Setup Box
