5920-00-320-7800
Cartridge Fuse
5920003207800 003207800 CLKL400-02 CLKL400-01
A fuse in which the element is inclosed in a cylindrical body. The element may be renewable. The terminals may be of varying types. It may contain a visual indication that the fusible element is severed, and may also provide an audible alarm through auxiliary circuitry. For noncylindrical items, see FUSE, INCLOSED LINK. View more Cartridge Fuse
May 2023
4
Marketplace 5920-00-320-7800
Request a Quotation from participating marketplace vendors
Related Documents 5920-00-320-7800 5+ Documents (More...)
/fsg-59/fsc-5920/us
Photo 1/2 NSN 5920-00-320-7800 (Identification) 2/2 - - 1.
BUY NE FedMall Updated Every Day 5920-00-320-7800 RQST NE Updated Every Day 5920-00-320-7800 RQST
Cartridge Fuse 5920003207800 003207800 5920-00-320-7800 RQST https//www.nsnlookup.com https//www.nsnlookup.com
5920003243228003243228 www.nsnlookup.com /fsg-59/fsc-5920/us 5920-00-324-3228 7800Cartridge Fuse5920003207800 003207800
/fsg-59/fsc-5920/us
Cartridge Fuse 5920003207800 003207800 for $1 a day Upgrade your Account Upgrade 5920-00-320-7800Cartridge
Fuse5920003207800 003207800 CLKL400-02 RQST NE Updated Every Day 5920-00-320-7800 RQST https//www.nsnlookup.com
/fsg-99/fsc-9999/uk
/fsg-99/fsc-9999/uk
Restrictions 5920-00-320-7800
5920-00-320-7800 is a Cartridge Fuse that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item contains Silver.
End Users 5920-00-320-7800
- US Navy (N9BN)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- N9ND
- Supplementary Collaborators:
- HD
Approved Sources 5920-00-320-7800
- Part Number
- Manufacturer
- Status
- CLKL400-02
- Manufacturer
- 0FWC8 - Global Electro Systems Inc (Active)
- Primary Buy
- Primary Buy
- CLKL400-01
- 72026 - Duro Equipment Co (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5920-00-320-7800
- Characteristic
- Specifications
- FIIG
- Specifications
- A01700
- Body Style [AAQL]
- Hole Type
- Center To Center Distance Between Inside Mounting Facilities Parallel To Length [AFWX]
- 2.500 Inches Nominal
- Center To Center Distance Between Mounting Facilities Parallel To Length [ABKQ]
- 4.000 Inches Nominal
- Circuit Over-Current Interruption Type [AFXF]
- Normal Instantaneous
- Continuous Current Rating In Amps [AEBJ]
- 400.000
- Features Provided [CBBL]
- Renewable Fusible Element
- Maximum Voltage Rating In Volts [AFXE]
- 600.0 Ac And 600.0 Dc
- Mounting Hole Diameter [ABTB]
- 0.250 Inches Nominal
- Interruption Indicator Method [AFXH]
- Opaque Body
- Precious Material [PRMT]
- Silver
- Precious Material And Location [PMLC]
- Terminal Surface Silver
- Short-Circuit/Interrupt Current Rating In Amps [CSQN]
- 200000.0
- Overall Diameter [ADAV]
- 1.500 Inches Nominal
- Overall Length [ABHP]
- 4.500 Inches Nominal
- Terminal Surface Treatment [ABDN]
- Silver Plated
- Terminal Thickness [AFWY]
- 0.188 Inches Nominal
- Terminal Width [AFWW]
- 1.000 Inches Nominal
DLA Procurement Analysis 5920-00-320-7800
Management Data 5920-00-320-7800
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5920-00-320-7800
Freight Information 5920-00-320-7800
5920-00-320-7800 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 062060. A Sub NMFC of Z. It has a NMFC Description of FUSES NOI IN BOXES. 5920-00-320-7800 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34740 which rates the freight between FCL and LCL. 5920-00-320-7800 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 72D for ocean manifesting and military sealift. 5920-00-320-7800 is not classified as a special type of cargo when transported by water. 5920-00-320-7800 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5920-00-320-7800
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- 0.25 lb or less, one dimension 2" or less, other dimensions less than 24"
- 85 to 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- MIL-DTL-17667, Neutral Wrapping Paper
- No Requirement
- Not Applicable
- --
- No special marking
- MIL-DTL-17667, Neutral Wrapping Paper
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
Contracting Technical Data File (CTDF) 5920-00-320-7800 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
