5920-00-142-7450
Block Fuseholder
5920001427450 001427450 522011
A fuseholder in which the fuseholder stud and/or clips and insulation are mounted on a flat base. Excludes FUSEHOLDER, RECEPTACLE. View more Block Fuseholder
May 2023
7
Marketplace 5920-00-142-7450
Request a Quotation from participating marketplace vendors
Related Documents 5920-00-142-7450 5+ Documents (More...)
5920-00-142-7450 5+ Documents ( More... ) https//www.nsnlookup.com /fsg-59/fsc-5920/us 5920-00-142-7450
Day 5920-00-142-7450 RQST NE Related Documents 5920-00-142-7450 5+ Documents ( More... ) https//www.nsnlookup.com
enable JavaScript in your web browser . 2530-66-130-1204Track Idler Wheel2530661301204 6613012046479-522011
Block Fuseholder 5920001427450 001427450 Documents 5920-00-142-7450 1+ Documents ( More... ) https
https//www.nsnlookup.com /fsg-59/fsc-5920/us 5920-00-142-7450 Block Fuseholder 5920001427450 001427450
for $1 a day Upgrade your Account Upgrade 5920-00-142-7450Block Fuseholder5920001427450 001427450 522011
0176-522011-0 0176-5220110 Managed by France NSN Created on 1 Jan 1967 Data Last Changed January 2023
-00176-52201100176-522011-0 F0086 - Daher Aerospace - Ex Socata ( https//www.nsnlookup.com /fsg-53/fsc
Restrictions 5920-00-142-7450
5920-00-142-7450 is a Block Fuseholder that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
Import and Export 5920-00-142-7450
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5920-00-142-7450
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
Approved Sources 5920-00-142-7450
- Part Number
- Manufacturer
- Status
- 522011
- Manufacturer
- 75915 - Littelfuse, Inc. (Active)
- Primary Buy
- Primary Buy
Datasheet 5920-00-142-7450
- Characteristic
- Specifications
- FIIG
- Specifications
- A014A0
- Fuse Accommodation Quantity [AGUE]
- 1
- Fuse Terminal Type Accommodated [CSNM]
- Ferrule
- Terminal Type And Quantity [TTQY]
- 2 Ferrule W/Screw
- Contact Material [AFRG]
- Brass
- Contact Surface Treatment [AFRH]
- Nickel Plated
- Overall Length [ABHP]
- 3.250 Inches Nominal
- Overall Height [ABKW]
- 1.062 Inches Nominal
- Overall Width [ABMK]
- 1.000 Inches Nominal
- Mounting Hole Quantity [ABTJ]
- 2
- Accommodated Fuse Length [AGUJ]
- 1.500 Inches Nominal
- Accommodated Ferrule Diameter [AGUK]
- 0.406 Inches Nominal
- Internal Circuit Configuration And Pole Quantity [CSDX]
- 1 Pole, Mainline, Fused
- Special Features [FEAT]
- Mounts By Two Holes For No. 6 Screw,Spaced 0.562 In. C To C
Similar Supply Items to 5920-00-142-7450
Freight Information 5920-00-142-7450
5920-00-142-7450 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061680. A Sub NMFC of Z. It has a NMFC Description of ELEC WIRING PLUGS ETC. 5920-00-142-7450 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. 5920-00-142-7450 is rated as class 77.5 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 34570 which rates the freight between FCL and LCL. It has a Water Commodity Code (WCC) of 658 for ocean manifesting and military sealift. 5920-00-142-7450 is not classified as a special type of cargo when transported by water. 5920-00-142-7450 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
